174-8000 Series
Connectors
2.54 min.
2.66 max.
174-8000 Series
ø.787
1
3
Fig. A
3 Pin
2
1
2 3
Fig. B
4 Pin
4
1
2
3
Fig. C
5 Pin
4
5
ø.748
Dimensions (In.)
Specifications:
•
Type: broadcast quality male XLR
•
Housing: zinc high-pressure diecasting satin nickel or black chrome
•
Screw collar: polycarbonate, 10% glass filled Lexan, black
•
Contact base: valox DR48
•
Contacts: brass 3µ silver plated or .5µ gold plated
•
Strain relief: PVC, black
•
Sealing ring: santoprene, UL 94 HB
•
Chuck: acetal, UL 94 HB
•
Screen: spring steel, 3µ silver plate, anti-tarnish
•
Optional identification rings: acetal, UL 94 HB; colors (yellow, brown,
blue, green, red, white, black, and clear)
•
Cable retention: chuck and screw collar
•
Terminals: solder buckets
•
Cable range: ø2.8mm~ø8.0mm
Current Wire Cap.
•
Insertion force:
≤20N
Mouser
•
Withdrawal force:
≤10N
Stock No. Fig. Housing Contacts Rating AWG (pf)
(A)
•
Life: 5000 insertions min.
•
Working voltage: 250VAC
16
174-8123
A
Nickel
Silver
12
≤4
•
Test voltage: 1500VAC
174-8124
B
10
Silver
Nickel
16
≤7
•
Contact resistance:
≤3mΩ
max.
C
7.5
174-8125
Silver
Nickel
18
≤7
•
Temperature range: -30°~+80°C
16
174-8223
A
Black
Silver
12
≤4
•
Insulation resistance:
≥1GΩ
174-8224
B
10
Silver
Black
16
≤7
C
7.5
174-8225
Black
Silver
18
≤7
16
174-8133
A
Nickel
Gold
12
≤4
174-8134
B
10
Gold
Nickel
16
≤7
C
7.5
174-8135
Gold
Nickel
18
≤7
A
16
174-8233
Black
Gold
12
≤4
10
174-8234
B
Black
Gold
16
≤7
7.5
174-8235
C
Gold
Black
18
≤7
Connectors
8-
041804
Date:
5-7-99
