74LVX14 — Low Voltage Hex Inverter with Schmitt Trigger Input
February 2008
74LVX14
Low Voltage Hex Inverter with Schmitt Trigger Input
Features
■
Input voltage level translation from 5V to 3V
■
Ideal for low power/low noise 3.3V applications
■
Guaranteed simultaneous switching noise level and
General Description
The LVX14 contains six inverter gates each with a
Schmitt trigger input. They are capable of transforming
slowly changing input signals into sharply defined, jitter-
free output signals. In addition, they have a greater noise
margin than conventional inverters.
The LVX14 has hysteresis between the positive-going
and negative-going input thresholds (typically 1.0V)
which is determined internally by transistor ratios and is
essentially insensitive to temperature and supply voltage
variations.
The inputs tolerate voltages up to 7V allowing the inter-
face of 5V systems to 3V systems.
dynamic threshold performance
Ordering Information
Order
Number
74LVX14M
74LVX14SJ
74LVX14MTC
Package
Number
M14A
M14D
MTC14
Package Description
14-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150" Narrow
14-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
