1742318 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 1742318

1742318: DescriptionFixed Terminal Blocks MKDS 5/ 5-7,62 GY BD:PA-W; CategoryThe connector; File Size82KB，3 Pages; ManufacturerPHOENIX CONTACT; Websitehttps://www.phoenixcontact.com; Environmental Compliance

Download Datasheet Parametric View All

1742318 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1742318	-	-	View	Buy Now

1742318 Overview

Fixed Terminal Blocks MKDS 5/ 5-7,62 GY BD:PA-W

1742318 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	PHOENIX CONTACT
Reach Compliance Code	not_compliant
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/hq/products/1742318

PCB terminal block - MKDS 5/ 5-7,62 GY BD:PA-W - 1742318

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

PCB terminal block, Nominal current: 32 A, Nom. voltage: 630 V, Pitch: 7.62 mm, Number of positions: 5,

Connection method: Screw connection with tension sleeve, Mounting: Wave soldering, Conductor/PCB

connection direction: 0 °, Color: gray

Key Commercial Data

Packing unit

GTIN

Custom tariff number

Note

4046356296496

85369010

Made to Order (non-returnable)

50 STK

Technical data

Dimensions

Length

Pitch

Dimension a

Constructional height

Height

Length of the solder pin

Pin dimensions

Hole diameter

19.05 mm

7.62 mm

30.48 mm

22 mm

21.5 mm

5.1 mm

0,9 x 0,9 mm

1.3 mm

General

Range of articles

Rated surge voltage (III/3)

Rated surge voltage (III/2)

Rated surge voltage (II/2)

Rated voltage (III/3)

Rated voltage (III/2)

Rated voltage (II/2)

Connection in acc. with standard

Nominal current I

Nominal cross section

MKDS 5

6 kV

500 V

630 V

1000 V

EN-VDE

32 A

4 mm²

11/14/2016 Page 1 / 3
