• Please read rating and CAUTION (for storage and operating, rating, soldering and mounting, handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
S21J.pdf
2012.10.1
Pyroelectric Infrared
Sensors
Cat.No.S21E-8
Note
• Please read rating and CAUTION (for storage and operating, rating, soldering and mounting, handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
S21J.pdf
2012.10.1
for EU RoHS Compliant
•
•
•
All the products on this catalog are complied with EU RoHS.
EU RoHS is "the European Directive 2011/65/EU on the Restriction of the Use
of Certain Hazardous Substances in Electrical and Electronic Equipment".
For more details, please refer to our website 'Murata's Approach for EU RoHS'
(http://www.murata.com/info/rohs.html).
Note
• Please read rating and CAUTION (for storage and operating, rating, soldering and mounting, handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
S21J.pdf
2012.10.1
CONTENTS
Part Numbering
1
2
3
HIC
®
in this catalog are the trademarks of
Murata Manufacturing Co., Ltd.
1
2
3
6
7
8
11
21
2
SMD-Dual / Parallel Quad Type Pyroelectric Infrared Sensor IRS Series
Dual Type Pyroelectric Infrared Sensor IRA-E700 Series
Quad Type Pyroelectric Infrared Sensor IRA-E900 Series
Pyroelectric Infrared Sensor IRS/IRA Series Characteristics Data
Lens
Notice
3
Note
• Please read rating and CAUTION (for storage and operating, rating, soldering and mounting, handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
S21J.pdf
2012.10.1
Part Numbering
Pyroelectric Infrared Sensor
(Part Number)
IR
❶
❶Product
ID
❷Type
❸Characteristics
❹Individual
Specification Code
* Part Number shows only an example which might be different
from actual part number.
* "❸Characteristics" and "❹Individual Specification Code" might
have different digit number from actual Part Number.
S- B210ST 01 -R1
❷
❸
❹
❺
2
Note
• Please read rating and CAUTION (for storage and operating, rating, soldering and mounting, handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
S21J.pdf
2012.10.1
Pyroelectric Infrared Sensors for Reflow Soldering
SMD-Dual Type Pyroelectric Infrared Sensor
IRS-B210ST01
Series
1
SMD type Pyroelectric infrared sensors, IRS series, exhibit
high sensitivity and reliable performance made possible by
Murata's ceramic technology and packaging technology
developed over many years.
IRS-B series is approximately 50% smaller in volume and
10% thinner than our previous surface mount model.
Compared with common lead-type models, it is significantly
smaller with a lower profile approximately 20% less in
volume and 50% less in thickness than the former.
▊
Features
0.9
1. Reflow surface-mounting support
2. Smallest and ultra-thin throughout the trade
(4.7×4.7×2.4mm)
3. High sensitivity
4. Achieves superior electromagnetic noise resistance
characteristics
▊
Applications
▊
Dimensions
2.4
& Circuit Diagrams
4.7
3.8
(4)
(3)
(2)
(1)
(5)
1.4
0.3
4.9
0.5
Power Supply
Terminal
(Vin)
GND
Out Put Terminal
(Vout)
0.4
1.0
0.6
0.6
1.20
0.80
2.50
General Tolerance:
±0.2
(in mm)
1.9
01X
0.5
1. Human detection
2. TV
3. Air conditioning
4. Digital photo-frame
5. Personal computers
6. Automatic switches for lighting equipment
7. WEB cameras (IP cameras)
8. Automatic warm water cleaning toilet seats
9. Security devices
10. Other automatic switches
(ex. :LCD monitors, Air purifiers, Ventilation fans)
