3 WATTS REGULATED OUTPUT POWER
•
2:1 WIDE INPUT VOLTAGE RANGE
•
INTERNATIONAL SAFETY STANDARD APPROVAL
•
FIVE-SIDED SHIELD
•
HIGH EFFICIENCY UP TO 80%
•
STANDARD 24 PIN DIP PACKAGE & SMD TYPE PACKAGE
•
OVER CURRENT PROTECTION
The YKC03 series offers 3 watts of output power from a package in an IC compatible
24pin DIP configuration without derating to 71ºC ambient temperature. YKC03 series
have 2:1 wide input voltage of 9-18, 18-36 and 36-75VDC. The YKC03 features
1600VDC of isolation, short-circuit protection and as well as five sided shielding. A safety
designed meet to EN60950 and UL1950. All models are particularly suited to
telecommunications, industrial, mobile telecom and test equipment applications.
UL E193009
TUV R3-50007936
CB JPTUV-003641
CE MARK
T E C H N I C A L S P E C I F I C AT I O N
OUTPUT SPECIFICATIONS
Output power
Voltage accuracy
Minimum load (Note 1)
Line regulation
Load regulation
Cross regulation
Ripple and noise
Temperature coefficient
LL to HL at Full Load
25% to 100% FL Single
Dual
Asymmetrical load 25% / 100% FL
20MHz bandwidth
Full load and nominal Vin
All specifications are typical at nominal input, full load and 25ºC otherwise noted
GENERAL SPECIFICATIONS
3 Watts max
± 2%
10% of FL
± 0.2%
± 0.2%
± 1%
± 5%
50mVp-p
I0.02%
/ ºC, max
200uS
180% typ
Isolation voltage
Isolation resistance
Isolation capacitance
Switching frequency
Design meet safety standard
Case material
Base material
Potting material
Dimensions
Weight
9 – 18VDC
18 – 36VDC
36 – 75VDC
Pi type
36VDC
50VDC
100VDC
20mAp-p
350mS typ
MTBF (Note 3)
DIP
SMD
Efficiency
Input to Output
Input(Output) to Case DIP
SMD
See table
1600VDC, min
1600VDC, min
1000VDC, max
10 ohms, min
300pF, max
300KHz, typ
UL1950, EN60950
Nickel-coated copper
Non-conductive black plastic
Epoxy (UL94-Vo)
1.25 X 0.80 X 0.40 Inch
(31.8 X 20.3 X 10.2 mm)
16g (0.55oz)
18g (0.62oz)
3.139 x 10
6
hrs
9
Transient response recovery time 25% load step change
Over load protection
Short circuit protection
% of FL at nominal input
Continuous, automatics recovery
INPUT SPECIFICATIONS
Input voltage range
Input filter
Input surge voltage
100mS max
12V input
24V input
48V input
Nominal Vin and full load
12V nominal input
24V nominal input
48V nominal input
ENVIRONMENTAL SPECIFICATIONS
Operating temperature range
Maximum case temperature
Storage temperature range
Thermal impedance
Thermal shock
Vibration
Nature convection
Standard
-25ºC ~ +85ºC (with derating)
M1 (Note 4) -40ºC ~ +85ºC (non-derating)
100ºC
-55ºC ~ +105ºC
20ºC/Watt
MIL-STD-810D
10~55Hz, 2G, 30minutes along X,Y and Z
5% to 95% RH
Input reflected ripple (Note 2)
Start up time
Nominal Vin and constant resistor load
OUTPUT POWER (%)
YKC03-48S05 Derating Curve
100
Relative humidity
EMC CHARACTERISTICS
M1 Version
M! Version
Conducted emissions
Radiated emissions
ESD
EN55022
EN55022
