Terminal Systems
HC3
1.15 mm female terminals (compact version)
Features
•
HC3 technology
•
Compact version
•
3 contact points
•
3.2 mm pitch
•
Protected contact springs
•
Selective gold-plated versions
available
Performance characteristics*
•
Contact resistance:
•
Contact mating force:
•
Contact unmating force:
•
Current carrying capacity
at 23°C up to approx.:
at 85°C up to approx.:
at 100°C up to approx.:
< 3 mΩ
<4N
< 1N
Packing
•
No. of terminals per reel: Consult us
•
No. of reels per packing: Consult us
Tooling
10 A
8A
5A
•
Manual crimping tool:
•
Mini applicator:
Consult us
Consult us
* Mated with Ø 1.15 mm male HC3
terminals
Part Numbers
Type
Wire size range
(in mm2)
Min.
Max.
Insulation Ø
(in mm)
Max.
Material
Plating
HC3SHFBS1PT
HC3SHFBS1GP
HC3SHFBS1G127
HC3SHFBS1G127M
Female
Female
Female
Female
0.35
0.35
0.35
0.35
0.50
0.50
0.50
0.50
1.70
1.70
1.70
1.70
CuSn
CuSn
CuSn
CuSn
Sn
Au 0.4 µ
Au 0.4 µ
Au 0.4 µ
1.65
