Electrical / Environmental
Miniature Button Inductors
Ro
p
H
t
S
losr
lian f
Com
‘LF’ M
ode
• Operating Temperature Range
• Insulation System
-40°C to +100°C
Class B, 130°C
Specifications
Part
Number
HM68-102R2
HM68-103R3
HM68-104R7
HM68-106R8
HM68-10100
HM68-10150
HM68-10220
HM68-10330
HM68-10470
HM68-202R2
HM68-203R3
HM68-204R7
HM68-206R8
HM68-20100
HM68-20150
HM68-20220
HM68-20330
HM68-20470
HM68-302R2
HM68-303R3
HM68-304R7
HM68-306R8
HM68-30100
HM68-30150
HM68-30220
HM68-30330
HM68-30470
HM68-402R2
HM68-403R3
HM68-404R7
HM68-406R8
HM68-40100
HM68-40150
HM68-40220
HM68-40330
HM68-40470
HM68-503R3
HM68-504R7
HM68-506R8
HM68-50100
HM68-50150
HM68-50220
HM68-50330
HM68-50470
Inductance
µH ±20%
2.2
3.3
4.7
6.8
10
15
22
33
47
2.2
3.3
4.7
6.8
10
15
22
33
47
2.2
3.3
4.7
6.8
10
15
22
33
47
2.2
3.3
4.7
6.8
10
15
22
33
47
3.3
4.7
6.8
10
15
22
33
47
(1)
DC
Resistance
(2)
Ω
Max.
0.21
0.24
0.29
0.44
0.62
0.91
1.27
1.79
2.74
0.21
0.24
0.30
0.43
0.52
0.82
1.18
1.53
2.27
0.15
0.20
0.27
0.38
0.63
0.82
1.05
1.50
2.47
0.16
0.19
0.22
0.27
0.38
0.62
0.91
1.32
1.75
0.081
0.106
0.144
0.187
0.30
0.431
0.637
0.875
Rated
Current
(3)
Amps
1.25
1.05
0.92
0.74
0.62
0.47
0.39
0.32
0.27
1.41
1.15
0.90
0.82
0.64
0.60
0.46
0.39
0.30
1.40
1.13
0.89
0.72
0.58
0.48
0.42
0.32
0.25
1.62
1.48
1.15
0.93
0.74
0.62
0.50
0.38
0.33
1.25
1.20
0.90
0.85
0.57
0.54
0.38
0.35
Terminals
(4)
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
1-4
(1,4) - (2,3)
(1,4) - (2,3)
(1,4) - (2,3)
(1,4) - (2,3)
(1,4) - (2.3)
1-2
1-2
1-2
Figure
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
4
4
4
38
MAGNETIC COMPONENTS SELECTOR GUIDE 2006 EDITION
We reserve the right to change specifications without prior notice.
www.bitechnologies.com
Specifications (Cont’d)
Notes:
(1) Inductance is measured at 100 kHz, 1.0 Vrms, 0 ADC.
(2) DC resistance is measured at 20°C.
(3) Rated current is the approximate current at which inductance will be decreased by 35% from its initial (zero DC) value
or the current at which
∆T
= 40°C, whichever is lower.
(4) Short pin 1 to pin 4, & pin 2 to pin 3 when HM68-50XXX ( Inductance below 22µH) model is in use.
Outline Dimensions (Inch/mm)
Figure 1 - Nonshielded
Figure 3 - Nonshielded
Figure 2 - Shielded
Figure 4 - Nonshielded
4
470
Recommended Solder Pad Layout
Figure 1 & 2
E
J
Figure 3 & 4
F G
Case Size Figure
10
1
20
30
40
50
1
2
2
3&4
A
.252
6.40
.252
6.40
.252
6.40
.252
6.40
.291
7.40
B
.197±.012
5.00±0.3
.197±.012
5.00±0.3
.197±.012
5.00±0.3
.197±.012
5.00±0.3
.216±.012
5.50±0.3
C
.039±.004
1.00±.10
.039±.004
1.20±.10
.039±.004
1.00±.10
.047±.004
1.20±.10
.059 Max.
1.50 Max.
D
.197±.004
5.00±.10
.197±.004
5.00±.10
.197±.004
5.00±.10
.197±.004
5.00±.10
.236±.008
6.0±0.2
E
.224
5.70
.224
5.70
.224
5.70
.224
5.70
.224
5.70
F
.079
2.00
.079
2.00
.079
2.00
.079
2.00
.142
3.60
G
.157
4.00
.157
4.00
.157
4.00
.157
4.00
.252
6.40
H
-
-
-
-
.330
8.40
I
-
-
-
-
.106
2.70
J
.146
3.7
.146
3.7
.146
3.7
.146
3.7
-
Ordering Information
Model Series
Case Size:
10, 20
30, 40
50 (L<22µH)
50 (L>22µH)
HM68
50
3R3
LF
TR
Tape & 7” Reel (1000 Units/Reel)
= Figure 1, Nonshielded
= Figure 2, Shielded
= Figure 3, Nonshielded
= Figure 4, Nonshielded
Inductance Code:
First 2 digits are significant.
Last digit denotes the number of trailing zeros.
For values below 10µH, “R” denotes the decimal point.
Lead-Free Option
LF = Lead-Free
(No code used for non lead-free part)
2006 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
www.bitechnologies.com
We reserve the right to change specifications without prior notice
39
