Strain Relief Bushings
Heyco RDD Lockit Strain Relief Bushings –
Pigtail
®
™
™
Snap onto
Flat or Round Cables
for Faster Assembly into
Double D
Mounting Holes
-
Semi-Automatic Equipment Available
WILL FIT THESE CABLES
UL Type
AWG/
Approximate
Conductors
Size
in.
mm.
PANEL DIMENSIONS
RDD LOCKIT STRAIN RELIEF
Corresponding
Mounting Hole
Thickness
for Faster Assembly
Mounting Hole Plug
Size
PART NO.
DESC.
PART
in.
mm.
in. mm.
Black White
NO.
DESC.
.032
.040
.625 w/ 15,9 w/
.048
.550 flats 14,0 flats
.063
.099
.032
.040
.625 w/ 15,9 w/
.048
.550 flats 14,0 flats
.063
.099
.032
.040
.625 w/ 15,9 w/
.048
.550 flats 14,0 flats
.063
.099
0,8
1,1
1,2
1,6
2,5
0,8
1,1
1,2
1,6
2,5
0,8
1,1
1,2
1,6
2,5
For Flat Cables
SPT-1
18/2
18/3
.105 x .222 2,7 x 5,6
.116 x .315 2,9 x 8,0
1769 1770
RDD 100A-7 2497 DD 625-550
SPT-2,
HPN
18/2
18/3
16/3
.116 x .315 2,9 x 8,0
.160 x .300 4,1 x 7,6
1771 1772
RDD 100-7
2497 DD 625-550
For Round Cables
See
table
on page
4-10
various
.220-.290 5,6 x 7,4
1773 1774
RDD 101-7
2497 DD 625-550
Standard color black. Consult Heyco for white and other colors.
Locking Tab varies with Cable Type
1.71
(43.5)
2.15
(54.7)
.53
(13.5)
.71
(18.0)
.550
(14.0)
MOUNTING HOLE
.625
(15.9)
RDD 100A-7, RDD 100-7, RDD 101-7
•
Integral nylon spring eases the cable
into a lazy bend;
prevents kinking and
assures longest cable and product life.
•
Designed to pass CSA’s 50,000 cycle
vacuum cleaner test ( C22.2 No. 67)
and UL’s 859 specification for
Household Electric Personal
Grooming Appliances Cord
Flexing Test.
•
Assembly friendly! Independent of
insertion into the panel, RDD Lockit
™
Strain Reliefs self-lock onto the cable.
Preassemble RDD Lockits off line
for final assembly at a later time
or remote location, for lower
installed cost!
•
Install easily with fingertip pressure
into a standard round or Double D
hole. No tools required, even for
hand assembly.
•
Protect the lifeline of your electric/
electronic products by absorbing the
forces of push and pull that may be
exerted on the flexible power cord.
Double D design eliminates the
possibility of part rotation under forces
of twist.
•
Multiple panel locking steps secure
Lockit Strain Reliefs into a wide range
of panel thicknesses for a
flush,
finished fit.
•
Heyco’s automated Pre-Assembly
Equipment speeds assembly of the
RDD onto the cable and thus lowers
costs while greatly reducing risk of
carpal tunnel syndrome.
See pages 4-15 & 4-16.
•
See page 4-38 for corresponding
Mounting Hole Plugs
which can be
used to fill blank/unused Mounting
Holes and thus allow for a single panel
design for multiple applications.
Material
Certifications
Flammability Rating
Temperature Range
Nylon 6/6
Recognized under the Component Program of Underwriters’ Laboratories
File E15331
Certified by the Canadian Standards Association File 8919
94V-2
-.04°F (-18°C) to 221°F (105°C)
Quick
Specs
4-12
1-800-526-4182 • 732-286-1800 (NJ) • FAX: 732-244-8843 • www.heyco.com
