17-101924: DescriptionEthernet Cables / Networking Cables RJ45-IP67 ZnDc By TO IP20 M Ct5e STPOD 2M; CategoryThe connector Connector bracket; File Size234KB，1 Pages; ManufacturerCONEC; Websitehttp://www.conec.com

Download Datasheet Parametric View All

17-101924 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	17-101924	-	-	View	Buy Now

17-101924 Overview

Ethernet Cables / Networking Cables RJ45-IP67 ZnDc By TO IP20 M Ct5e STPOD 2M

17-101924 Parametric

Parameter Name	Attribute value
Maker	CONEC
Reach Compliance Code	compliant
Connector bracket type	CABLE ASSEMBLY

Preview

Download Datasheet

View All

± 0.05m

Cat. 5e RJ45 Plug

(Standard)

Cat. 5e RJ45 Plug

Industrial IP67

Die-Cast Version

Bayonet Locking Type

Notes:

Cable

Length

Part Number

Cat. 5e Outdoor STP 4 Pair, Cat. 5e Outdoor UTP 4 Pair,

AWG24 Solid Black Cable

Cat. 5e STP 4 Pair,

AWG24 Solid Black Cable

Cat. 5e UTP 4 Pair,

AWG24 Solid Black Cable

1. Electrical Specifications:

- Meets EIA/TIA-568-B.2 Cat.5e Specification

THIS DRAWING MAY NOT BE COPIED OR REPRODUCED

IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD

PARTY WITHOUT WRITTEN PERMISSION.

OWNERSHIP AND COPYRIGHT OF CONEC CORPORATION

DOT NOT ALTER CAD DRAWING BY HAND

- Connector Operating Temperature: -40

C to +85

17-101934

17-101964

17-102024

17-101994

2. Materials and Finish:

17-101944

17-101974

- Coupling Ring: Zin Die-Cast, Nickel Plated

17-102004

17-102034

- Plug Housing: Zin Die-Cast, Nickel Plated

Note: Special cable length are available please contact factory; SPT: Shielded Twisted Pair; UTP: Unshielded Twisted Pair

- Interfacial Seal: Silicone, Color: White

- Cable Gland: Brass, Nickel Plated

Customer:

Tolerance

Unless otherwise specified

Scale:

Dim. in meter

- Cable Gland Seal: NBR, Color: Black

Approval Date

Name

Title

Autodesk

Material: See Notes

- RJ45 Plug Metal Shell: Copper Alloy, Nickel Plated

Inventor

- RJ45 Plug Plastic Housing: Clear Polycarbonate UL94 V-2

Name

2010

Date

RJ45 Cat. 5e Ethernet Patch Cord

Draw.

Jan. 28

Vincent Ke

- RJ45 Plug Contacts: Phosphor Bronze, Finish: 50 u" Gold min. over Nickel

Industrial to Standard

Appd.

J. Chaudry

Jan. 28

- Cable: See Part Number Table

Nickel Plated Zinc Die-Cast Version

Norm

DIN

1 x c Sep/22/2011 Vincent Ke

D-old

3. IP67 rated on IP67 side when fully mated with the appropriate mating connector

Drawing No.: 17K1A153

Dimensional:

Angles

17-101924

17-101954

17-101984

17-102014

Directive 2002/95/EC RoHS Compliant

2 x b May/28/2010 Vincent ke

original

Date

Name

Rev.

Changes

Part No.: SEE P/N ABOVE

Sheet

1/1
