Preview

591-2301-113F: DescriptionLED Circuit Board Indicators Green 570nm 4mcd; CategoryLED optoelectronic/LED photoelectric; File Size132KB，1 Pages; ManufacturerDIALIGHT; Websitehttps://www.dialight.com; Environmental Compliance

Download Datasheet Parametric Compare View All

591-2301-113F Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	591-2301-113F	-	-	View	Buy Now

591-2301-113F Overview

LED Circuit Board Indicators Green 570nm 4mcd

591-2301-113F Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	DIALIGHT
package instruction	ROHS COMPLIANT PACKAGE-2
Reach Compliance Code	compliant
Is Samacsys	N
Other features	SUPPORTS INFRARED
color	GREEN
color@wavelength	Green
Configuration	SINGLE
Maximum forward current	0.03 A
Maximum forward voltage	2.6 V
JESD-609 code	e2
Nominal luminous intensity	10.6 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	5.03 mm
method of packing	TAPE AND REEL 13"
peak wavelength	572 nm
shape	RECTANGULAR
size	2.717 mm
surface mount	YES
Terminal surface	Tin/Silver/Nickel (Sn/Ag/Ni)
Terminal pitch	3.2 mm
perspective	40 deg
Base Number Matches	1

Preview

Download Datasheet

View All

591-2301-113F Related Products

	591-2301-113F	591-3101-113F	591-3501-832F	591-3501-113F	591-2001-113F
Description	LED Circuit Board Indicators Green 570nm 4mcd	LED Circuit Board Indicators Yel/Green 590/570nm mcd	LED Circuit Board Indicators RGB CBI LED 7" REEL 626/525/470nm	LED Circuit Board Indicators RGB 645/570/466nm	LED Circuit Board Indicators Red 628nm 5mcd
Is it lead-free?	Lead free	Lead free	Lead free	-	Lead free
Is it Rohs certified?	conform to	conform to	conform to	-	conform to
Maker	DIALIGHT	-	DIALIGHT	-	DIALIGHT
package instruction	ROHS COMPLIANT PACKAGE-2	ROHS COMPLIANT PACKAGE-4	ROHS COMPLIANT PACKAGE-4	-	ROHS COMPLIANT PACKAGE-2
Reach Compliance Code	compliant	compliant	compliant	-	compliant
color	GREEN	YELLOW/GREEN	RED/GREEN/BLUE	-	HIGH EFFICIENCY RED
color@wavelength	Green	Green/Yellow	-	-	Orange-Red
Configuration	SINGLE	2 BANKS, COMMON BIPOLAR TERMINAL, 2 ELEMENTS	COMMON ANODE, 3 ELEMENTS	-	SINGLE
Maximum forward current	0.03 A	0.03 A	0.03 A	-	0.03 A
Maximum forward voltage	2.6 V	2.6 V	-	-	2.6 V
JESD-609 code	e2	e2	e3	-	e2
Nominal luminous intensity	10.6 mcd	11.3 mcd	60.0/150.0/30.0 mcd	-	9.8 mcd
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	-	SURFACE MOUNT
Number of functions	1	2	1	-	1
Number of terminals	2	4	4	-	2
Maximum operating temperature	100 °C	100 °C	100 °C	-	100 °C
Minimum operating temperature	-40 °C	-40 °C	-55 °C	-	-40 °C
Optoelectronic device types	SINGLE COLOR LED	DUAL COLOR LED	TRIPLE COLOR LED	-	SINGLE COLOR LED
total height	5.03 mm	5.0292 mm	5.03 mm	-	5.03 mm
method of packing	TAPE AND REEL 13"	TAPE AND REEL 13\"	TAPE AND REEL 7\"	-	TAPE AND REEL 13"
peak wavelength	572 nm	586/572 nm	635/523/468 nm	-	635 nm
shape	RECTANGULAR	RECTANGULAR	ROUND	-	RECTANGULAR
size	2.717 mm	-	2.85 mm	-	2.717 mm
surface mount	YES	YES	YES	-	YES
Terminal surface	Tin/Silver/Nickel (Sn/Ag/Ni)	Tin/Silver/Nickel (Sn/Ag/Ni)	Tin (Sn)	-	Tin/Silver/Nickel (Sn/Ag/Ni)
Terminal pitch	3.2 mm	0.5 mm	-	-	3.2 mm
perspective	40 deg	40 deg	40 deg	-	40 deg
Base Number Matches	1	1	-	-	1
