PI4MSD5V9544A
4 Channel I2C bus Multiplexer with interrupt logic
Features
1-of-4 bidirectional translating multiplexer
I2C-bus interface logic;
Operating power supply voltage :1.65 V to 5.5 V
Allows voltage level translation between 1.2V,
1.8V,2.5 V, 3.3 V and 5 V buses
Low standby current
Low Ron switches
Channel selection via I2C bus
Power-up with all multiplexer channels deselected
Capacitance isolation when channel disabled
No glitch on power-up
Supports hot insertion
5 V tolerant inputs
0 Hz to 400 kHz clock frequency
ESD protection exceeds 8000 V HBM per JESD22-
A114, and 1000 V CDM per JESD22-C101
Latch-up testing is done to JEDEC Standard
JESD78 which exceeds 100 mA
Packages offered: TSSOP-20L
Only one SCx/SDx channel is selected at a time,
determined by the contents of the programmable control
register. Four interrupt inputs, INT0 to INT3, one for
each of the SCx/SDx downstream pairs, are provided.
One interrupt output, INT, which acts as an AND of the
four interrupt inputs, is provided.
A power-on reset function puts the registers in their
default state and initializes the I2C bus state machine
with no channels selected. The pass gates of the
multiplexer are constructed such that the VCC pin can
be used to limit the maximum high voltage which will
be passed by the PI4MSD5V9544A. This allows the use
of different bus voltages on each SCx/SDx pair, so that
1.2V,1.8 V, 2.5 V or 3.3 V parts can communicate with
5 V parts without any additional protection.
External pull-up resistors pull the bus up to the
desired voltage level for each channel. All I/O pins are 5
V tolerant.
Pin Description
Pin
No
Pin
Name
Type
Input
Input
Input
Input
I/O
I/O
Input
Description
Description
The PI4MSD5V9544A is a 1-of-4 bidirectional
translating multiplexer, controlled via the I2C bus.
The SCL/SDA upstream pair fans out to four
SCx/SDx downstream pairs, or channels.
1
2
3
4
5
6
7
8
9
10
11
12
A0
A1
A2
INT0
address input 0
address input 1
address input 2
active LOW interrupt input 0
serial data 0
serial clock 0
Pin Configuration
SD0
SC0
INT1
SD1
SC1
GND
INT2
active LOW interrupt input 1
I/O
serial data 1
serial clock 1
I/O
Ground
supply ground
Input
I/O
I/O
Input
I/O
I/O
Output
I/O
I/O
Power
active LOW interrupt input 2
serial data 2
serial clock 2
active LOW interrupt input 3
serial data 3
serial clock 3
active LOW interrupt output
serial clock line
serial data line
Power supply
SD2
SC2
INT3
TSSOP20
13
14
15
16
17
18
19
20
SD3
SC3
INT
SCL
SDA
VCC
2015-07-0035
1
PT0525-4
8/18/15
PI4MSD5V9544A
4 Channel I2C/SMBus Multiplexer
with Interrupt Logic
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Block Diagram
Figure 1: Block Diagram
Maximum Ratings
Storage Temperature .................................................–55° to +125°
C
C
Supply Voltage port B .................................................–0.5V to +6.0V
Supply Voltage port A ................................................–0.5V to +6.0V
DC Input Voltage ....................................................... –0.5V to +6.0V
Control Input Voltage (EN)… .................................. –0.5V to +6.0V
Total power dissipation
(1)
.......................................................100mW
Input current(EN,VCCA,VCCB,GND).....................................50mA
ESD: HBM Mode .....................................................................8000V
Note:
Stresses greater than those listed under MAXIMUM
RATINGS may cause permanent damage to the
device. This is a stress rating only and functional
operation of the device at these or any other condi-
tions above those indicated in the operational sec-
tions of this specification is not implied. Exposure
to absolute maximum rating conditions for extended
periods may affect reliability.
