AS85049/79
90° EMI/RFI Environmental Backshell
CONNECTOR DESIGNATOR:
Finish
X
= Aluminum, Nickel Flurocarbon Polymer
Z
= Aluminum, Zinc-Nickel, Black
H
MIL-DTL-38999, Series III and IV
EN3645
N
= Electroless Nickel
W
= 1,000 Hr. Cadmium Olive Drab
over Electroless Nickel
M85049/79
-
10
TABLE I: Shell Size,
Thread and Dimensions
Shell
Size
09
11
13
15
17
19
21
23
25
A Thread
Class 2B
M12 X 1 - 6H
M15 X 1 - 6H
M18 X 1 - 6H
M22 X 1 - 6H
M25 X 1 - 6H
M28 X 1 - 6H
M31 X 1 - 6H
M34 X 1 - 6H
M37 X 1 - 6H
B Dia
Max
.750 (19.1)
.850 (21.6)
1.000 (25.4)
1.150 (29.2)
1.250 (31.8)
1.400 (35.6)
1.550 (39.4)
1.650 (41.9)
1.850 (47.0)
Basic
Part Number
Shell Size
(Tables I & II)
W
01
Clamp Size
(Tables II & III)
B
TABLE II: Shell Size,
Clamp Size and Dimensions
Shell
Size
09
11
13
15
17
19
21
23
25
Clamp Size
Min Max
01
01
02
02
02
03
03
03
04
02
03
04
05
06
07
08
09
10
F
±.156 (4.0)
.532
.627
.642
.719
.774
.854
.899
1.009
1.024
(13.5)
(15.9)
(16.3)
(18.3)
(19.7)
(21.7)
(22.8)
(25.6)
(26.0)
G
±.188 (4.8)
3.267
3.387
3.407
3.477
3.567
3.737
3.737
3.847
3.847
(83.0)
(86.0)
(86.5)
(88.3)
(90.6)
(94.9)
(94.9)
(97.7)
(97.7)
Clamp
Size
01
02
03
04
05
06
07
08
09
10
TABLE III: Clamp Size,
Cable Range and Dimensions
Cable Range
Min
Max
.062
.125
.250
.375
.500
.625
.750
.875
1.000
1.125
(1.6)
(3.2)
(6.4)
(9.5)
(12.7)
(15.9)
(19.1)
(22.2)
(25.4)
(28.6)
.125
.250
.375
.500
.625
.750
.875
1.000
1.125
1.250
(3.2)
(6.4)
(9.5)
(12.7)
(15.9)
(19.1)
(22.2)
(25.4)
(28.6)
(31.8)
H
Max
.800
1.000
1.100
1.200
1.250
1.400
1.500
1.650
1.750
1.900
(20.3)
(25.4)
(27.9)
(30.5)
(31.8)
(35.6)
(38.1)
(41.9)
(44.5)
(48.3)
APPLICATION NOTES
1.
2.
3.
For complete dimensions
see the applicable Military
Specification.
Metric dimensions (mm) are in
parentheses.
Cable Range is defined as
the accommodation range
for the wire bundle or cable.
Dimensions shown are not
intended for inspection criteria.
© 2013 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
B-93
E-Mail: sales@glenair.com
AS85049
