8852-0-15-15-30-27-04-0 datasheet, PDF

Datasheet> All Categories > The connector> terminals> 8852-0-15-15-30-27-04-0

8852-0-15-15-30-27-04-0: DescriptionCircuit Board Hardware - PCB 10u AU OVER NI 30 CON; CategoryThe connector terminals; File Size603KB，1 Pages; ManufacturerMill-Max; Websitehttps://www.mill-max.com; Environmental Compliance

Download Datasheet Parametric Compare View All

8852-0-15-15-30-27-04-0 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	8852-0-15-15-30-27-04-0	-	-	View	Buy Now

8852-0-15-15-30-27-04-0 Overview

Circuit Board Hardware - PCB 10u AU OVER NI 30 CON

8852-0-15-15-30-27-04-0 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mill-Max
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
terminal gender	MALE
Terminal and terminal strip types	PCB TERMINAL
Base Number Matches	1

Preview

Download Datasheet

View All

RECEPTACLES

FOR .015” - .025” DIAMETER PINS

0385

0385-0-15-XX-43-XX-10-0

Press-fit in .046 mounting hole

4001

4001-0-15-XX-43-XX-04-0

Press-fit in .057 mounting hole

1782

1782-0-15-XX-43-XX-04-0

Press-fit in .045 mounting hole

5960

5960-0-15-XX-43-XX-04-0

Hex press-fit in .057 plated through-hole

1401/3185

XXXX-0-15-XX-30-XX-10-0

Solder mount in .055 min. mounting hole

Also available on 16mm wide carrier tape:

1,700 parts per 13” reel

Order as: XXXX-0-57-XX-30-XX-10-0

4310

Basic Part

Number

Length

Depth

4310-0-31-XX-43-XX-04-0

Compliant press-fit in .040 ± .003 plated

through-hole. For .090”

.130”

thick board

1385

1385-0-15-XX-43-XX-10-0

Surface mount

1401-0

3185-0

.165

.130

.145

.109

3018

3018-0-15-XX-30-XX-04-0

Press-fit in .057 mounting hole

8852

8852-0-15-XX-30-XX-04-0

Press-fit in .056 mounting hole

3907

3907-0-18-XX-30-XX-10-0

Surface mount

Also available on 12mm wide carrier tape:

4,000 parts per 13” reel

Order as: 3907-0-58-XX-30-XX-10-0

.100 DIA.

.020

.083

.115

.043 DIA.

.010

.095

.060

.059

.080

.084 DIA.

P.C.B. Layout

.069

PAGE 170 | PIN RECEPTACLES

P.C.B. PAD

.095

SPECIFICATIONS:

Shell Material:

Brass Alloy 360, 1/2 Hard

Contact Material:

Beryllium Copper Alloy 172, HT

Dimensions: Inches

Tolerances On:

Lengths:

± .005

RoHS - 2

2011/65/EU

ORDER CODE: XXXX - X - XX - XX -

- XX - XX - 0

BASIC PART #

SPECIFY SHELL FINISH:

200

”

TIN/LEAD OVER NICKEL

200

”

TIN OVER NICKEL (RoHS)

”

GOLD OVER NICKEL (RoHS)

SPECIFY CONTACT FINISH:

100

”

TIN/LEAD OVER NICKEL

100

”

TIN OVER NICKEL (RoHS)

”

GOLD OVER NICKEL (RoHS)

Diameters: ± .002

Angles:

±2°

SELECT CONTACT:

#30, #35 or #43

CONTACT (DATA ON PAGE 253 & 254)

(For alternate contact choices, see groups B and C on page 248)

Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
