LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS
Standard snap-ins, 105℃
KMM
Downsized
Longer life
KMH
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
(tanδ)
Low Temperature
Characteristics
(Max. Impedance Ratio)
Endurance
Series
・Endurance
with ripple current : 2,000 hours at 105℃
・Non
solvent resistant type
・RoHS2
Compliant
KMH
◆SPECIFICATIONS
Characteristics
-40 to +105℃
6.3 to 100V
dc
(at 20℃, 120Hz)
±20%
(M)
I=0.02CV or 3mA, whichever is smaller
Where, I : Max. leakage current (µA), C : Nominal capacitance (µF), V : Rated voltage (V)
(at 20℃ after 5 minutes)
Rated voltage (V
dc
)
6.3V 10V 16V 25V 35V 50V 63V 80V 100V
tanδ (Max.)
0.60 0.50 0.40 0.30 0.25 0.20 0.15 0.15 0.15
(at 20℃, 120Hz)
Rated voltage (V
dc
)
6.3V 10V 16V 25V 35V 50V 63V 80V 100V
Z(-25℃)/Z(+20℃)
4
4
4
3
3
2
2
2
2
Z(-45℃)/Z(+20℃)
15
15
15
10
8
6
6
5
5
(at 120Hz)
The following specifications shall be satisfied when the capacitors are restored to 20℃ after subjected to DC voltage with the rated
ripple current is applied (the peak voltage shall not exceed the rated voltage) for 2,000 hours at 105℃
Capacitance change
≦±20%
of the initial value
D.F. (tanδ)
≦200%
of the initial specified value
Leakage current
≦The
initial specified value
The following specifications shall be satisfied when the capacitors are restored to 20℃ after exposing them for 1,000 hours at 105℃ without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change
≦±20%
of the initial value
D.F. (tanδ)
≦150%
of the initial specified value
Leakage current
≦The
initial specified value
Shelf Life
◆DIMENSIONS
[mm]
●
Terminal
Code : VS (
φ
22 to
φ
35) : Standard
Negative mark
PC board pin-out
(View from Solder side)
●
Terminal
Code : LI (
φ
35)
Negative mark
PC board pin-out
(View from Solder side)
4.2±0.5
5±0.5
14.2±1
2-1.2×6
Sleeve (PET : Brown)
φ
D+1max.
Sleeve (PET : Brown)
φ
D+1max.
Vent
L±2
*
4.0±0.5
2-φ2
10
Vent
L±2
4.5±1
*
φ
D=35mm : 3.5
±
0.5mm
The standard design has no plastic disc.
◆PART
NUMBERING SYSTEM
E KMH
1
2
3
4
5
6
7
VS N
8
9
10
11
12
13
M
14
15
16
17
S
18
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 820µF:821, 3,300µF:332)
Dummy terminal code
Terminal code (VS, LI)
Voltage code (ex. 6.3V:6R3, 10V:100, 100V:101)
Series code
Category
Please refer to "Product code guide (snap-in type)"
Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.
