HSMx-A2-xx-xxxxx Bi-Color
HSMx-A3xx-xxxxx Tri-Color
Surface Mount LED Indicators,
PLCC-4 SMT LEDs
Data Sheet
Description
This family of SMT LEDs is packaged in the industry
standard PLCC-4 package. These SMT LEDs have high
reliability performance and are designed to work under
a wide range of environmental conditions. This high
reliability feature makes them ideally suited to be used
under harsh interior automotive as well as interior signs
application conditions.
To facilitate easy pick and place assembly, the LEDs are
packed in EIA-compliant tape and reel. Every reel will be
shipped in single intensity and color bin, except red color
to provide close uniformity.
These LEDs are compatible with IR and TTW solder reflow
process.
This super wide viewing angle at 120° together with
the built in reflector pushing up the intensity of the
light output makes these LED suitable to be used in the
interior electronics signs. The flat top emitting surface
makes it easy for these LEDs to mate with light pipes.
This is suitable for general backlighting in automotive
interior, office equipment, industrial equipment, and
home appliances.
Features
• Industry Standard PLCC-4 package (Plastic Leaded
Chip Carrier)
• High reliability LED package
• High brightness using AlInGaP and InGaN dice tech-
nologies
• Available in full selection of colors
• Super wide viewing angle at 120°
• Available in 8 mm carrier tape on 7-inch reel
• Compatible with IR soldering process
Applications
• Electronic signs and signals
– Interior full color sign
– Variable message sign
• Interior automotive
– Instrument cluster backlighting
– Central console backlighting
– Cabin backlighting
• Office automation, home appliances, industrial
equipment
– Front panel backlighting
– Display backlighting
CAUTION: HSMF-Axxx-xxxxx LEDs are Class 2 ESD sensitive. Please observe appropriate precautions
during handling and processing. Refer to Avago Application Note AN-1142 for additional details.
Part Numbering System
HSM x
1
– A x
2
x
3
x
4
– x
5
x
6
x
7
x
8
x
9
Packaging Option
Color Bin Selection
Intensity Bin Select
Device Specification Configuration
Package Type
LED Chip Color
Absolute Maximum Ratings (T
A
= 25°C)
Parameters
DC Forward Current
[1]
Peak Forward Current
[2]
Power Dissipation
Reverse Voltage
Junction Temperature
Operating Temperature
Storage Temperature
Notes:
1. Derate linearly as shown in figure 4.
2. Duty factor = 10%, Frequency = 1kHz.
3. Drive Current between 10 mA and 30 mA are recommended for best long term performance.
4. Operation at current below 5 mA is not recommended.
GaP
30 mA
100 mA
78 mW
AlGaAs
30 mA
100 mA
78 mW
AlInGaP
Red, Amber
Yellow Green
30 mA
[3,4]
100 mA
72 mW
5V
110°C
–55°C to +100°C
–55°C to +100°C
20 mA
[4]
100 mA
48 mW
GaN/InGaN
20 mA
100 mA
120 mW
4
Optical Characteristics (T
A
= 25°C)
Peak
Wavelength
λ
PEAK
(nm)
Typ.
635
645
635
621
600
592
583
592
565
558
523
468
428
575
Dominant
Wavelength
λ
D
(nm)
[1]
Typ.
626
637
626
615
602
590
585
590
569
560
525
470
462
571
Viewing Angle
2θ
1/2
(Degrees)
[2]
Typ.
120
120
120
120
120
120
120
120
120
120
120
120
120
120
Luminous
Efficacy
η
v
(lm/W)
[3]
Typ.
120
63
150
240
380
480
580
480
590
650
500
75
65
620
Luminous Intensity/
Total Flux
I
v
(mcd) /Φ
v
(mlm)
Typ.
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
Color
GaP Red
AlGaAs Red
AlInGaP Red
AlInGaP Red Orange
GaP Orange
AlInGaP Amber
GaP Yellow
AlInGaP Amber
GaP Yellow Green
GaP Emerald Green
InGaN Green
InGaN Blue
GaN Blue
AlInGaP Yellow Green
N
otes:
1. The dominant wavelength,
λ
D
, is derived from the CIE Chromaticity Diagram and represents the color of the device.
2.
θ
1/2
is the off-axis angle where the luminous intensity is 1/2 the peak intensity.
3. Radiant intensity, I
e
in watts/steradian, may be calculated from the equation I
e
= I
v
/η
v
, where I
v
is the luminous intensity in candelas and
η
v
is the luminous efficacy in lumens/watt.
Electrical Characteristics (T
A
= 25°C)
Dice Technology
GaP
AS AlGaAs
AlInGaP
GaN Blue
InGaN
Forward Voltage
V
F
(Volts) @ I
F
= 20mA
Typ.
Max.
2.2
1.9
1.9
3.9
3.4
2.6
2.6
2.4
4.3
4.05
Reverse Voltage
V
R
@ 100
µA
Min.
5
5
5
-
-
Reverse Voltage
V
R
@ 10
µA
Min.
-
-
-
5
5
