ZEE

CONNECT

Stainless Steel Connectors

18 GHZ PRECISION RF

COAX CABLE ASSEMBLIES

___

ZEE

CONNECT

SS402 50 Ohm 18G Hz Precision Coaxial Cables

makes multiple connections simple.

Connectors are designed to allow for finger tightening.

Connectors also incorporate hex nut configuration when torque

requirements are needed. Perfect for Lab and Field Use.

Features:

Strain Relief:

Center Conductor:

Inner Shielding:

Outer Braid:

Insulation:

Jacket:

Heavy duty adhesive strain relief

SPCCS (Silver-Plated Copper Clad Steel)

SS (Spiral Strip Of Silver-Plated Copper)

SPC (Silver-Plated Copper Braid)

PTFE (Polytetrafluoroethylene) dielectric

ETFE (Ethylene Tetrafluoroethylene

Copolymer)

Cable Outer Dia.

0.163” (4.14mm)

Connectors:

SST, corrosion-resistant 303 stainless steel

per ASTM-A582

(Passivated finish per SAE-AMS-2700)

Center Pin:

GPBC (Gold-Plated Beryllium Copper)

Jacket Color:

Blue

Operating Temperature:

-40°C to +85°C

Minimum Bend Radius:

0.8”

Electrical Specifications:

Impedance:

Frequency:

Insertion Loss:

VSWR:

Nominal Capacitance:

Velocity of Propagation:

Shield Effectiveness:

Attenuation (dB/ft):

*connector loss not included

50 Ohms

18 GHz

0.58 dB/ft Typ at 18 GHz

<1.3, DC to 18 GHz

29.4 pF/ft

70%

Greater than 110 dB

0.07 Typical at 400 MHz

0.11 Typical at 1 GHz

0.16 Typical at 2 GHz

0.21 Typical at 3 GHz

0.27 Typical at 5 GHz

0.41 Typical at 10 GHz

0.58 Typical at 18 GHz

1100 @ 400 MHz

550 @ 1 GHz

350 @ 3 GHz

245 @ 5 GHz

140 @ 10 GHz

Max Power in (Watts):

*as specified at 25°C

Mechanical Specifications:

Available Connectors:

SMA Male

SMA Male Right Angle

Connector Corrosion (salt spray):

MIL-STD-202, method 101, test cond. B 5% salt

solution.

Connector Durability:

500 connections Minimum

Custom Lengths Available

Part Number

CCESMA-MM-SS402-12

CCESMA-MM-SS402-24

CCESMA-MM-SS402-36

CCESMA-MM-SS402-48

CCESMA-MM-SS402-60

CCESMA-MM-SS402-72

CCESMA-MM-SS402-120

SMA / SMA [Straight/Straight]

Description

SS402 Precision Coax Cable, SMA Male/Male, Straight/Straight

Length

12”

24”

36”

48”

60”

72”

120”

Rev.: D

Date: 04-07-14
