ASPI-0425-330M-T3 datasheet, PDF

Datasheet> All Categories > Passive components> inductor> ASPI-0425-330M-T3

ASPI-0425-330M-T3: DescriptionGeneral Purpose Inductor, 33uH, 20%, 1 Element, SMD, 1616, CHIP, 1616, ROHS COMPLIANT; CategoryPassive components inductor; File Size1MB，3 Pages; ManufacturerAbracon; Websitehttp://www.abracon.com/index.htm; Environmental Compliance

Download Datasheet Parametric Compare View All

ASPI-0425-330M-T3 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ASPI-0425-330M-T3	-	-	View	Buy Now

ASPI-0425-330M-T3 Overview

General Purpose Inductor, 33uH, 20%, 1 Element, SMD, 1616, CHIP, 1616, ROHS COMPLIANT

ASPI-0425-330M-T3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	1616
Reach Compliance Code	compli
ECCN code	EAR99
Factory Lead Time	12 weeks
uppercase and lowercase codes	1616
DC Resistance	0.305 Ω
Nominal inductance(L)	33 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Number of functions	1
Number of terminals	2
Maximum operating temperature	120 °C
Minimum operating temperature	-25 °C
Maximum rated current	0.5 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	YES
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	ONE SURFACE
Test frequency	0.1 MHz
Tolerance	20%
Base Number Matches	1

Preview

Download Datasheet

View All

LOW PROFILE SHIELDED SMD CHIP POWER INDUCTOR

ASPI-0425

FEATURES:

•

Small size and low profile: 2.5mm

Small DCR and high rated current

High reliability to mechanical strength

Magnetically shielded by magnetic powder molding

Suitable for RoHS reflow profile

Abracon P/N:

Operating Temperature & Humidity

Storage Temperature & Humidity:

ASPI-0425

RoHS

Compliant

4.0 x 4.0 x 2.5mm

APPLICATIONS:

• Mobile phones

• MP3 & 4 and other portable communication equipment

• Digital cameras.

ELECTRICAL SPECIFICATIONS:

-25˚C to +120˚C

(Including self generated heat)

-10˚C to + 40˚C, 30% to 70%

Inductance

Tolerance

M, N

DCR

mΩ

DCR

120

195

305

495

710

1000

1600

2300

DCR

Tolerance

±30%

Saturation

Current

Isat*

3.00

2.75

2.10

1.60

1.40

1.20

0.97

0.77

0.67

0.50

0.40

0.35

0.30

0.22

0.20

Temperature

Rise Current

Irms*

3.00

2.75

2.10

1.60

1.40

1.20

0.97

0.77

0.67

0.50

0.40

0.35

0.30

0.22

0.20

Part Number

Units

Symbol

ASPI-0425-1R0

ASPI-0425-1R2

ASPI-0425-2R2

ASPI-0425-3R3

ASPI-0425-4R7

ASPI-0425-6R8

ASPI-0425-100

ASPI-0425-150

ASPI-0425-220

ASPI-0425-330

ASPI-0425-470

ASPI-0425-680

ASPI-0425-101

ASPI-0425-151

ASPI-0425-221

Inductance

μH

1.0

1.2

2.2

3.3

4.7

6.8

100

150

220

±20%

Test Conditions

1. Inductance is measured in

HP-4285A

Precision LCR Meter.

2. RDC is measured in

DU-5011

milli ohm meter.(or equivalent).

3. Isat : Based on inductance change (△

L/Lo :

≤

-30%)

4. Irms : Based on temperature rise (△ : 40

C TYP.

)

5. Test Freq: 100KHz, 1Vrms

OPTIONS AND PART IDENTIFICATION

ASPI-0425-

Inductance Code

Please refer to the

Electrical Spec Table

Tolerance

N: ±30%*

M: ±20%*

*N for L = 1.0 ~ 2.2µH

*M for L = 3.3 ~ 220µH

Packaging

T3: Tape and Reel (3kpcs / reel)

ABRACON IS

ISO9001:2008

CE RTIFIED

Revised: 12.20.11

30332 E speranza, Rancho Santa Margarita, California 92688

tel 949-546-8000

fax 949-546-8001

| www.abracon.com

Visit www.abracon.com for Terms & Conditions of Sale
