LPS6225-153MRC

Description
Fixed Inductors LPS6225 Low Profile 15uH 1.2A 20% SMD
CategoryPassive components
File Size185KB,2 Pages
ManufacturerCOILCRAFT
Websitehttp://www.coilcraft.com/
Environmental Compliance
Download Datasheet Parametric View All

LPS6225-153MRC Online Shopping

Suppliers Part Number Price MOQ In stock
LPS6225-153MRC - - View Buy Now

LPS6225-153MRC Overview

Fixed Inductors LPS6225 Low Profile 15uH 1.2A 20% SMD

LPS6225-153MRC Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerCOILCRAFT
Product CategoryFixed Inductors
RoHSDetails
Termination StyleSMD/SMT
ShieldingShielded
Inductance15 uH
Tolerance20 %
Maximum DC Current2.2 A
Maximum DC Resistance135 mOhms
Minimum Operating Temperature- 40 C
Maximum Operating Temperature+ 85 C
Test Frequency100 kHz
Termination-
Mounting StylePCB Mount
Length6 mm
Width6 mm
Height2.4 mm
ApplicationPower
PackagingCut Tape
PackagingMouseReel
PackagingReel
Core MaterialFerrite
ProductFixed Inductors
Self Resonant Frequency23 MHz
TypeShielded Power Inductor
Factory Pack Quantity750
Unit Weight0.011640 oz
Web
page
Sample
& buy
Tools &
software
Support
& FAQ
Document 554-1
Shielded Power Inductors – LPS6225
• Low DCR; high current; shielded construction
• Perfect for backlight applications
Designer’s Kit C349
contains 3 each of all values
Core material
Ferrite
Core and winding loss
See
www.coilcraft.com/coreloss
Environmental
RoHS compliant, halogen free
Terminations
RoHS compliant matte tin over nickel over silver.
Other terminations available at additional cost.
Weight
309 – 331 mg
Ambient temperature
–40°C to +85°C with (40°C rise)
Irms
current.
Maximum part temperature
+125°C (ambient + temp rise).
Derating.
Storage temperature
Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
750/7″ reel; 2500/13″ reel Plastic tape: 12 mm wide,
0.3 mm thick, 8 mm pocket spacing, 2.57 mm pocket depth
Recommended pick and place nozzle
OD: 6.2 mm; ID:
3.1 mm
PCB washing
Tested to MIL-STD-202 Method 215 plus an additional
aqueous wash. See
Doc787_PCB_Washing.pdf.
Part number
1
Isat
(A)
5
DCR
SRF
Inductance
2
max
3
typ
4
10% 20% 30%
± 20% (µH) (Ohms) (MHz) drop drop drop
1.2
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
120
150
220
330
470
680
1000
1500
1800
2200
3300
4700
5600
0.040 178
0.045 100
0.055 68
0.065 53
0.095 40
0.105
0.135
0.175
0.260
0.360
0.420
0.610
0.750
0.920
1.30
2.00
2.60
4.00
6.00
9.00
11.7
13.5
21.0
30.0
36.0
43.0
54.0
70.0
35
23
17
14
10
9.6
7.7
7.4
6.4
5.0
3.8
3.2
2.8
2.3
1.8
1.7
1.3
1.1
0.90
0.72
5.3
3.9
3.5
3.0
2.6
2.5
2.1
1.4
1.1
0.98
0.58
0.48
0.42
0.39
0.32
0.26
0.22
0.18
0.15
0.12
0.11
0.10
0.099
0.086
0.083
5.4
4.0
3.5
3.1
2.7
2.6
2.2
1.5
1.2
1.0
0.61
0.51
0.45
0.41
0.34
0.27
0.23
0.19
0.16
0.13
0.12
0.10
0.10
0.096
0.090
5.4
4.1
3.6
3.2
2.8
2.7
2.2
1.6
1.2
1.0
0.62
0.52
0.46
0.42
0.35
0.28
0.24
0.20
0.17
0.13
0.12
0.11
0.11
0.10
0.096
Irms
(A)
6
20°C 40°C
rise rise
1.1
1.0
1.0
0.90
0.90
0.90
0.85
0.80
0.65
0.60
0.57
0.47
0.43
0.40
0.37
0.28
0.24
0.18
0.15
0.13
0.11
0.11
0.080
0.075
0.070
1.65
1.40
1.35
1.30
1.30
1.30
1.20
1.10
0.90
0.80
0.74
0.64
0.58
0.54
0.50
0.39
0.37
0.26
0.24
0.20
0.14
0.13
0.11
0.090
0.090
1. Please specify
termination
and
packaging
codes:
LPS6225-106MRC
Termination: R
= RoHS compliant matte tin over
nickel over silver.
Special order, added cost:
Q
= RoHS tin-silver-copper (95.5/4/0.5)
or
P
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481
embossed plastic tape (750 parts
per full reel).
B
= Less than full reel. In tape, but not
machine ready. To have a leader and
trailer added ($25 charge), use code
letter C instead.
D
= 13″ machine-ready reel. EIA-481
embossed plastic tape. Factory
order only, not stocked (2500 parts
per full reel).
2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using Agilent/HP 8753ES or equivalent.
5. DC current at 25°C that causes the specified induc-
tance drop from its value without current.
Click for temperature derating information.
6. Current that causes the specified temperature rise from
25°C ambient. This information is for reference only and
does not represent absolute maximum ratings.
Click for temperature derating information.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering.
LPS6225-122MR_
LPS6225-222MR_
LPS6225-332MR_
LPS6225-472MR_
LPS6225-682MR_
LPS6225-103MR_
LPS6225-153MR_
LPS6225-223MR_
LPS6225-333MR_
LPS6225-473MR_
LPS6225-683MR_
LPS6225-104MR_
LPS6225-124MR_
LPS6225-154MR_
LPS6225-224MR_
LPS6225-334MR_
LPS6225-474MR_
LPS6225-684MR_
LPS6225-105MR_
LPS6225-155MR_
LPS6225-185MR_
LPS6225-225MR_
LPS6225-335MR_
LPS6225-475MR_
LPS6225-565MR_
LPS6225-685MR_ 6800
LPS6225-825MR_ 8200
LPS6225-106MR_ 10000
0.70 0.080 0.086 0.089 0.065 0.080
0.69 0.079 0.086 0.088 0.060 0.075
0.68 0.075 0.084 0.087 0.060 0.065
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 554-1
Revised 02/20/18
© Coilcraft Inc. 2018
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
