5202UE 008U1000

Description
Multi-Conductor Cables 16AWG 2C STRAND 1000ft BOX GRAY
CategoryWire/cable
File Size187KB,3 Pages
ManufacturerBelden Wire & Cable
Environmental Compliance
Download Datasheet Parametric View All

5202UE 008U1000 Overview

Multi-Conductor Cables 16AWG 2C STRAND 1000ft BOX GRAY

5202UE 008U1000 Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerBelden Wire & Cable
Product CategoryMulti-Conductor Cables
Shipping RestrictionsDue to size or weight of the product, your shipping charge may increase.
RoHSDetails
TypeSound, Security and Alarm
Number of Conductors4 Conductor
Length1000 ft
Wire Gauge - AWG16 AWG
Jacket ColorGray
Outside Diameter4.98 mm
Jacket MaterialPolyvinyl Chloride (PVC)
ShieldingUnshielded
Conductor MaterialCopper
FeaturesApplications include data circuits, monitors, control and initiation circuits
Insulation MaterialPolyvinyl Chloride (PVC)
PackagingBulk
Stranding19 x 29
Voltage Rating300 V
Factory Pack Quantity1
Unit Weight42 lbs
Part Number:
5202UE
Security & Sound, #16-4c, BC, CMR
Product Description
Security & Sound Cable, Riser-CMR, 4-16 AWG stranded bare copper conductors with polyolefin insulation, PVC jacket with ripcord
Technical Specifications
Physical Characteristics (Overall)
Conductor
AWG Stranding
16
19x29
Material
No. of Conductors
BC - Bare Copper 4
4
16 AWG
Conductor Count:
Conductor Size:
Insulation
Material
Nominal Wall Thickness
PP - Polypropylene 0.008 in
Color Chart
Color
Black
Red
White
Green
Outer Shield Material
Material
Unshielded
Outer Jacket Material
Material
Nominal Diameter Nominal Wall Thickness Ripcord
0.017 in
Yes
PVC - Polyvinyl Chloride 0.21 in
Construction and Dimensions
Cabling
Lay Length
3.5 in
Print Legend:
Twists
3.4 twist/ft
NEW GENERATION(R) BY BELDEN-M 5202UE CMR 75C 4C16 (UL) E108998 OR C(UL) CMG (2 FT., 7 DIGIT SEQUENTIAL) FEET
Electrical Characteristics
Conductor DCR
Nominal Conductor DCR
4.2 Ohm/1000ft
Capacitance
Nom. Capacitance Conductor to Conductor
23 pF/ft
Shielding:
Unshielded
