XStream™ OEM RF Module
Product Manual
v5.x00
For XStream OEM RF Module Part Numbers:
X09-001…
X09-009…
X09-019…
X24-009…
X24-019…
XH9-001…
XH9-009…
XH9-019…
Reliable 900 MHz and 2.4 GHz OEM RF Modules by Digi International Inc.
XStream™ OEM RF Module – Product Manual v5.x00
XStream OEM RF Module – Product Manual v5.x00
(Part number 90002209 B)
Revision
B
Date
10/15/14
Description
Minor changes and new part number
© 2014 Digi International Inc. All rights reserved
Digi, Digi International, the Digi logo, and XStream
®
are
trademarks or registered trademarks of Digi International Inc.
in the United States and other countries worldwide. All other
trademarks mentioned in this document are the property of
their respective owners.
Information in this document is subject to change without
notice and does not represent a commitment on the part of
Digi International. Digi provides this document “as is,”
without warranty of any kind, expressed or implied,
including, but not limited to, the implied warranties of fitness
or merchantability for a particular purpose. Digi may make
improvements and/or changes in this manual or in the
product(s) and/or the program(s) described in this manual at
any time.
© 2014 Digi International Inc.
ii
XStream™ OEM RF Module – Product Manual v5.x00
Contents
IC (Industry Canada) Certification
53
1.
XStream OEM RF Module
1.1.
1.2.
1.3.
1.4.
1.5.
Features
Worldwide Acceptance
Specifications
Mechanical Drawings
Pin Signals
Electrical Characteristics
Timing Specifications
1.1.1.
4
4
5
5
6
6
8
8
Appendix B: Development Guide
XStream OEM Development Kit Contents
Interfacing Hardware
Adapters
Antennas
Interfacing Protocols
RS-232 Operation
RS-485 (2-wire) Operation
RS-485 (4-wire) and RS-422 Operation
XCTU Software
Using the XCTU Software
54
54
54
58
59
60
60
62
63
65
65
1.5.1.
2.
RF Module Operation
2.1.
Serial Communications
UART-Interfaced Data Flow
Flow Control
Idle Mode
Transmit Mode
Receive Mode
Sleep Mode
Command Mode
2.1.1.
2.1.2.
2.2.
2.2.1.
2.2.2.
2.2.3.
2.2.4.
2.2.5.
10
10
10
11
12
12
12
14
14
17
Appendix C: Additional Information
1-Year Warranty
Ordering Information
Contact Digi
66
66
66
67
Modes of Operation
3.
RF Module Configuration
3.1.
Hands-on Programming Examples
AT Command Example
Binary Command Example
3.1.1.
3.1.3.
3.2.
3.3.
19
19
19
20
21
22
Command Reference Table
XStream Command Descriptions
4.
RF Communication Modes
4.1.
4.2.
Addressing
Address Recognition
Streaming Mode (Default)
Repeater Mode
Acknowledged Mode
Multi-Streaming Mode
Basic Communications
4.1.1.
4.2.1.
4.2.2.
4.3.
4.3.1.
4.3.2.
37
38
38
39
39
40
44
44
46
Acknowledged Communications
Appendix A: Agency Certifications
FCC Certification
OEM Labeling Requirements
Antenna Usage
FCC-Approved Antennas
50
50
51
51
52
© 2014 Digi International Inc.
iii
XStream™ OEM RF Module – Product Manual v5.x00
1. XStream OEM RF Module
The XStream OEM RF Module is a drop-in wireless data solution that
transfers a standard asynchronous serial data stream over-the-air
between devices. The module was engineered to provide OEMs and
integrators with an easy-to-use wireless solution that yields reliable,
long range and low cost wireless links.
1.1.
