AZ23C3V6-TP: DescriptionZener Diodes 3.6V 300mW; CategoryDiscrete semiconductor diode; File Size233KB，4 Pages; ManufacturerMicro Commercial Components (MCC); Environmental Compliance

Download Datasheet Parametric Compare View All

AZ23C3V6-TP Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	AZ23C3V6-TP	-	-	View	Buy Now

AZ23C3V6-TP Overview

Zener Diodes 3.6V 300mW

AZ23C3V6-TP Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Micro Commercial Components (MCC)
package instruction	R-PDSO-G3
Contacts	3
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	COMMON ANODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	95 Ω
JESD-30 code	R-PDSO-G3
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	2
Number of terminals	3
Maximum operating temperature	175 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.3 W
Certification status	Not Qualified
Nominal reference voltage	3.6 V
surface mount	YES
technology	ZENER
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	10
Maximum voltage tolerance	5.55%
Working test current	5 mA

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

AZ23C2V7

THRU

AZ23C51

300

Zener Diode

2.7 to

Volts

Features

Dual zeners in common anode configuration.

300mW power dissipation rating.

Ideally suited for automatic insertion.

vz for both diodes in one case is

•

5%.

SOT-23

Epoxy meets UL 94 V-0 flammability rating

Moisture Sensitivity Level 1

Halogen

free available upon request by adding suffix "-HF"

Absolute Maximum Ratings

Symbol

Parameter

Power dissipation

Thermal Resistance, Junction to Ambient Air

Rating

300

Unit

DIMENSIONS

INCHES

MIN

.110

.083

.047

.035

.070

.018

.0005

.035

.003

.015

.007

MIN

2.80

2.10

1.20

.89

1.78

.45

.013

.89

.085

.37

.20

thJA

STG

417

-65 to +175

C/W

Storage Temperature Range

*Pin Configuration - Top View

DIM

MAX

.120

.104

.055

.041

.081

.024

.0039

.044

.007

.020

MAX

3.04

2.64

1.40

1.03

2.05

.60

.100

1.12

.180

.51

.50

NOTE

Revision:

www.mccsemi.com

1 of 4

2013/01/01
