SH
www.vishay.com
Vishay Sfernice
Heatsink Encased Wirewound Power Resistors
Industrial Applications
FEATURES
•
•
•
•
•
•
50 W at + 25 °C
High power characteristics
RoHS
Utilize heatsink capability
COMPLIANT
Good mechanical protection
Industrialized product
Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
Built for high power dissipation applications, these components have very good overall characteristics for industrial use under
harsh environmental conditions.
DIMENSIONS
in millimeters
A
D
M
F
N
Ø2
H
J
G
B
ØK
E
Q
ØP
L
SERIES
SH5
SH10
SH25
SH50
A
28.5 ± 1.5
35.5 ± 1.5
49 ± 1.3
70.2 ± 1.4
B±
0.2
12.5
15.9
19.8
21.4
D±
0.2
11.3
14
18.3
39.7
E±
0.5
16.3
19
28
50
F
6.8 ± 1.5
7.9 ± 1.5
11.1 ± 1.5
11 ± 1.2
G±1
8.5
11
14
15.5
H±
0.7
6.2
7.9
9.9
10.7
J±
0.5
16.4
20.6
27.5
29.4
ØK±
0.1
2.4
2.4
3.2
3.2
L
MAX.
8.9
11
15
15
M±
0.5
4.3
5.6
8
8
N±
0.3
1.6
2
2.4
2.4
ØP
MIN.
2.1
2.1
2.1
2.1
Q
25.3 ± 1.5
30.6 ± 1.5
44.6 ± 1.3
66.5 ± 1.4
WEIGHT
g
3
8.8
16.5
30.8
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
SH5
SH10
SH25
SH50
RESISTANCE RANGE
0.1 to 3.3K
0.1 to 15K
0.1 to 33K
0.1 to 51K
RATED POWER
P
25 °C
W
10
12.5
25
50
LIMITING ELEMENT
VOLTAGE
V
160
250
550
1285
TOLERANCE
±%
5
5
5
5
TECHNICAL SPECIFICATIONS
VISHAY SFERNICE SERIES
Power Rating
Chassis mounted resistors:
413 cm
2
for SH5 and SH10, 536 cm
2
for SH25 and SH50
Unmounted resistors
Dielectric Strength V
RMS
Insulation Resistance
Temperature Coefficient
Climatic Category
Temperature Limits
Revision: 05-Aug-13
at 25 °C
at 70 °C
at 25 °C
at 70 °C
SH5
10 W
8W
4W
3.2 W
800 V
SH10
12.5 W
10 W
SH25
25 W
20 W
SH50
50 W
40 W
6W
9W
12 W
4.8 W
7.2 W
9.6 W
1000 V
2000 V
2000 V
4
M
4
M
> 10
> 3 x 10
± 50 ppm/°C
R
n
> 50
55/200/56
- 55 °C
+ 200 °C
Document Number: 50014
1
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
SH
www.vishay.com
Vishay Sfernice
CONDITIONS
5
P
n
/5 s
- 55 °C
+ 200 °C
5 cycles
Nominal power
P
n
1000 h at 25 °C
TYPICAL DRIFTS
± 0.5 % max.
± 1 % max.
± 1 % max.
+ 0.05
+ 0.05
+ 0.05
PERFORMANCE
TESTS
Momentary Overload
Climatic Sequence
Load Life
POWER RATING
125
TEMPERATURE RISE
HOT SPOT TEMPERATURE IN °C
250
100
RATED POWER IN %
200
5
SH
0
75
150
50
100
1
SH
5
SH
0
2
SH
5
25
50
0
0
50
100
150
200
250 275 300
350
0
0
10
20
30
40
50
60
70
AMBIENT TEMPERATURE IN °C
RATED POWER IN W
(Mounted on heatsink chassis)
MARKING
Vishay Sfernice trademark, model, style, nominal resistance
(in
),
tolerance (in %), manufacturing date.
PACKAGING
Bag of 10 units
ORDERING INFORMATION
SH
MODEL
25
STYLE
10 k
OHMIC VALUE
5%
TOLERANCE
BA10
PACKAGING
e1
LEAD (Pb)-FREE
SAP PART NUMBERING GUIDELINES
SH
MODEL
25
STYLE
10001
OHMIC VALUE
J
TOLERANCE
S03
PACKAGING
Revision: 05-Aug-13
Document Number: 50014
2
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
