PREMIUM PLASTIC LITHIUM & ALKALINE CELL HOLDERS
For “1/2AA” · “AA” · “2/3A”
108C,
1028C &
1029LC
RETAINER
COVER
SHOWN
WITH OPTIONAL
RETAINER COVER
INSTALLED
1029C
RETAINER
COVER
A
B
.375 [9.5]
SPECIFICATIONS
Base:
PBT, UL Rated 94V-0
Retainer Cover:
PBT, UL Rated 94V-0
Contacts:
.012 (.30) thick Spring Steel,
Tin Nickel Plate
C
.125 [3.2] DIA.
(2) PLS
FEATURES
•
Snap-In PC contact holds in position for wave soldering
•
Tin Nickel Plated contacts for excellent solderability and durability
•
Polarity clearly marked for orientation
•
Low Profile, space-saving
•
Snap-on retainer cover (optional) retains battery securely to withstand
shock and vibration. Helps protect against shorting. Tamper-proof.
APPLICATIONS
•
Computer memory, power transfer and back-up systems
•
Video and telecommunications power back-up requirements
•
Preprogrammed video and electronic games
•
Microprocessor, microcomputers, minicomputers, notebook, laptop and
handheld computer memory hold applications
•
Emergency power systems
•
Residential, industrial and commercial security and fire alarm systems
CELL
SIZE
“1/2 AA”
D
LITHIUM BATTERY HOLDERS
.600
[15.2]
Mounting Detail
.094 [2.4] DIA.
FOR LEG
.140
[3.6]
E
.038
[0.97]
.062 [1.57] DIA.
x .062 [1.57] L. LEG
W
L
.047 [1.19] DIA.
(2) PLS FOR
PC CONTACT
HOLDER COVER
CAT.
CAT.
NO.
NO.
108
1028
1029
108C
DIMENSIONS
A
(MAX)
1.360 (34.5)
B
.610 (15.5)
C
D
E
MTG HOLES
L
W
.279 (7.1)
BATTERY CROSS REFERENCE
Eveready:
544,
Duracell:
PX28L,
Kodak:
K28A & KS28,
Panasonic:
CR14250,
Saft:
LCP3,
Electrochem:
3B955,
Maxell:
4LR44,
Sanyo:
CR14250SE
Eveready:
E9,EV15, E91, E177, 505, 1015,
Duracell:
ZM9, NC15,
M15F, TR177, M505, MN1500,PC1500,
Panasonic:
UM-3 &
P-45AA,
Sanyo:
N-600AA & N-700AA,
Rayovac:
5AA, 7AA, 615,815
Duracell:
DL2/3A,
Panasonic:
CR123A,
Saft:
450SC &VR0450,
Electrochem:
3B793 & 3B950,
Sanyo:
CR17335SE,
Kodak:
K123L
.640 (16.3) 1.030 (26.2) 1.160 (29.5) 1.160 (29.5)
1028C
2.360 (59.9) 1.610 (40.9)
1029C
1.700 (43.2) .950 (24.1)
1029LC
.640 (16.3) 2.030 (51.6) 2.160 (54.9) 2.160 (54.9)
.720 (18.3)
1.375 (34.9) 1.500 (38.1) 1.500 (38.1)
.279 (7.1)
.320 (8.1)
“AA”
“2/3 A”
RUGGED STEEL & ALUMINUM LITHIUM CELL HOLDERS
STEEL HOLDERS
•
Available in steel and aluminum
•
Ideal for punishing applications
•
Sturdily constructed of quality materials
•
Contacts made from Brass, Nickel Plate
ALUMINUM HOLDERS
ADDITIONAL SPECIFICATIONS
FIG. 1
Mounting Detail
.082 [2.10] DIA.
(2) PLS FOR
PC CONTACT
FIG. 2
Steel Holders: Refer to page 13
Aluminum Holders: Refer to page 15
FIG. 3
FIG. 4
Mounting Detail
A
.128 [3.3] DIA.
(3) PLS
.437
[11.1]
.430 [10.9]
L
STD LUGS FIG.
CAT. NO.
NO.
1103
2
1105
2
132
3
PC LUGS
CAT. NO.
2103
2105
131
FIG. BATTERY
BATTERY
DURA- PANA-
SANYO
NO.
SIZE
DIA.
CELL
SONIC
(G.E.)
1
“1/2 AA”
.510
×
.990 (13.0
×
25.1) P× 28L CR14250 CR14250SE
1
“1/2 A”
.611
×
.866 (15.5
×
22.0)
—
BR-1/2A
—
4
“2/3 A”
.661
×
1.315 (16.8
×
33.4) DL-2/3A BR-2/3A CR17335SE
.082 [2.10] DIA.
(2) PLS FOR
PC CONTACT
.118 [3.0] DIA.
(4) PLS
.437
[11.1]
1.125 [28.6]
1.557 [39.6]
6 VOLT LITHIUM CELL HOLDERS
PC Terminals
1.125 [28.6]
.415 [10.5]
1.656
.750
[42.1]
[19.1]
REF. 1.000
[25.4]
.125 [3.2] DIA.
(2) PLS
POLARIZING
TAB
SPRING
.187 [4.75] TAB
.836 [21.25]
REF.
.415 [10.54]
1.656
.750
[42.06] 1.000 [19.05]
REF. [25.40]
Quick Fit/Solder Lug
1.125 [28.58]
.125 [3.18] DIA.
(2) PLS
POLARIZING
TAB
SPRING
224
223
.238 [6.1]
.205 [5.21] TAB
•
Polarizing Tab for proper orientation
•
Lightweight, ideal for rugged applications
•
DL223A or Equivalent Batteries
SPECIFICATIONS
Frame:
Aluminum 2024-T3
Terminals:
Brass, Tin Plate
Spring Contacts:
.025 (.64) Dia. Spring Steel, Nickel Plate
.648 [16.5]
.600
[15.2]
.750 [19.1]
.075 [1.9]
.648 [16.46]
.239 [6.06]
.600
[15.24]
CAT. NO. 224
®
CAT. NO. 223
Tel (718) 956-8900
•
Fax (718) 956-9040
(800) 221-5510
•
kec@keyelco.com
RoHS COMPLIANT
~
ISO 9001 CERTIFIED
www.keyelco.com
31-07 20th Road – Astoria, NY 11105-2017
