Thru-Hole DIP Switches
SPST Rocker
FEATURES
• Raised and Recessed, Rocker
and PIANO-DIP
®
Styles
• Sealed Base Standard
• Spring and Ball Contact
• Top Tape Seal Option
SERIES 76
DIP Switches
DIMENSIONS
in inches (and millimeters)
PIANO-DIP
®
End Views
Rocker and Recessed Rocker
B = .156 ± .010
(3,96 ± 0,25)
TYPICAL
.020 + .005 –.000
(0,51 + 0,13)
LENGTH
± .010 (±0,25)
SEE ORDER INFO.
1
2
3
4
5
6
7
LENGTH
± .010 (±0,25)
SEE ORDER INFO.
.281 ± .010
(7,14 ± 0,25)
TYP.
.380 ± .010
(9,65 ± 0,25)
B
.012 ± .001
(0,30 ± 0,03)
.300 + .030 –.000
(7,62 + 0,76)
A = .272 ± .010
(6,91 ± 0,25)
A
.020 + .005
–.000
(0,51 + 0,13)
.012 ± .001
(0,30 ± 0,03)
.300 + .030 –.000
(7,62 + 0,76)
.380 ± .010
(9,65 ± 0,25)
OPEN
OPEN
Rocker
1
2
3
4
5
6
7
8
C
L
C
L
.020 ± .002
(0,51 ± 0,05)
See also end view.
.090 ± .005
(2,29 ± 0,13)
.100 ± .005
(2,5 ± 0,13)
.020 ± .002
(0,51 ± 0,05)
See also end view.
.090 ± .005
(2,29 ± 0,13)
.100 ± .005
(2,5 ± 0,13)
.295 + .000
–.020
(7,49 –0,51)
.156 ± .010
(3,96 ± 0,25)
TYP.
C
L
C
L
For recessed rockers, delete .295 dimension.
CIRCUITRY
Styles 76SB and 76RSB
Style 76PSB
UP IS OPEN (OFF)
Styles 76PRB
UP IS CLOSED (ON)
Typical circuit diagram with actuator
in the closed position.
Actuator shown in the down position.
Actuator shown in the down position.
ORDERING INFORMATION
Series
Switch Style:
No. of Pos.
SB = Raised Rocker
RSB = Recessed Rocker
PSB = Piano-DIP (Up is Off )
PRB = Piano-DIP (Up is On)
2
3
4
5
6
7
8
10
12
Length (Inches)
0.280"
0.380"
0.480"
0.580"
0.680"
0.780"
0.880"
1.080"
1.280"
Length (Metric)
7,1 mm
9,7 mm
12,2 mm
14,7 mm
17,3 mm
19,8 mm
22,4 mm
27,4 mm
32,5 mm
No./Tube
35
27
21
18
15
13
12
9
8
76RSB04ST
T = RoHS compliant
Sealed*: S = Tape Seal
Number of Positions: 02 through 10, 12
*A top tape seal is required for switches that are machine
soldered or heavily cleaned after hand soldering. To order top
seal versions, add "S" to the Grayhill part number.
Available from your local Grayhill Distributor.
For prices and discounts, contact a local Sales Office,
an authorized local Distributor or Grayhill.