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
Level A
Level A
Perf. Criteria2
Perf. Criteria2
Perf. Criteria2
Perf. Criteria2
Perf. Criteria2
75
50
25
Nature convection
50 60 70 80
90 100
Radiated immunity
Fast transient
Surge
Conducted immunity
0
-40 -25 -10 0
AMBIENT TEMPERATURE (ºC)
Model
Number
YKC03-12S05
YKC03-12S12
YKC03-12S15
YKC03-12D05
YKC03-12D12
YKC03-12D15
YKC03-24S05
YKC03-24S12
YKC03-24S15
YKC03-24D05
YKC03-24D12
YKC03-24D15
YKC03-48S05
YKC03-48S12
YKC03-48S15
YKC03-48D05
YKC03-48D12
YKC03-48D15
Input
Range
9 – 18 VDC
9 – 18 VDC
9 – 18 VDC
9 – 18 VDC
9 – 18 VDC
9 – 18 VDC
18 – 36 VDC
18 – 36 VDC
18 – 36 VDC
18 – 36 VDC
18 – 36 VDC
18 – 36 VDC
36 – 75 VDC
36 – 75 VDC
36 – 75 VDC
36 – 75 VDC
36 – 75 VDC
36 – 75 VDC
Output
Voltage
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
Output
Current
500mA
250mA
200mA
± 250mA
± 125mA
± 100mA
500mA
250mA
200mA
± 250mA
± 125mA
± 100mA
500mA
250mA
200mA
± 250mA
± 125mA
± 100mA
Input
(5)
Current
290mA
329mA
334mA
290mA
334mA
334mA
151mA
169mA
171mA
151mA
174mA
171mA
76mA
83mA
82mA
76mA
85mA
86mA
Eff
(%)
76
80
79
76
79
79
73
78
77
73
76
77
73
79
80
73
78
77
(6)
Capacitor
Load max
1000uF
220uF
150uF
± 470uF
± 100uF
± 68uF
1000uF
220uF
150uF
± 470uF
± 100uF
± 68uF
1000uF
220uF
150uF
± 470uF
± 100uF
± 68uF
(7)
Note
1.
2.
3.
4.
5.
6.
7.
The YKC03 series required a minimum 10% loading on the output to maintain specified regulation. Operation under no-load condition will not damage
these devices, however they may not meet all listed specification.
Simulated source impedance of 12uH. 12uH inductor on series with + Vin.
BELLCORE TR-NWT-000332. Case I: 50% Stress, Temperature at 40ºC. (Ground fixed and controlled environment)
M1 version is more efficient, therefore, it can be operated in a more extensive temperature range than standard.
Maximum value at nominal input voltage and full load of standard type.
Typical value at nominal input voltage and full load.
Test by minimum Vin and constant resistor load.
Suffix: ”S”
0.10 (2.54)
0.08(2.0)
0.01 x 0.02 (0.25 x 0.50)
Rectangular Pin
1.00(25.4)
0.92(23.4)
0.02(0.5)
0.44(11.2)
0.43(10.9)
0.90 (22.9)
24
1
1.25 (31.8)
20
BOTTOM
VIEW
5
15
13
0.60(15.2)
0.80(20.3)
0.15
(3.8)
0.40
(10.2)
Pin Area
0.04 x 0.02
(1.0 x 0.5)
13
12
0.80(20.3)
1. All dimensions in Inches (mm)
2. Pin pitch tolerance
I0.014(0.35)
DIP PIN CONNECTION
PIN
1
2
10
11
12
SINGLE
+ INPUT
+ INPUT
DUAL
+ INPUT
+ INPUT
PIN
24
23
15
13
SINGLE
- INPUT
- INPUT
NC
DUAL
- INPUT
- INPUT
+ OUTPUT
PIN
1
2
SMD PIN CONNECTION
SINGLE
+ INPUT
+ INPUT
DUAL
+ INPUT
+ INPUT
PIN
24
23
SINGLE
- INPUT
- INPUT
DUAL
- INPUT
- INPUT
NC
COMMON
NC
COMMON
- OUTPUT
NC
+ OUTPUT - OUTPUT
10
NC
15
NC
+ OUTPUT
COMMON
11
NC
COMMON
12
- OUTPUT
NC
13 + OUTPUT - OUTPUT
Others
NC
NC
Others
NC
NC
0.25 (6.35)
10
11
12
16
9
1.26 (32.0)
BOTTOM
VIEW
0.10 (2.5)
0.15 (3.81)
24
23
1
2
FPGA/CPLD
