4
TYPE
LL1005FHL
Multilayer Chip Inductors
Meeting Your Needs
The LL1005-FHL Series is a multilayer ceramic chip inductor
with an EIA standard 0402 footprint, lead-free terminations, and
expanded electrical specifications with respect to inductance,
Q, self-resonant frequency, and operating temperature range.
L
W
T
A
Polarity Marking
Unit: mm
1nH~68nH
82nH~100nH
L (mm)
1.0±0.05
1.0±0.1
W (mm)
0.5±0.05
0.5±0.1
T (mm)
0.5±0.05
0.5±0.1
A (mm)
0.25±0.1
0.25±0.1
Features
• Inductance range: 1.0-100nH
• Miniature size: 0402 footprint (1.0mm x 0.5mm)
• Inductance specified at 100MHz and 800MHz
• Self-resonant frequency specified at
±15%
• Q: 8 ~ 50 typical (at 1800MHz)
• Temperature coefficient of inductance: +250ppm/°C
• Temperature range: –55°C to +125°C
• S-parameter data available upon request
• Packaged on tape and reel in 10,000 piece quantity
• Reflow solderable
• Lead-free terminations
Part Numbering
LL 1005 - FHL 10N J
Tolerance
(S=±0.3nH, J=±5%)
Inductance
Material
Dimensions
(LxW)
Type Name
STANDARD PARTS SELECTION GUIDE
TYPE LL1005-FHL
Inductance & Tolerance
TOKO
Part Number
at 100MHz
Lo
(nH)
LL1005-FHL1N0S
LL1005-FHL1N2S
LL1005-FHL1N5S
LL1005-FHL1N8S
LL1005-FHL2N2S
LL1005-FHL2N7S
LL1005-FHL3N3S
LL1005-FHL3N9S
LL1005-FHL4N7S
LL1005-FHL5N6S
LL1005-FHL6N8J
LL1005-FHL8N2J
LL1005-FHL10NJ
LL1005-FHL12NJ
LL1005-FHL15NJ
LL1005-FHL18NJ
LL1005-FHL22NJ
LL1005-FHL27NJ
LL1005-FHL33NJ
LL1005-FHL39NJ
LL1005-FHL47NJ
LL1005-FHL56NJ
LL1005-FHL68NJ
LL1005-FHL82NJ
LL1005-FHLR10J
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
L
Tol.*
S
S
S
S
S
S
S
S
S
S
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
at 800 (500) MHz
Lo
(nH)
0.93
1.1
1.4
1.7
2.0
2.5
3.1
3.7
4.4
5.3
6.5
7.9
9.7
12
15
18
23
30
36
44
50
60
77
95
122
L
Tol.*
± 0.5nH
± 0.5nH
± 0.5nH
± 0.5nH
± 0.5nH
± 0.5nH
± 0.5nH
± 0.5nH
± 0.5nH
± 0.5nH
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
Freq.
(MHz)
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
500
500
500
500
500
Q
min.
100
MHz
7
7
8
8
8
8
8
8
9
9
9
9
9
9
9
10
10
10
10
10
10
10
10
10
10
100
MHz
8.7
9.0
9.6
9. 0
1 0. 0
9. 9
9. 7
9. 9
10.2
10.7
10.8
11.3
11.1
11.8
12.4
12.0
11.9
12.4
12.0
12.0
11.5
11.9
11.7
13.1
13.2
300
MHz
15.5
16.5
17.5
16.5
17.5
18.0
17.0
18.5
18.0
18.5
18.5
20.0
19.0
19.5
19.0
18.5
18.5
19.0
16.5
17.0
15.5
19.5
17.9
19.1
19.1
Q (Typ.)
500
MHz
21.0
21.0
22.5
21.0
23.0
24.0
23.0
24.5
23.0
24.5
24.0
26.0
25.0
25.0
24.0
23.5
23.0
24.0
21.0
21.5
19.7
23.4
20.3
21.8
20.0
800
MHz
25.5
27.2
28.1
26.7
29.6
30.3
28.5
29.2
30.3
31.7
31.3
33.1
32.0
31.8
32.0
31.5
30.3
29.2
28.6
27.6
21.7
22.6
20.8
21.4
18.8
1000
MHz
31.5
31.0
31.5
30.0
33.0
35.0
33.5
35.5
33.0
34.0
34.5
37.0
35.0
34.0
32.0
30.5
28.5
26.5
25.0
25.0
22.2
17.8
—
—
—
1800
MHz
42.5
42.5
44.0
40.5
44.5
49.0
47.5
50.0
42.5
44.0
43.0
46.0
43.0
34.0
30.0
27.5
18.5
8.0
13.0
10.5
—
—
—
—
—
20000 min
16000 min
15000 ± 15%
15000 ± 15%
13000 ± 15%
9600 ± 15%
9100 ± 15%
7400 ± 15%
7000 ± 15%
6100 ± 15%
5600 ± 15%
4700 ± 15%
4300 ± 15%
3300 ± 15%
2800 ± 15%
2800 ± 15%
2500 ± 15%
2100 ± 15%
2100 ± 15%
1900 ± 15%
1500 ± 15%
1400 ± 15%
1300 ± 15%
1150 ± 15%
1030 ± 15%
SRF
(MHz)
RDC
(
Ω
)
max.
0.10
0.10
0.13
0.14
0.15
0.15
0.16
0.18
0.20
0.22
0.23
0.25
0.30
0.40
0.50
0.60
0.70
0.85
1.00
1.10
1.30
1.50
1.70
1.90
2.20
IDC
(mA)
max.
400
400
400
400
400
400
400
300
300
300
300
300
300
300
300
300
300
300
200
200
200
200
180
150
150
* Add tolerance to part number: S=±0.3nH, J =
±5%
Testing Conditions: (1) L,Q: Agilent 4291A/B (Test fixture Agilent 16192A)
1.800.PIK.TOKO
www.tokoam.com
(2) SRF: Agilent 8719D, 8720D
(3) RDC: Agilent 4338A/B
R-LOG0703A
1.847.297.0070
