4 mm Oval Precision Optical
Performance LED Lamps
Data Sheet
Features
• Well defined spatial radiation
pattern
• Viewing angle:
major axis 120°
minor axis 60°
• High luminous output
• Two red and amber intensity
levels
AlInGaP (bright) and
AlInGaP II (brightest)
• Colors
626/630 nm red
590/592 nm amber
526 nm green
470 nm blue
• Superior resistance to moisture
• UV resistant epoxy
Benefits
• Viewing angle designed for wide
field of view applications
• Superior performance for outdoor
environments
• Radiation pattern matched for red,
green, and blue for full color sign
Applications
• Full color signs
SunPower Series
Agilent HLMP-RG10, HLMP-SG10, HLMP-RL10, HLMP-SL10,
HLMP-RD11, HLMP-SD11, HLMP-RL11, HLMP-SL11,
HLMP-RM11, HLMP-SM11, HLMP-RB11, HLMP-SB11
Description
These Precision Optical Perfor-
mance Oval LEDs are specifically
designed for Full Color/Video and
Passenger Information signs. The
oval shaped radiation pattern
(60° x 120°) and high luminous
intensity ensure that these de-
vices are excellent for wide field
of view outdoor applications
where a wide viewing angle and
readability in sunlight are essen-
tial. These lamps have very
smooth, matched radiation pat-
terns ensuring consistent color
mixing in full color applications,
message uniformity across the
viewing angle of the sign.
High efficiency LED materials are
used in these lamps: Aluminum
Indium Gallium Phosphide
(AlInGaP) for Red and Amber
color and Indium Gallium Nitride
(InGaN) for Blue and Green.
There are two families of red and
amber lamps, AlInGaP and the
higher performance AlInGaP II.
Each lamp is made with an
advanced optical grade epoxy
offering superior high tempera-
ture and high moisture resistance
in outdoor applications. The
package epoxy contains both uv-a
and uv-b inhibitors to reduce the
effects of long term exposure to
direct sunlight.
Designers can select parallel
(where the axis of the leads is
parallel to the wide axis of the
oval radiation pattern) or perpen-
dicular orientation. Both lamps
are available in tinted version.
CAUTION:
The Blue and Green LEDs are Class 1 ESD sensitive. Please observe appropriate precautions during
handling and processing. Refer to Agilent Technologies Application Note AN-1142 for additional details.
Device Selection Guide for AlInGaP II
Color and
Dominant
Wavelength
λ
d
(nm) Typ.
Red 630
Red 630
Red 630
Red 630
Red 630
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Luminous
Intensity
I
V
(mcd) at 20 mA
Min.
Max.
345
345
345
345
450
155
345
345
345
345
345
345
1330
1330
1330
1330
1010
600
1330
1330
1330
1330
1330
1330
Part Number
HLMP-SD11-LP000
HLMP-RD11-LP000
HLMP-SD11-LPT00
HLMP-RD11-LPT00
HLMP-SD11-MNT00
HLMP-SL11-HLR00
HLMP-SL11-LP000
HLMP-RL11-LP000
HLMP-SL11-LPR00
HLMP-RL11-LPR00
HLMP-SL11-LPV00
HLMP-RL11-LPV00
Leads with
Stand-Offs
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Leadframe
Orientation
Perpendicular
Parallel
Perpendicular
Parallel
Perpendicular
Perpendicular
Perpendicular
Parallel
Perpendicular
Parallel
Perpendicular
Parallel
Package
Drawing
A
B
A
B
A
A
A
B
A
B
A
B
Notes:
1. The luminous intensity is measured on the mechanical axis of the lamp package.
2. The optical axis is closely aligned with the package mechanical axis.
3. The dominant wavelength,
λ
d
, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.
Device Selection Guide for InGaN
Color and
Dominant
Wavelength
λ
d
(nm) Typ.
Green 526
Green 526
Blue 470
Blue 470
Luminous
Intensity
I
V
(mcd) at 20 mA
Min.
Max.
345
345
70
70
1330
1330
270
270
Part Number
HLMP-SM11-LP000
HLMP-RM11-LP000
HLMP-SB11-EH000
HLMP-RB11-EH000
Leads with
Stand-Offs
Yes
Yes
Yes
Yes
Leadframe
Orientation
Perpendicular
Parallel
Perpendicular
Parallel
Package
Drawing
A
B
A
B
Notes:
4. The luminous intensity is measured on the mechanical axis of the lamp package.
5. The optical axis is closely aligned with the package mechanical axis.
6. The dominant wavelength,
λ
d
, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.
