4-channel, 40MSa Oscilloscope
4-channel voltmeter
2 programmable reference voltages
2-channel Arbitrary Waveform Generator
Triple-Output Power Supply (two programmable)
32-Channel Logic Analyzer
32-Channel Pattern Generator
Discrete digital I/O’s (buttons, switches, LEDs, etc)
Complete System!
Includes EE Board + WaveForms Software
The Digilent Electronics Explorer board (EE board) includes all of the test and measurement equipment needed to design and test
analog and digital circuits of all types. Built around a large solderless breadboard, the EE board includes oscilloscopes, waveform
generators, power supplies, voltmeters, reference voltage generators, and thirty-two digital signals that can be configured as a logic
analyzer, pattern generator, or any one of several static digital I/O devices. All of these instruments can be connected to circuits built
on the solderless breadboards using simple jumper wires.
Designed for daily use and intended for every student to own, the EE board combines everything needed to design and test circuits
in a single “all in one” device. Even in introductory classes, students can complete, test, and analyze real circuit designs as a part
of every homework assignment. No more once a week labs; now every student can complete designs in virtually any setting – any
residence can be a complete, 24-hour design studio!
The EE board is powered by the free, PC-based WaveForms™ software that makes it easy to acquire, store, analyze, produce and
reuse analog and digital signals. WaveForms™ runs well on virtually any notebook PC, including low-cost Netbooks. A high-speed
USB2 connection ensures all EE board instruments respond in near real-time.
WaveForms™ data files are stored using standard formats, making it easy to share data between instruments, and to export data to
word processors or graphics editors. This means well documented student lab/project reports can be completed using standard
office tools, and submitted electronically.
Integrated Analog/Digital
Circuit Design Station
Oscilloscope
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
4 channels, 40MSa/sec sampling frequency
70MHz analog input stage bandwidth
9MΩ /10pF input impedance
+/-20V input range
AC/DC coupling
10 bits Analog to Digital converter
0.8mV to 40mV/LSB resolution
Input protection up to +-200V
Up to 16KSa buffer depth
Advanced triggering(edge, pulse, transition types and
hysteresis, holdoff parameters)
Channels filtering: average, decimate, min/max
FFT, XY, and Histogram functions
Recording and audio functions
Advanced data measurements for each channel and global
measurements
Export data and waveform options
Logic Analyzer
• 32 digital pins
(shared with Digital Signal Generator and Static I/O)
• 100MSa/sec
• Internal/External clock
• Up to 16KSa per pin buffer depth
• Trigger options
• Save signals values option
• Customized visualization for each signal or bus
• Tabular data visualization
Digital signal generator
•
•
•
•
•
•
•
Arbitrary waveform generator
•
•
•
•
•
•
•
100MSa/sec
32 digital pins (shared with Logic Analyzer and Static I/O)
Algorithmic pattern generator (no memory buffers used)
Custom pattern editor in up to 16KSa per pin buffer depth
Import data from files options
Customized visualization for each signal or bus
Tabular data visualization for custom signal types only
2 channels, 40MSa/sec
4 MHz bandwidth
10V amplitude with +/-10 V offset
Open loop impedance 35Ω
14 bits Digital to Analog converter
Standard and user defined waveforms
2KSa buffer depth for carrier and up to 32KSa buffer depth for
the modulator signal
• AM/FM modulation with frequencies of up to 4MHz
• Swept and damped waveforms
• Import data options
Static I/O
• 32 digital pins
(shared with Logic Analyzer and Digital Signal Generator)
• PC-based virtual I/O devices including push buttons, LEDs,
switches, seven segments displays, sliders, progress bars
• Customized visualization
General
•
•
•
•
•
•
Power supplies and voltmeters
• V+ and V- programmable voltage/current supplies of up to
+/-9V and up to 1.5 A
• fixed 5V/3.3V supply with up to 2 A
• 4 voltmeters with +/-10V inputs
• Input impedance 1.2MΩ
• Voltmeter input protection up to +-200V
• Two reference voltages with +/-10V
• Auto scale and plot functions for each supply(voltage, current
and power) and voltmeter
• Save data and waveform options
Large breadboard for design implementation
High-speed USB2 interface for fast data transfer
4 external trigger sources (used by any instrument)
Possibility to reallocate resources according to the user needs
External Power Supply DC 12V 2A
Dimension 198 mm x 160 mm
