Z8 Encore! XP
®
4K Series Development Kit
Z8 Encore! XP
®
4K Series MCU Development Kit Contents
8-Pin Development Kit
20, 28-Pin Development Kit
Hardware
• Z8 Encore! XP
®
4K Series Development Board
• Serial or USB Smart Cable
• 5 V DC Universal Power Supply
Software
• ZDS II Integrated Development Environment (IDE)
• ANSI C-Compiler
• Sample Code
Documentation/CD-ROM
• Development Kit Quick Start Guide
• Development Kit User Manual
• ZDS II - IDE User Manual
• eZ8 CPU User Manual
• Product Specifications
• Product Briefs
• Application Notes
Development Board Features
• Z8 Encore! XP
®
4K MCU
• Three LEDs
• RS-232 interface
• IrDA transceiver
• Two Push Buttons, RESET and TEST
• 5 V DC power connector
• On-chip debugger interface
• Header for ADC input (not present on 8-pin board)
• Prototyping area
• External interface connectors
• 2.7 to 3.6 V operating range with 5 V tolerant inputs
OVERVIEW
Evaluate. Design. Build. That's the simple power behind the
value of the ZiLOG Z8 Encore! XP
®
4K Series Development Kit.
Our complete development platform includes all the hardware
and software you need to cut design time and get your prod-
ucts to market faster.
These new kits feature the Z8 Encore! XP
®
4K Series Flash
MCU, with new features such as a full range temperature
sensor and a transimpedance amplifier which have their
outputs processed by an enhanced sigma-delta analog to
digital converter. The Z8 Encore! XP
®
4K Series Flash MCU is
perfect for applications such as motor control, security systems,
systems monitoring, personal electronic devices, home appli-
ances, home automation, and sensor monitoring.
Use the Z8 Encore! XP
®
4K Series Development Kits both to
evaluate our new MCU and create your Z8 Encore! XP
®
4K
Series MCU product solution. You get everything you need to
go from concept to design - there's nothing else to buy.
Discover the value and power ZiLOG brings to your next 8-bit
MCU design. Order a Z8 Encore! XP
®
4K Series Development
Kit today!
Z8 Encore! XP
®
4K Series Development Kit
C-Compiler
A full version ANSI C compiler is included in this kit at no addi-
tional cost allowing you to begin your design immediately. The
C-Compiler supports a powerful configurable optimizer allow-
ing code to be optimized for speed or size.
Smart Cable
This small circuit board provides reliable and robust communi-
cation between your desktop PC and the development board.
Use it for your development board and again with your final
product's hardware.
Serial Smart Cable
converts RS-232 signals to communicate
with the on-chip debugger of the eZ8 core.
P/N: Z8ENCORE000ZAC
Z8 Encore!
®
MCU ZDS II IDE GUI
ZiLOG Developer Studio II Integrated Development Environ-
ment is a complete suite of software tools that supports devel-
opment with the Z8 Encore!
®
MCU. Its easy-to-use Windows-
based GUI provides an environment that accelerates the edit,
compile, and debug cycle. Included in ZDS II are a language
sensitive editor, project manager, compiler, assembler, linker,
librarian, and debugger.
USB Smart Cable
is compatible with both USB highspeed and
full-speed standards and converts the signals sent from the USB
port on your development PC to communicate with the on-chip
debugger.
P/N: ZUSBSC00100ZACG (RoHS)
P/N: ZUSBOPTSC01ZACG (RoHS)
16-Bit Timers
Speed (MHz)
Device
UART
Memory
Flash
(Bytes)
4K
4K
2K
2K
1K
1K
NVDS
(Bytes)
128
128
64
64
16
16
SRAM
(Bytes)
1K
1K
512
512
256
256
Comparator
10-Bit A/D
Channels
I/O Lines
Other Features
Operating
Voltage
Temp.
Range
(º C)
Pin
Count
Development Kit
Z8F042A
Z8F041A
Z8F022A
Z8F021A
Z8F012A
Z8F011A
20
20
20
20
20
20
23
25
23
25
23
25
2
2
2
2
2
2
8
-
8
-
8
-
1
1
1
1
1
1
1
1
1
1
1
1
Temp. Sensor, Int
Prec. Oscillator
Temp. Sensor, Int
Prec. Oscillator
Temp. Sensor, Int
Prec. Oscillator
Temp. Sensor, Int
Prec. Oscillator
Temp. Sensor, Int
Prec. Oscillator
Temp. Sensor, Int
Prec. Oscillator
2.7 - 3.6 V
2.7 - 3.6 V
2.7 - 3.6 V
2.7 - 3.6 V
2.7 - 3.6 V
2.7 - 3.6 V
-40º to 125º
-40º to 125º
-40º to 125º
-40º to 125º
-40º to 125º
-40º to 125º
28, 20, 8
28, 20, 8
28, 20, 8
28, 20, 8
28, 20, 8
28, 20, 8
Z8F04A28100KITG
Z8F04A08100KITG
Z8F04A28100KITG
Z8F04A08100KITG
Z8F04A28100KITG
Z8F04A08100KITG
Z8F04A28100KITG
Z8F04A08100KITG
Z8F04A28100KITG
Z8F04A08100KITG
Z8F04A28100KITG
Z8F04A08100KITG
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
Order your ZiLOG Development Kits at
http://www.zilog.com
to get your applications to
market in recored time.
Z8 Encore! XP
®
is a registered trademarks of ZiLOG, Inc. in the United States and in the other countries. FL006005-0607