CAT. No. E1001S
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS
Standard snap-ins, 105℃
KMH
Series
◆STANDARD
RATINGS
WV
(V
dc
)
Cap
(µF)
12,000
15,000
18,000
18,000
22,000
22,000
22,000
27,000
27,000
27,000
33,000
33,000
33,000
33,000
39,000
39,000
39,000
47,000
47,000
47,000
56,000
56,000
68,000
68,000
82,000
10,000
12,000
15,000
15,000
18,000
18,000
22,000
22,000
22,000
27,000
27,000
27,000
27,000
33,000
33,000
33,000
39,000
39,000
39,000
47,000
47,000
56,000
56,000
68,000
6,800
10,000
10,000
12,000
12,000
12,000
15,000
15,000
15,000
18,000
18,000
18,000
18,000
22,000
22,000
22,000
27,000
27,000
Rated ripple
current
Case size
tanδ
(Arms/
φD×L(mm)
105℃, 120Hz)
22
×
25
22
×
25
22
×
30
25.4
×
25
22
×
35
25.4× 30
30
×
25
22
×
40
25.4
×
35
30
×
25
22
×
45
25.4
×40
30
×
30
35
×
25
25.4× 40
30
×
35
35
×
30
25.4× 50
30
×
40
35
×
30
30
×
45
35
×
35
30
×
50
35
×
40
35
×
45
22
×
25
22
×
30
22
×
30
25.4× 25
22× 35
25.4× 30
22
×
40
25.4
×35
30
×
25
22
×
50
25.4× 40
30
×
30
35
×
25
25.4
×
45
30
×35
35
×
30
25.4
×
50
30
×
40
35
×
30
30
×
45
35
×
35
30
×
50
35
×
40
35
×
50
22
×
25
22× 30
25.4× 25
22
×
35
25.4
×
30
30
×
25
22
×
40
25.4
×
35
30
×
25
22
×
45
25.4× 40
30
×
30
35
×
25
25.4
×
45
30
×
35
35
×
25
25.4
×50
30
×
40
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.60
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
1.54
1.72
1.95
1.96
2.23
2.25
2.28
2.54
2.57
2.52
2.88
2.93
2.89
2.93
3.18
3.26
3.40
3.69
3.69
3.73
4.16
4.12
4.71
4.69
5.32
1.55
1.77
1.97
1.96
2.21
2.23
2.51
2.54
2.40
2.93
2.90
2.87
2.73
3.30
3.28
3.16
3.68
3.69
3.43
4.17
3.76
4.68
4.67
5.46
1.57
1.97
1.97
2.22
2.24
2.45
2.55
2.58
2.52
2.87
2.92
2.88
2.92
3.32
3.29
3.23
3.78
3.77
Part No.
EKMH6R3VSN123MP25S
EKMH6R3VSN153MP25S
EKMH6R3VSN183MP30S
EKMH6R3VSN183MQ25S
EKMH6R3VSN223MP35S
EKMH6R3VSN223MQ30S
EKMH6R3VSN223MR25S
EKMH6R3VSN273MP40S
EKMH6R3VSN273MQ35S
EKMH6R3VSN273MR25S
EKMH6R3VSN333MP45S
EKMH6R3VSN333MQ40S
EKMH6R3VSN333MR30S
EKMH6R3VSN333MA25S
EKMH6R3VSN393MQ40S
EKMH6R3VSN393MR35S
EKMH6R3VSN393MA30S
EKMH6R3VSN473MQ50S
EKMH6R3VSN473MR40S
EKMH6R3VSN473MA30S
EKMH6R3VSN563MR45S
EKMH6R3VSN563MA35S
EKMH6R3VSN683MR50S
EKMH6R3VSN683MA40S
EKMH6R3VSN823MA45S
EKMH100VSN103MP25S
EKMH100VSN123MP30S
EKMH100VSN153MP30S
EKMH100VSN153MQ25S
EKMH100VSN183MP35S
EKMH100VSN183MQ30S
EKMH100VSN223MP40S
EKMH100VSN223MQ35S
EKMH100VSN223MR25S
EKMH100VSN273MP50S
EKMH100VSN273MQ40S
EKMH100VSN273MR30S
EKMH100VSN273MA25S
EKMH100VSN333MQ45S
EKMH100VSN333MR35S
EKMH100VSN333MA30S
EKMH100VSN393MQ50S
EKMH100VSN393MR40S
EKMH100VSN393MA30S
EKMH100VSN473MR45S
EKMH100VSN473MA35S
EKMH100VSN563MR50S
EKMH100VSN563MA40S
EKMH100VSN683MA50S
EKMH160VSN682MP25S
EKMH160VSN103MP30S
EKMH160VSN103MQ25S
EKMH160VSN123MP35S
EKMH160VSN123MQ30S
EKMH160VSN123MR25S
EKMH160VSN153MP40S
EKMH160VSN153MQ35S
EKMH160VSN153MR25S
EKMH160VSN183MP45S
EKMH160VSN183MQ40S
EKMH160VSN183MR30S
EKMH160VSN183MA25S
EKMH160VSN223MQ45S
EKMH160VSN223MR35S
EKMH160VSN223MA25S
EKMH160VSN273MQ50S
EKMH160VSN273MR40S
