80% Efficiency
•
22 Watts per in
3
•
3.3, 5, 12, 24 and 48 VD
•
1000/3000 VDC Isola
•
Industry Standards Pi
Specification
Input
Input Voltage
•
Input Reflected Noise •
(20 MHz) BW
±10%
100mV pk-pk max
Environmental
Input Output Isolation
Temperature
Coefficient
Operating
Temperature Range
Storage
Temperature Range
•
•
•
•
1000 VDC/ 3000 VD
0.03%/°C max
-40 °C to +85 °C
-55 °C to +125 °C
Output
Output Voltage
•
Accuracy
Output Ripple & Noise •
(20 MHz BW)
Line Regulation
•
Load Regulation
•
(20% to 100% Load)
±5%
100 mV pk-pk max
1.2%/1% of Vin
±10% or ±15% for 3.3 V output model
General
Efficiency
•
At full load 9 V, 12 V & 15 V
outputs 80% typical
At full load 3.3 V & 5 V outputs
70% typical
1 second max
Short Circuit
Protection
•
•
www.XPiQ.com
PH:
FAX:
Email: sa
Holliston, M
Add suffix “S” for single-in-line package, suffix “D” for dual-in-line package.
Add suffix “H” for 3000 VDC isolation.
* Derate output by 50% for 3.3 VDC input models.
•
Mechanical Details
SINGLE-IN-LINE PACKAGE
0.10
0.300
0.045
0.010
max
0.010
0.300
DUAL-IN-LINE PACKAGE
0.20
BOTTOM
0.300
(BOTTOM VIEW)
.500 max
0.500 max
*0.24
max
0.400
max
0.400
max
0.150
max
0.020
*0.27
max
0.15
max
0.020
* 0.30 max for 48VDC input models
0.020
* 0.30 max for 48VDC input models
Pins .0
SINGLE-IN-LINE PACKAGE
DUAL-IN-LINE PACKAGE (TOP VIEW)
0V
7
+V
5
1
GND
2
3
Vcc 0V
4
+V
1
GND
4
Vcc
Derating Curve
www.XPiQ.com
PH:
FAX:
Email: sa
Holliston, M
