IMC-0603-01
Vishay Dale
Wirewound, Surface Mount Inductors
FEATURES
• Excellent solderability and resistance to
soldering heat
• Suitable for reflow soldering
• High reliability and easy surface mount
assembly
• Wide range of inductance values available
• Tape and reel packaging for automatic
handling, 3000/reel EIA 481
• Compliant to RoHS Directive 2002/95/EC
STANDARD ELECTRICAL SPECIFICATIONS
TEST
FREQ.
(MHz)
TOL.
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
10 %, 5 %
10 %, 5 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
L&Q
250
250
250
250
250
250
250
250
250
250
250
250
250
200
200
200
150
150
150
150
150
100
100
100
SRF DCR RATED DC
Q
MIN. MAX. CURRENT
MIN. (MHz) ()
(mA)
(1)
16
20
20
30
30
30
35
35
38
38
40
43
43
40
40
40
35
35
35
35
35
30
30
30
6900
6900
5800
5800
4600
4800
4000
4000
3100
3000
2800
2300
2200
2000
1900
1700
1700
1700
1400
1300
1000
1000
1000
1000
0.08
0.08
0.11
0.11
0.10
0.13
0.13
0.17
0.17
0.22
0.22
0.22
0.25
0.28
0.31
0.34
0.49
0.54
0.63
0.65
0.92
1.25
1.70
1.80
700
700
700
700
700
700
700
700
700
700
600
600
600
600
600
600
400
400
400
300
280
240
200
170
IND.
(nH)
2.0
3.9
4.7
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
72
82
100
120
150
180
220
270
ELECTRICAL SPECIFICATIONS
Inductance Range:
2 nH to 270 nH
Operating Temperature:
- 40 °C to + 125 °C
Storage Temperature:
- 40 °C to + 125 °C
TEST EQUIPMENT
• Inductance is measured in HP4287A RF LCR meter with
HP16193 fixture
• Q is measured in HP4287A RF LCR meter with HP16193
fixture
• SRF is measured in HP8753E RF network analyzer
• DCR ismeasured in HP4338B millohmeter
DIMENSIONS
in inches [millimeters]
0.063 ± 0.008
[1.60 ± 0.2]
0.041 ± 0.008
[1.05 ± 0.2]
0.014 ± 0.004
[0.35 ± 0.1]
Note
(1)
Value obtained when current flows and temperature has risen 15 °C
0.02 ref.
[0.5]
0.041 ± 0.008
[1.05 ± 0.2]
DESRIPTION
IMC-0603-01
MODEL
10 nH
INDUCTANCE VALUE
±5%
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e4
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
M
PRODUCT
FAMILY
C
0
6
SIZE
0
3
E
R
1
0
INDUCTANCE
VALUE
N
J
TOL.
0
1
PACKAGE
CODE
SERIES
