ELECTRICAL SOLUTIONS
A.
System
Overview
Pin Terminals, Vinyl Insulated
–
Funnel Entry
Type PV-PB
• Continuously molded design provides reliable, consistent
performance through the applicator for a high quality termination
every time
• Solid pin designed to prevent damage to the wire from over
tightening, resulting in a reliable electrical connection
• For use with pin-type terminal blocks
• Insulation support helps to prevent wire damage in
bending applications
• UL Flammability UL 94V-0, maximum insulation temperature
221°F (105°C)
• UL rated up to 600 V per UL 486A/B
L
W
B1.
Cable Ties
B2.
Cable
Accessories
B3.
Stainless
Steel Ties
P
Max.
Ins.
(In.)
0.150
0.170
Figure Dimensions
(In.)
L
0.90
0.90
W
0.07
0.07
P
0.49
0.49
CA9
Series
Crimp Die
CD9-1A
CD9-2A
CA-800/EZ
Series
Crimp Die
CD-800-1
CD-800-2
Pieces
Per
Reel
3000
3000
C1.
Wiring
Duct
Part Number
PV18-P47B-3K
PV14-P47B-3K
Wire
Range
22 – 18 AWG
16 – 14 AWG
Color
Code
Red
Blue
C2.
Surface
Raceway
For applicator information, see page D1.143.
Male Blade Adapters, Vinyl Insulated
–
Funnel Entry
Type DV-MB
• Continuously molded design provides reliable, consistent
performance through the applicator for a high quality termination
every time
• Flat blade design to prevent damage to the wire from over
tightening, resulting in a reliable electrical connection
• For use with blade-type terminal blocks
• Insulation support helps to prevent wire damage in
bending applications
• UL Flammability UL 94V-0, maximum insulation temperature
221°F (105°C)
• Rated up to 600 V
L
C3.
Abrasion
Protection
C4.
Cable
Management
D1.
Terminals
Y
D2.
Power
Connectors
Part Number
DV18-145MB-3K
DV14-145MB-3K
Wire
Range
22 – 18 AWG
16 – 14 AWG
Color
Code
Red
Blue
Max.
Ins.
(In.)
0.155
0.175
Figure Dimensions
(In.)
L
0.90
0.90
Y
0.42
0.42
Tab
Size
(In.)
0.145 x 0.032
0.145 x 0.032
CA9
Series
Crimp Die
CD9-1A
CD9-2A
CA-800/EZ
Series
Crimp Die
CD-800-1
CD-800-2
Pieces
Per
Reel
3000
3000
D3.
Grounding
Connectors
For applicator information, see page D1.143.
Butt Splices Nylon Insulated and Premium Grade Nylon
E1.
Labeling
Systems
Type BSN, BSP
• Continuously molded design provides reliable, consistent
performance through the applicator for a high quality termination
every time
• Designed to splice two solid or stranded wires together to repair or
lengthen wires
• Butted configuration provides low profile for limited space applications
• Brazed seam protects terminal barrel from splitting during the
crimp process
• Internal wire stop assures proper length of insertion into
terminal barrel
• Premium grade nylon insulation available for applications requiring
a tighter grip around the wire insulation for maximum strain relief
• UL Flammability UL 94V-2/HB, maximum insulation temperature
221°F (105°C)
• UL and CSA rated up to 600 V per UL 486C
L
E2.
Labels
E3.
Pre-Printed
& Write-On
Markers
E4.
Permanent
Identification
E5.
Lockout/
Tagout
& Safety
Solutions
F.
Index
Wire
Part Number
Range
22 – 16 AWG
BSN18-3K
18 – 14 AWG
BSN14-3K
BSN10-2K
12 – 10 AWG
BSP18-3K
22 – 16 AWG
BSP14-3K
18 – 14 AWG
For applicator information, see page D1.143.
Color
Code
Red
Blue
Yellow
Red
Blue
Max.
Ins.
(In.)
0.150
0.170
0.230
0.150
0.170
Figure Dimensions
(In.)
L
0.95
0.95
0.95
0.96
0.96
CA9
Series
Crimp Die
CD9-1A
CD9-2A
CD9-17B
CD9-1A
CD9-2A
CA-800/EZ
Series
Crimp Die
CD-800-1
CD-800-2
CD-800-17
CD-800-1
CD-800-2
Pieces
Per
Reel
3000
3000
2000
3000
3000
D1.130
Order number of pieces required, in multiples of Standard Package Quantity.
Prime items appear in
BOLD.
