For 1/2” Mounting Hole
.639
(16.23)
1.369
(34.77)
1.677
(42.6)
1.769
(44.93)
2.10 MAX
(53.3)
M
IN
Electrical specifications
Operating Voltage:
Operating Temp:
Storage Temp:
.650
(16.51)
6.00
(152.4)
EL
I
.639
(16.23)
1.369
(34.77)
1.677
(42.6)
1.769
(44.93)
2.350 MAX
(59.69)
Dimensions in inches [mm]
PR
•
UL1598
•
NEMA 4x IP66
•
RoHS Compliant - w/6C Exemption
Certifications & Ratings
Features and Benefits
•
Long life – typically 100K hours
•
Daylight viewable
•
Tamperproof/Designed for high durability
•
Available in red, yellow, green, and blue
•
Low profile flat (viewing angle: 50)
•
Wide angle domed (viewing angle: TBD)
www.dialight.com
•
Dialight HQ (P) 732-919-3119
AR
Mechanical Information
Mounting Hole Size:
0.5” (12.7mm)
Max Panel Thickness:
Mounting Torque:
.600” (15.24 mm)
40 in-lbs torque
12 to 125VDC and 125, 230VAC
-30°C to +85°C
-40°C to +100°C
110 Faston Quick connect terminals or 6”
wire leads
Electrical connection:
Construction
Housing:
Nickel Plated Brass
Transparent Polycarbonate (UL 94V-0)
Tin over Brass
18 AWG
Phosphor Bronze – White Nickel Plated
Brass – White Nickel Plated
Lens Material:
Terminals:
Wire leads:
Lock washer:
Nut:
656 Series
High Intensity LED
Panel Mount Indicators
...and many more!
Y
Application:
The 656 Series ½” LED Panel Mount Indictors incorporate both In-
GaN and AllnGap technologies to offer super bright intensities in a
full range of colors and voltages. This is a highly durable package,
designed to withstand outdoor applications susceptible to rain,
dust and sunlight.
•
Instrument panels
•
Safety applications
•
UL 508 panel Applications
•
Power Generation
•
Transportation – rail, bus, airline
High Intensity LED
•
Panel Mount Indicators
For 1/2” Mounting Hole
656 Series
3 = 6" WIRE LEAD (18 AWG)
LED Code
Connectors
4 = BLADE TERMINALS (110
FASTON QUICK CONNECTS)
LED Code
1103
1203
1303
1403
1104
1204
1304
1404
1106
1206
1306
1406
1105
1205
1305
1405
Lens Style*
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Flat
Color
RED
GREEN
YELLOW
BLUE
RED
AR
Voltage
12
12
12
12
Voltage Type
VDC
VDC
VDC
VDC
24
24
24
24
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC/AC
VDC/AC
VDC/AC
VDC/AC
VAC
VAC
VAC
VAC
28
28
28
28
120
120
120
120
230
230
230
230
M
IN
GREEN
BLUE
RED
YELLOW
GREEN
BLUE
RED
YELLOW
GREEN
BLUE
RED
YELLOW
GREEN
BLUE
YELLOW
EL
I
1109
Flat
1209
Flat
1309
Flat
1409
Flat
*For domed lens style: replace the 1st digit with “3”. For example:
3103
PR
Dialight reserves the right to make changes at any time in order to supply the best product possible. The most current version of this document will always be available at:
www.dialight.com/Assets/Brochures_And_Catalogs/Illumination/M D EL6 5 6 HI PM I .pdf. Warranty Statement: EXCEPT FOR THE WARRANTY EXPRESSLY PROVIDED FOR [HEREIN/ABOVE/BELOW], DIALIGHT DISCLAIMS
ANY AND ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND NON-INFRINGEMENT.
www.dialight.com
•
Dialight HQ (P) 732-919-3119
Y
Current (MA)
18
16
18
16
20
20
20
20
19
18
19
18
5
5
5
5
3
3
3
3
M D E L 65 6HI PM I _ B
656-
XXXX -
3
0
X
F
Connectors
