NT
Features
■
■
■
■
■
Applications
■
■
■
■
Formerly
model
Current rating up to 2.4 A
Inductance range: 10 µH to 10,000 µH
High Q
Shielded construction
■
RoHS compliant*
DC/DC converters
Power supplies
Desktop notebooks
Output chokes
*R
oH
S
CO
M
PL
IA
Electrical Specifications (@ 25 °C)
Test Frequency
Part
Inductance
Number
(µH)
RL875S-100L-RC
10
RL875S-220L-RC
22
RL875S-270L-RC
27
RL875S-330L-RC
33
RL875S-390L-RC
39
RL875S-470L-RC
47
RL875S-560K-RC
56
RL875S-680K-RC
68
RL875S-820K-RC
82
RL875S-101K-RC
100
RL875S-121K-RC
120
RL875S-151K-RC
150
RL875S-181K-RC
180
RL875S-221K-RC
220
RL875S-271K-RC
270
RL875S-331K-RC
330
RL875S-391K-RC
390
RL875S-471K-RC
470
RL875S-561K-RC
560
RL875S-681K-RC
680
RL875S-821K-RC
820
RL875S-102K-RC
1,000
RL875S-122K-RC
1,200
RL875S-152K-RC
1,500
RL875S-182K-RC
1,800
RL875S-222K-RC
2,200
RL875S-272K-RC
2,700
RL875S-332K-RC
3,300
RL875S-392K-RC
3,900
RL875S-472K-RC
4,700
RL875S-562K-RC
5,600
RL875S-682K-RC
6,800
RL875S-822K-RC
8,200
RL875S-103K-RC
10,000
Q
Tol. (Ref.)
L
Q
±15 %
60
2.52 MHz 2.52 MHz
±15 %
35
2.52 MHz 2.52 MHz
±15 %
35
2.52 MHz 2.52 MHz
±15 %
35
2.52 MHz 2.52 MHz
±15 %
30
2.52 MHz 2.52 MHz
±15 %
30
2.52 MHz 2.52 MHz
±10 %
30
2.52 MHz 2.52 MHz
±10 %
28
2.52 MHz 2.52 MHz
±10 %
28
2.52 MHz 2.52 MHz
±10 %
35
1 KHz
796 KHz
±10 %
45
1 KHz
796 KHz
±10 %
50
1 KHz
796 KHz
±10 %
50
1 KHz
796 KHz
±10 %
60
1 KHz
796 KHz
±10 %
40
1 KHz
796 KHz
±10 %
30
1 KHz
796 KHz
±10 %
50
1 KHz
796 KHz
±10 %
45
1 KHz
796 KHz
±10 %
45
1 KHz
796 KHz
±10 %
45
1 KHz
796 KHz
±10 %
45
1 KHz
796 KHz
±10 %
95
1 KHz
252 KHz
±10 % 110
1 KHz
252 KHz
±10 % 110
1 KHz
252 KHz
±10 % 110
1 KHz
252 KHz
±10 % 110
1 KHz
252 KHz
±10 %
95
1 KHz
252 KHz
±10 %
95
1 KHz
252 KHz
±10 %
95
1 KHz
252 KHz
±10 %
95
1 KHz
252 KHz
±10 %
95
1 KHz
252 KHz
±10 %
95
1 KHz
252 KHz
±10 %
85
1 KHz
252 KHz
±10 %
85
1 KHz
79.6 KHz
SRF
(MHz)
Typ.
25.0
15.0
14.0
13.5
11.0
12.0
12.0
10.5
9.0
6.5
6.0
6.0
5.5
5.5
4.0
4.0
3.5
2.5
2.5
2.0
2.0
2.0
1.5
1.5
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
DCR
(Ω)
Max.
0.06
0.08
0.10
0.14
0.15
0.17
0.19
0.21
0.27
0.32
0.36
0.51
0.57
0.76
0.86
0.97
1.28
1.44
1.61
2.07
2.33
2.72
3.98
4.50
6.81
7.56
8.54
9.74
12.9
14.7
20.4
23.0
30.6
35.0
I dc
(mA)
2400
1600
1490
1300
1200
1100
990
890
810
740
670
600
550
500
450
410
370
340
310
280
260
230
210
190
170
160
140
130
120
110
99
89
81
74
0
22
RL875S - 102K - RC
RL875S Series - Radial Lead RF Choke
General Specifications
Rated Current .....Inductance drop 10 %,
or temperature rise of 40 °C at I dc
Operating Temperature
................................-40 °C to +105 °C
Storage Temperature
................................-40 °C to +105 °C
Materials
Core Material ................................Ferrite
Wire ...........................Enameled copper
Terminal Coating.................................Sn
Marking
............. Value code on top of inductor
Packaging
Standard ...................... 100 pcs. per bag
Product Dimensions
7.8 ± 0.5
(.307 ± .020)
7.5
(.295)
MAX.
5.0
(.197)
0.7
(.028)
DIA.
5.0 ± 0.3
(.197 ± .012)
How To Order
Electrical Schematic
Model
Value/Tolerance Code (see table)
Compliance Code
RC = RoHS Compliant
Example:
RL875S-102K-RC = 1000 µH, ±10 %
DIMENSIONS:
MM
(INCHES)
REV. 03/12
* RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