Recommended operation conditions
Symbol
V
CC
V
EN
V
IO
Δt /ΔV
T
A
Enable Control Pin Voltage
I/O Pin Voltage
Input transition rise or fall time
Operating Temperature Range
Parameter
V
CCA
Positive DC Supply Voltage
Min
1.65
GND
GND
-
−40
Typ
-
-
-
-
-
Max
5.5
5.5
5.5
10
+85
Unit
V
V
V
ns/V
°
C
2015-07-0035
2
PT0525-4
8/18/15
PI4MSD5V9544A
4 Channel I2C/SMBus Multiplexer
with Interrupt Logic
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DC Electrical Characteristics
Unless otherwise specified, -40°C≤T
A
≤85° 1.1V≤Vcc≤3.6V
C,
Symbol
Supply
VCC
Supply Voltage
operating mode;
no load;
V
I
= VCC or GND;
fSCL = 100 kHz
standby mode; VCC =
3.6 V;
no load; V
I
= VCC or
GND;
fSCL = 0 kHz
no load; V
I
= VCC or
GND
3.6V to 5.5V
2.3V to 3.6V
1.65V to 2.3V
3.6V to 5.5V
2.3V to 3.6V
1.65V to 2.3V
3.6V to 5.5V
1.65
65
20
10
0.3
0.1
0.1
1.3
5.5
100
50
30
1
1
1
1.5
V
uA
uA
uA
uA
uA
uA
V
Parameter
Conditions
VCC
Min
Typ
Max
Unit
ICC
supply current
Istb
standby current
VPOR
[1]
power-on reset voltage
Input SCL; input/output SDA
V
IL
V
IH
LOW-level input voltage
HIGH-level input voltage
V
OL
= 0.4 V
V
OL
= 0.6 V
V
I
= GND
V
I
= VCC
VI = GND
1.65V to 5.5V
1.65V to 2V
2V to 5.5V
1.65V to 5.5V
1.65V to 5.5V
1.65V to 5.5V
1.65V to 5.5V
3.6V to 5.5V
-0.5
0.75V
CC
0.7V
CC
3
6
-1
-1
-
12
+0.3V
CC
6
6
-
-
+1
+1
13
V
V
V
mA
mA
uA
uA
pF
Ω
Ω
Ω
Ω
V
4.5
2.2
1.6
1.5
1.1
0.9
0.54
-1
3
1.3
+1
5
2
2.8
V
V
V
V
V
V
V
uA
pF
I
OL
I
IL
I
IH
Ci
Pass Gate
LOW-level output current
LOW-level input current
HIGH-level input current
input capacitance
V
O
= 0.4 V;
I
O
= 15 mA
Ron
ON-state resistance
V
O
= 0.4 V;
I
O
= 10mA
4.5 V to 5.5 V
3V to 3.6V
2.3V to 2.7V
1.65V to 2V
5V
4.5 V to 5.5 V
3.3V
4
5
7
9
9
11
16
20
3.6
24
31
55
70
2.8
Vpass
switch output voltage
Vin =VCC;
Iout = -100uA
3V to 3.6V
2.5V
2.3V to 2.7V
1.8V
1.65V to 2V
I
L
Cio
leakage current
input/output capacitance
VI = VCC or GND
VI = VCC or GND
1.65V to 5.5V
1.65V to 5.5V
To be continued
2015-07-0035
3
PT0525-4
8/18/15
PI4MSD5V9544A
4 Channel I2C/SMBus Multiplexer
with Interrupt Logic
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Continued
Symbol
Parameter
Conditions
VCC
Min
Typ
Max
Unit
Select inputs A0, A1, A2, INT0, INT1,INT2,INT3
V
IL
V
IH
I
IL
Ci
INT output
I
OL
I
OH
LOW-level output current
HIGH-level output current
V
OL
= 0.4 V
1.65V to 5.5V
1.65V to 5.5V
3
+10
mA
uA
LOW-level input voltage
HIGH-level input voltage
LOW-level input current
input capacitance
V
I
= GND
V
I
= GND
1.65V to 5.5V
1.65V to 5.5V
1.65V to 5.5V
1.65V to 5.5V
-0.5
0.7V
CC
-1
3
+0.3V
CC
6
+1
5
V
V
uA
pF
Note:
VCC must be lowered to 0.2 V for at least 5 us in order to reset part.
AC Electrical characteristics
Tamb = - 40
ºC
to +85
ºC;
unless otherwise specified.
Symbol
t
PD[1]
INT
[2]
t
V_INT
t
D_INT
t
REJ_L
valid time from INTn to
INT signal
delay time from INTn to
INT inactive
LOW-level rejection time
1.65V to 5.5V
1.65V to 5.5V
1.65V to 5.5V
1
4
2
us
us
us
us
Parameter
propagation delay
Conditions
from SDA to SDx,
or SCL to SCx
VCC
1.65V to 5.5V
Min
Typ
Max
0.3
Unit
ns
t
REJ_H
HIGH-level rejection time
1.65V to 5.5V
0.5
Note
[1]Pass gate propagation delay is calculated from the 20Ω typical Ron and the 15 pF load capacitance.
[2] Measurements taken with 1 kΩpull-up resistor and 50 pF load.
2015-07-0035
4
PT0525-4
8/18/15
PI4MSD5V9544A
4 Channel I2C/SMBus Multiplexer
with Interrupt Logic
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
I2C Interface Timing Requirements
Symbol
fscl
t
Low
t
High
t
SP
t
SU:DAT
t
HD:DAT
tr
tf
t
BUF
t
SU:STA
t
HD:STA
t
SU:STO
t
VD:DAT
Parameter
I2C clock frequency
I2C clock high time
I2C clock low time
I2C spike time
I2C serial-data setup time
I2C serial-data hold time
I2C input rise time
I2C input fall time
I2C bus free time between stop and start
I2C start or repeated start condition setup
I2C start or repeated start condition hold
I2C stop condition setup
Valid-data time (high to low)
[3]
SCL low to SDA output low valid
Valid-data time (low to high)
[3]
SCL low to SDA output high valid
Valid-data time of ACK condition
ACK signal from SCL low to SDA output low
I2C bus capacitive load
4.7
4.7
4
4
1
0.6
250
0
[1]
1000
300
1.3
0.6
0.6
0.6
1
0.6
STANDARD MODE
I
2
C BUS
MIN
MAX
FAST MODE
I
2
C BUS
MIN
MAX
UNIT
0
4.7
4
100
0
1.3
0.6
400
kHz
μs
μs
50
100
0
[1]
50
ns
ns
μs
300
300
ns
ns
μs
μs
μs
μs
μs
μs
μs
pF
t
VD:ACK
Cb
1
400
1
400
Notes:
[1] A device internally must provide a hold time of at least 300 ns for the SDA signal (referred to as the VIH min of the SCL
signal), in order to bridge the undefined region of the falling edge of SCL.
[2] Data taken using a 1-kΩ pullup resistor and 50-pF load Notes
Figure 2. Definition of timing on the I2C-bus
2015-07-0035
5
PT0525-4
8/18/15
