365S8GE: Description365 SERIES, PRESCALER, PDSO8; Categorysemiconductor logic; File Size354KB，6 Pages; ManufacturerHittite Microwave（ADI）; Websitehttp://www.hittite.com/

Download Datasheet Parametric Compare View All

365S8GE Overview

365 SERIES, PRESCALER, PDSO8

365S8GE Parametric

Parameter Name	Attribute value
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 Cel
Minimum operating temperature	-40 Cel
Maximum supply/operating voltage	5.25 V
Minimum supply/operating voltage	4.75 V
Rated supply voltage	5 V
Processing package description	PLASTIC, SMT-8
state	ACTIVE
packaging shape	RECTANGULAR
Package Size	SMALL OUTLINE, HEAT SINK/SLUG
surface mount	Yes
Terminal form	GULL WING
Terminal spacing	1.27 mm
terminal coating	TIN LEAD
Terminal location	DUAL
Packaging Materials	PLASTIC/EPOXY
Temperature level	INDUSTRIAL
series	365
Logic IC type	PRESCALER
Number of data clock inputs	1
Output polarity	COMPLEMENTARY
Max-Min frequency	13000 MHz

Preview

Download Datasheet

View All

HMC365S8G

365S8GE

v04.0506

SMT GaAs HBT MMIC

DIVIDE-BY-4, DC - 13.0 GHz

Features

Ultra Low SSB Phase Noise: -151 dBc/Hz

Wide Bandwidth

Output Power: 5 dBm

Single DC Supply: +5V

S8G SMT Package

Typical Applications

FREQUENCY DIVIDERS & DETECTORS - SMT

Prescaler for DC to Ku Band PLL Applications:

• Satellite Communication Systems

• Fiber Optic

• Point-to-Point and Point-to-Multi-Point Radios

• VSAT

Functional Diagram

General Description

The HMC365S8G & HMC365S8GE are low noise

Divide-by-4 Static Dividers with InGaP GaAs HBT

technology in 8 lead surface mount plastic packages.

This device operates from DC (with a square wave

input) to 13.0 GHz input frequency with a single +5.0V

DC supply. The low additive SSB phase noise of -151

dBc/Hz at 100 kHz offset helps the user maintain good

system noise performance.

Electrical Specifications,

= +25° C, 50 Ohm System, Vcc = 5V

Parameter

Maximum Input Frequency

Minimum Input Frequency

Input Power Range

Sine Wave Input. [1}

Fin = 1 to 8 GHz

Fin = 8 to 11 GHz

Fin = 11 to 13 GHz

Output Power

Reverse Leakage

SSB Phase Noise (100 kHz offset)

Output Transition Time

Supply Current (Icc)

1. Divider will operate down to DC for square-wave input signal.

Fin = 13 GHz

Both RF Outputs Terminated

Pin = 0 dBm, Fin = 6 GHz

Pin = 0 dBm, Fout = 882 MHz

-15

-10

-5

Conditions

Min.

Typ.

0.2

>-20

>-15

>-8

-151

100

110

0.5

+10

Max.

Units

GHz

dBm

dBc/Hz

6 - 44

For price, delivery, and to place orders, please contact Hittite Microwave Corporation:

20 Alpha Road, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373

Order On-line at www.hittite.com

365S8GE Related Products

	365S8GE	HMC365S8G	HMC365S8G_06
Description	365 SERIES, PRESCALER, PDSO8	365 SERIES, PRESCALER, PDSO8	365 SERIES, PRESCALER, PDSO8
Number of functions	1	1	1
Number of terminals	8	8	8
Maximum operating temperature	85 Cel	85 °C	85 Cel
Minimum operating temperature	-40 Cel	-40 °C	-40 Cel
surface mount	Yes	YES	Yes
Terminal form	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	DUAL	DUAL
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
series	365	365	365
Output polarity	COMPLEMENTARY	COMPLEMENTARY	COMPLEMENTARY
Maximum supply/operating voltage	5.25 V	-	5.25 V
Minimum supply/operating voltage	4.75 V	-	4.75 V
Rated supply voltage	5 V	-	5 V
Processing package description	PLASTIC, SMT-8	-	PLASTIC, SMT-8
state	ACTIVE	-	ACTIVE
packaging shape	RECTANGULAR	-	RECTANGULAR
Package Size	SMALL OUTLINE, HEAT SINK/SLUG	-	SMALL OUTLINE, HEAT SINK/SLUG
Terminal spacing	1.27 mm	-	1.27 mm
terminal coating	TIN LEAD	-	TIN LEAD
Packaging Materials	PLASTIC/EPOXY	-	PLASTIC/EPOXY
Logic IC type	PRESCALER	-	PRESCALER
Number of data clock inputs	1	-	1
Max-Min frequency	13000 MHz	-	13000 MHz
