10/100 BASE-T SINGLE PORT
TRANSFORMER MODULES
With 2:1 Transmit Turns Ratios Compatible
with MicroLinear, MITEL, and SEEQ Transceivers
RoHS-5 peak reflow temperature rating 235°C
RoHS-6 peak reflow temperature rating 245°C
Patented InterlockBase design
Meets all IEEE 802.3 and ANSI X3.236 standards,
including 350 µH OCL with 8 mA bias
Various pinout options available for optimal
board layout
Electrical Specifications @ 25°C — Operating Temperature 0°C to 70°C
RoHS-5
1
Compliant
Part
Number
H1038
H1090
H1094
RoHS-6
2
Compliant
Part
Number
H1038NL
H1090NL
H1094NL
Insertion Loss
(dB TYP)
0.1 to 100 MHz
-1.0
-1.0
-1.0
Rise Time
(ns TYP)
(10 - 90%)
3.5
3.5
3.5
Return Loss
(dB TYP)
0.1-60 MHz 60-100 MHz
-16
-12
-16
-12
-16
-12
Differential to Common
Mode Rejection
(dB TYP)
0.1-60 MHz 60-100 MHz
-35
-32
-35
-32
-35
-32
Crosstalk
(dB TYP)
0.1-60 MHz 60-100 MHz
-40
-35
-40
-35
-40
-35
Voltage
Isolation
(Vrms MIN)
1500
1500
1500
1. RoHS-5:
Product does not contain 5 out of the 6 banned substances specified in the RoHS directive (product contains lead in applications considered solder).
2. RoHS-6:
Product does not contain 5 out of the 6 banned substances specified in the RoHS directive. Some internal connections may contain lead in high-temperature
solder (solder alloys containing more than 85% lead).
NOTE:
For Tape & Reel packaging add a “T” suffix to the part number (i.e.: H1038T).
U.S. Patent No. 5,015,981
Mechanical
H1038, H1090, H1094
.700
17,78
.100
2,54
Schematics
H1038
1
3
2
6
7
2CT:1
1CT:1CT
16
14
RECEIVE
15
9
H10XX
Date Code Countr y of Origin
.505 MAX
12,83
.540
13,72
.100
2,54
.700
17,78
1.005 MAX
25,53
.040
1,02
.100
2,54
8
SUGGESTED PAD LAYOUT
TRANSMIT
10
.395
10,03
.235 MAX
5,97
0° 8°
16 x .035
0,89
Weight
. . . . . . .2.5 grams
Tube
. . . . . . . . . . .23/tube
Tape & Reel
. . . . .350/reel
H1090
1
10Base-T
1:1:1CT
14
RECEIVE
2CT:1CT
11
TRANSMIT
16
100Base-TX
2
3
4
.004/0,10
16 SURFACES
.010
0,25
15
10
6
7
8
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
9
USA 858 674 8100
•
UK 44 1483 401 700
•
France 33 3 84 35 04 04
•
Singapore 65 6287 8998
•
Shanghai
86 21 32181071
•
China 86 769 5538070
•
Taiwan 886 2 26980228
www.pulseeng.com
1
H315.B (8/06)
10/100 BASE-T SINGLE PORT
TRANSFORMER MODULES
With 2:1 Transmit Turns Ratios Compatible
with MicroLinear, MITEL, and SEEQ Transceivers
Schematics
H1094
16
10Base-T
Application Notes
The magnetics modules have been specifically designed for implementation of 10/100
Mbps and 100Base-TX data links over data-grade unshielded twisted pair cable (UTP-
5). The modules provide excellent EMI filtering and are targeted for adapter card and
multiport applications. In designing these parts, Pulse has worked closely with mem-
bers of the IEEE 802.3 and ANSI X3.236 committees to develop an analog interface
that provides isolation and EMI filtering for MLT-3 and NRZ transceivers.
The H1090 and H1094 are designed to interface with the MicroLinear ML6692,
ML6694, ML6697, or ML6698 in 10/100 Mbps applications. The H1038 is optimized for
SEEQ or MITEL (formerly GEC Plessy) 10/100 Mbps applications.
The transformers used in the modules provide high voltage isolation, wide
bandwidth, and fast rise time. They utilize stable ferrite materials to minimize the
degradation of primary inductance with base-line wander. At least 350 µH of
inductance will be provided by the transformers in these modules when 0 - 8 mA is
applied across the windings over a temperature range of 0° - 70°C. The High Speed
LAN magnetics modules provide the designer with low cost analog components
for simple and reliable designs. The parts are encased in IC-grade packaging, which
shows superior performance under high temperature solder reflow conditions.
For information on TP-FDDI, Fast Ethernet, and ATM solutions, contact Pulse’s
HS LAN Marketing Group.
1:1:1CT
11
RECEIVE
2CT:1
10
100Base-TX
15
13
12
9
7
1
2
3
TRANSMIT
8
Typical Application Circuit
OUT TO THE
10BASE-T PHY INPUTS
IN- IN+
AVCC
6 5 4 3 2
I/O TO THE CONTROLLER
7
8
9
10
11
12
VCC
13
14
15
16
17
1
2
CMREF
TPINP
TPINN
AVCC2
3
4
6
7
8
16
14
15
1
2
3
4
5
RJ-45
6
7
8
9
10
H1090
10
11
9
ML6692/ML6694
TPOUTP
TPOUTN
24
For More Information:
Pulse Worldwide
Headquarters
12220 World Trade Dr.
San Diego, CA 92128
U.S.A.
www.pulseeng.com
TEL: 858 674 8100
FAX: 858 674 8262
Pulse European
Headquarters
Einsteinstrasse 1
71083 Herrenberg
Germany
TEL: 49 7032 7806 0
FAX: 49 7032 7806 12
Pulse China
Headquarters
No. 1
Industrial District
Changan, Dongguan
China
TEL: 86 769 85538070
FAX: 86 769 85538870
Pulse North China
Room 1503
XinYin Building
No. 888 YiShan Rd.
Shanghai 200233
China
TEL: 86 21 54643211/2
FAX: 86 21 54643210
Pulse South Asia
150 Kampong Ampat
#07-01/02
KA Centre
Singapore 368324
TEL: 65 6287 8998
FAX: 65 6280 0080
Pulse North Asia
No. 26
Kao Ching Rd.
Yang Mei Chen
Taoyuan Hsien
Taiwan, R. O. C.
TEL: 886 3 4641811
FAX: 886 3 4641911
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product
names mentioned herein may be trademarks or registered trademarks of their respective owners.
© Copyright, 2006. Pulse Engineering, Inc. All rights reserved.
