July 5, 2016 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • 200041AC
DATA SHEET • MIXER AND DETECTOR SCHOTTKY DIODES
Electrical and Mechanical Specifications
The absolute maximum ratings of the mixer and detector Schottky
diodes are provided in Table 2. Electrical specifications are
provided in Tables 3 and 4. The associated SPICE model
parameters are provided in Table 5. A typical detector schematic
diagram is shown in Figure 1.
Typical performance characteristics are illustrated in Figures 2
and 3. Package dimensions are shown in Figures 4 to 10 (even
numbers), and tape and reel dimensions are provided in Figures 5
to 11 (odd numbers).
Package and Handling Information
Instructions on the shipping container label regarding exposure to
moisture after the container seal is broken must be followed.
Otherwise, problems related to moisture absorption may occur
when the part is subjected to high temperature during solder
assembly.
The mixer and detector Schottky diodes are rated to Moisture
Sensitivity Level 1 (MSL1) at 260
C
for 5 seconds. They can be
used for lead or lead-free soldering. For additional information,
refer to the Skyworks Application Note,
Solder Reflow Information,
document number 200164.
Care must be taken when attaching this product, whether it is
done manually or in a production solder reflow environment.
Production quantities of this product are shipped in a standard
tape and reel format.
Table 2. Absolute Maximum Ratings
1
Parameter
Reverse voltage
Forward current, steady state
Power dissipation
Storage temperature
Operating temperature
Junction temperature
V
R
I
F
P
D
T
STG
T
A
T
J
–65
–65
Symbol
Minimum
Maximum
Rated V
B
50
75
+150
+150
+150
Units
V
mA
mW
C
C
C
1 Exposure to maximum rating conditions for extended periods may reduce device reliability. There is no damage to device with only one parameter set at the limit and all other parameters set
at or below their nominal value. Exceeding any of the limits listed here may result in permanent damage to the device.
ESD HANDLING:
Although this device is designed to be as robust as possible, electrostatic discharge (ESD) can damage this device.
This device must be protected at all times from ESD when handling or transporting. Static charges may easily produce
potentials of several kilovolts on the human body or equipment, which can discharge without detection.
Industry-standard ESD handling precautions should be used at all times.
Table 3. Electrical Specifications
1
(T
A
= +25
C
Per Junction, Unless Otherwise Noted)
Minimum V
B
@ 10
μA
(V)
2
Typical C
T
@ 0 V
(pF)
0.25
V
F
@ 1 mA
(mV)
260 to 320
Maximum Pair Configuration
ΔV
F
@ 1 mA
(mV)
10
Maximum R
T
2
(Ω)
18 @ 5 mA
Part Number
SMS7621 series
2 R
T
is the slope resistance.
Barrier
Low
1 Performance is guaranteed only under the conditions listed in this table.