3
Part Numbering System
HLMP - x x xx - x x x xx
Mechanical Options
00: Bulk Packaging
DD: Ammo Pack
YY: Flexi-Bin; Bulk Packaging
ZZ: Flexi-Bin; Ammo Pack
Color Bin & V
F
Selections
0: No Color Bin Limitation
R: Amber Color Bins 1, 2, 4, and 6 with V
F
Maximum of 2.6 V
T: Red Color with V
F
Maximum of 2.6 V
V: Amber Color Bins 1, 2, 4, and 6 with V
F
Maximum of 2.6 V
Maximum Intensity Bin
0: No Iv Bin Limitation
Minimum Intensity Bin
Refer to Device Selection Guide
Color
B: 470 nm Blue
D: 630 nm Red
G: 626 nm Red
L: 590/592 nm Amber
M: 526 nm Green
Package
R: 4 mm 60º x 120º Oval, Parallel
S: 4 mm 60º x 120º Oval, Perpendicular
Absolute Maximum Ratings
T
A
= 25°C
Parameter
DC Forward Current
[1]
Peak Pulsed Forward Current
Average Forward Current
Reverse Voltage (I
R
= 100
µA)
Power Dissipation
LED Junction Temperature
Operating Temperature Range
Storage Temperature Range
Soldering Temperature
Note:
1. Derate linearly as shown in Figures 6 and 7.
Blue and Green
30 mA
100 mA
30 mA
5V
120 mW
130°C
–40°C to +80°C
–40°C to +100°C
260° for 5 sec
Amber and Red
50 mA
100 mA
30 mA
5V
120 mW
130°C
–40°C to +100°C
–40°C to +120°C
260° for 5 sec
4
Electrical/Optical Characteristics
T
A
= 25°C
Parameter
Typical Viewing Angle
[1]
Major
Minor
Forward Voltage
Red (λ
d
= 626 nm)
Red (λ
d
= 630 nm)
Amber (λ
d
= 590 nm)
Amber (λ
d
= 592 nm)
Blue (λ
d
= 470 nm)
Green (λ
d
= 526 nm)
Reverse Voltage
Amber and Red
Blue and Green
Peak Wavelength
Red (λ
d
= 626 nm)
Red (λ
d
= 630 nm)
Amber (λ
d
= 590 nm)
Amber (λ
d
= 592 nm)
Symbol
2θ
1/2
Min.
Typ.
120
60
V
F
1.9
2.0
2.02
2.15
3.5
3.5
V
R
5
5
λ
PEAK
635
639
592
594
20
–
nm
Peak of Wavelength of
Spectral Distribution
at I
F
= 20 mA
2.4
2.4
[2]
2.4
2.4
[2]
4.0
4.0
V
I
R
= 100
µA
V
I
F
= 20 mA
Max.
Units
deg
Test Conditions
LED Indicators
Parameter
Blue (λ
d
= 470 nm)
Green (λ
d
= 526 nm)
Spectral Halfwidth
Red (λ
d
= 626/630 nm)
Amber (λ
d
= 590/592 nm)
Blue (λ
d
= 470 nm)
Green (λ
d
= 526 nm)
Capacitance
All Colors
Thermal Resistance
All Colors
Luminous Efficacy
[3]
Red (λ
d
= 626 nm)
Red (λ
d
= 630 nm)
Amber (λ
d
= 590 nm)
Amber (λ
d
= 592 nm)
Blue (λ
d
= 470 nm)
Green (λ
d
= 526 nm)
Symbol
Min.
Typ.
467
524
17
17
20
35
Max.
Units
Test Conditions
∆λ
1/2
nm
Wavelength Width at
Spectral Distribution
1
/
2
Power Point at I = 20 mA
F
C
40
Rθ
J-PIN
240
η
v
150
155
480
500
70
540
pF
°C/W
lm/W
V
F
= 0, F = 1 MHz
LED Junction-to-Cathode
Lead
Emitted Luminous Power/
Emitted Radiant Power
Notes:
1. 2θ
1/2
is the off-axis angle where the luminous intensity is the on-axis intensity.
2. For options -xxRxx, -xxTxx, and -xxVxx, maximum forward voltage, V
F
, is 2.6 V.
3. The radiant intensity, I
e
, in watts per steradian, may be found from the equation I
e
= I
v
/η
v
, where I
v
is the luminous intensity in candelas and
η
v
is
the luminous efficacy in lumens/watt.
5
