SERIES
0805R
ct
du
In
DA
Open Construction
Wirewound Surface Mount Inductors
s
or
Actual Size (Max.)
Physical Parameters
Inches
A
0.090 Max.
B
0.068 Max.
C
0.060 Max.
D
0.050 (Ref. only)
E
0.018 (Ref. only)
F
0.040 (Ref. only)
G
0.070
H
0.040
I
0.030
Millimeters
2.29 Max.
1.73 Max.
1.52 Max.
1.27 (Ref. only)
0.44 (Ref. only)
1.03 (Ref. only)
1.78
1.02
0.76
Operating Temperature Range
–40°C to +125°C
Inductance and Q
tested on HP4291A using HP16193A
test fixture, or equivalent
Packaging
Tape & reel (8mm): 7" reel, 2000 pieces max.
-2N8K
-3N0K
-3N3K
-5N6K
-6N8K
-7N5K
-8N2K
-10NK
-12NK
-15NK
-18NK
-22NK
-24NK
-27NK
-33NK
-36NK
-39NK
-43NK
-47NK
-56NK
-68NK
-82NK
-91NK
-101K
-111K
-121K
-151K
-181K
-221K
-241K
-271K
-331K
-391K
-471K
-561K
-621K
-681K
-751K
-821K
-102K
-122K
-152K
-182K
-222K
-272K
2.8
3.0
3.3
5.6
6.8
7.5
8.2
10
12
15
18
22
24
27
33
36
39
43
47
56
68
82
91
100
110
120
150
180
220
240
270
330
390
470
560
620
680
750
820
1000
1200
1500
1800
2200
2700
SERIES 0805R CERAMIC CORE
250
80
1500
7900
250
65
1500
7900
250
50
1500
6000
250
65
1000
5500
250
50
1000
5500
250
50
1000
4500
250
50
1000
4700
250
60
500
4200
250
50
500
4000
250
50
500
3400
250
50
500
3300
250
55
500
2600
250
50
500
2000
250
55
500
2500
250
60
500
2050
250
55
500
1700
250
60
500
2000
200
60
500
1650
200
60
500
1650
200
60
500
1550
200
60
500
1450
150
65
500
1300
150
65
500
1200
150
65
500
1200
150
50
250
1000
150
50
250
1100
100
50
250
920
100
50
250
870
100
50
250
850
100
44
250
690
100
48
250
650
100
48
250
600
100
48
250
560
50
33
100
375
25
23
50
340
25
23
50
220
25
23
50
200
25
23
50
200
25
23
50
200
25
20
50
100
7.9
18
25
100
7.9
16
25
100
7.9
16
7.9
80
7.9
16
7.9
60
7.9
16
7.9
50
0.06
0.06
0.08
0.08
0.11
0.14
0.12
0.10
0.15
0.17
0.20
0.22
0.22
0.25
0.27
0.27
0.29
0.34
0.31
0.34
0.38
0.42
0.48
0.46
0.48
0.51
0.56
0.64
0.70
1.00
1.00
1.40
1.50
1.70
1.90
2.20
2.20
2.30
2.35
2.50
2.50
2.50
2.50
2.70
2.95
800
800
600
600
600
600
600
600
600
600
600
500
500
500
500
500
500
500
500
500
500
400
400
400
400
400
400
400
400
350
350
310
290
220
210
210
190
180
180
170
170
170
170
160
150
Optional Tolerances: 8.2nH & Lower J = 5%
All Other Values: J = 5% G = 2%
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com