Features
Long Range
9XStream (900 MHz) Range:
•
Indoor/Urban: up to 1500’ (450 m)
•
Outdoor line-of-sight: up to 7 miles (11 km)
w/ 2.1 dBm dipole antenna
•
Outdoor line-of-sight: up to 20 miles (32 km)
w/ high gain antenna
24XStream (2.4 GHz) Range:
•
Indoor/Urban: up to 600’ (180 m)
•
Outdoor line-of-sight: up to 3 miles (5 km)
w/ 2.1 dBm dipole antenna
•
Outdoor line-of-sight: up to 10 miles (16 km)
w/ high gain antenna
Receiver Sensitivity: -110 dBm (900 MHz),
-105 dBm (2.4 GHz)
Advanced Networking and Security
True peer-to-peer (no “master” required), point-
to-point, point-to-multipoint, multidrop
Retries and Acknowledgements
7 hopping channels, each with over 65,000
available network addresses
FHSS (Frequency Hopping Spread Spectrum)
Fast network synchronization (~ 35 ms)
Streaming, Repeater, Multi-Streaming and
Acknowledged Modes supported
Easy-to-Use
No configuration required
Advanced configurations supported
through standard AT and binary
Commands
5 VDC (± 0.25 V) power supply
Continuous RF data stream
up to 19.2 kbps
Portable (small form factor easily
designed into a wide range of data radio
systems)
Software-selectable serial interfacing
rates
MODBUS, CTS, RTS, DTR, DCD (and
more) I/O Support
Support for multiple data formats (parity,
start and stop bits, etc.)
XII™ Interference Immunity
Power-saving Sleep Modes
© 2014 Digi International Inc.
4
XStream™ OEM RF Module – Product Manual v5.x00
1.1.1.
Worldwide Acceptance
FCC Certified
(USA) – Refer to Appendix A for FCC Requirements.
Systems that include XStream Modules automatically inherit Digi Certifications
ISM
(Industrial, Scientific and Medical) frequency band
Manufactured under
ISO 9001:2000 registered standards
9XStream (900 MHz) OEM RF Modules are approved for use in
US, Canada, Australia,
Israel.
1.2.
Table 1‐01.
Specifications
XStream OEM RF Module Specifications
Specification
Performance
Indoor/Urban Range
Outdoor line-of-sight Range
Interface Data Rate
Throughput Data Rate
RF Data Rate
Transmit Power Output
Receiver Sensitivity
Power Requirements
Supply Voltage
Receive Current
Transmit Current
Power Down Current
General
Frequency Range
Spread Spectrum
Network Topology
Channel Capacity
Serial Data Interface
Physical Properties
Module Board Size
Weight
Connector
Operating Temperature
Antenna
Integrated Wire (optional)
Connector (optional)
Impedance
9XStream (900 MHz) OEM RF Module
up to 1500’ (450 m)
Up to 7 miles (11 km) w/ dipole antenna
Up to 20 miles (32 km) w/ high-gain antenna
1200 – 57,600 bps
(non-standard baud rates also supported)
9,600 bps
10,000 bps
100 mW (20 dBm)
-110 dBm
19,200 bps
20,000 bps
100 mW (20 dBm)
-107 dBm
24XStream (2.4 GHz) OEM RF Module
up to 600’ (180 m)
Up to 3 miles (5 km) w/ dipole antenna
Up to 10 miles (16 km) w/ high-gain antenna
1200 – 57,600 bps
(non-standard baud rates also supported)
9,600 bps
10,000 bps
50 mW (17 dBm)
-105 dBm
19,200 bps
20,000 bps
50 mW (17 dBm)
-102 dBm
5 VDC (± 0.25 V) regulated
50 mA
140 mA
< 26 µA
902-928 MHz
5 VDC (± 0.25 V) regulated
80 mA
150 mA
< 26 µA
2.4000-2.4835 GHz
Frequency Hopping, Wide band FM modulator
Peer-to-Peer, Point-to-Multipoint, Point-to-Point, Multidrop
7 hop sequences share 25 frequencies
CMOS UART
1.600” x 2.825” x 0.350” (4.06 cm x 7.18 cm x 0.89 cm)
0.8 oz (24 g)
11-pin and 4-pin, 0.1” spaced male Berg-type headers
0 to 70º C (commercial), -40 to 85º C (industrial)
¼ wave monopole, 3” (7.62 cm) length, 1.9 dBi Gain
Reverse-polarity SMA or MMCX
50 ohms unbalanced
OUR-24XSTREAM
4214A 12008
Certifications (visit
www.digi.com
for complete list)
FCC Part 15.247
OUR9XSTREAM
Industry Canada (IC)
4214A-9XSTREAM
© 2014 Digi International Inc.
5
