PRELIMINARY
SOLID STATE DEVICES, INC.
14005 Stage Road * Santa Fe Springs, Ca 90670
Phone: (562) 404-4474 * Fax: (562) 404-1773
5R1/220
thru
15R1/220
3 AMPS
50-150 VOLTS
EPION
HIGH SPEED
RECTIFIER
TO-220
Designer's Data Sheet
FEATURES:
Optimized for 12V and 15V auxiliary output power supplies. The
EPION series has been designed to provide low forward voltage
drops and small delta shifts in reverse recovery time at high
temperature minimizing switching loses.
• Radiation Tolerant
• Ultra Fast Recovery Time
• Low Forward Voltage
• Low Reverse Leakage
• High Reverse Blocking Voltage
• 175
o
C Operating T
J
Maximum Ratings
Peak Repetitive Reverse and
DC Blocking Voltage
5R
7R
10R
12R
15R
SYMBOL
V
RM(rep)
V
R
VALUE
50
70
100
125
150
3
UNITS
Volts
Half Wave Rectified Forward Current. Averaged Over
Full Cycle
(Resistive load, 60Hz, Sine Wave, T
C
= 55
o
C)
Peak Repetitive Forward Current
(T
C
= 55
o
C, 8.3 ms Pulse, Allow Junction to Reach Equilib-
rium Between Pulses)
Peak Surge Current
(T
C
= 55
o
C, Superimposed on Rated Current at Rated
Voltage, 8.3 ms Pulse)
Operating and Storage Temperature
Maximum Thermal Resistance
Junction to Case
Io
Amps
I
FM(rep)
I
FM(surge)
T
J
& Tstg
R
2JC
4
Amps
12
-65 TO +175
30
Amps
o
C
o
C/W
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0012A
5R1/220
thru
15R1/220
Electrical Characteristics
Reverse Leakage Current
(T
J
= 25
o
C, 300:s pulse minimum V
R
= 150V)
Reverse Leakage Current
(T
J
= 125
o
C, 300:s pulse minimum V
R
= 150V)
Instantaneous Forward Voltage Drop
(T
J
= 25
o
C, 300:sec pulse minimum
I
F
= 3A
I
F
= 10A)
I
nstantaneous Forward Voltage Drop
(T
J
= 125
o
C, 300:sec pulse minimum
I
F
= 3A
I
F
= 10A)
Reverse Recovery Time
(T
A
= 25
o
C, I
F
= 0.5A, I
R
= 1.0A, I
RR
= 0.25A)
Reverse Recovery Time
(T
A
= 150
o
C, I
F
= 0.5A, I
R
= 1.0A, I
RR
= 0.25A)
Junction Capacitance
(V
R
= 10V
DC
, T
A
= 25
o
C, f = 1MHz)
CASE OUTLINE: TO-220
PIN 1: ANODE 1
PIN 2: CATHODE
PIN 3: ANODE 2
PRELIMINARY
SOLID STATE DEVICES, INC.
14005 Stage Road * Santa Fe Springs, Ca 90670
Phone: (562) 404-4474 * Fax: (562) 404-1773
SYMBOL
I
R1
I
R2
I
F1
VALUE
35
130
UNITS
:A
:A
V
DC
V
DC
V
DC
V
DC
nsec
nsec
pF
0.90
1.0
I
F2
T
RR1
T
RR2
C
J
.75
.90
50
65
50
FORWARD VOLTAGE @T
J
= 25
o
C
FORWARD VOLTAGE @T
J
= 125
o
C
10
Forward Current (A)
Forward Current (A)
10
1
0.1
0.01
0.001
0.0001
0.2
1
0.1
0.01
0.001
0.0001
0.3
0.4
0.5 0.6 0.7 0.8
Forward Voltage (V)
0.9
1
0.3
0.4
0.5
0.6
Forward Voltage (V)
0.7
0.8
