MKE04Z8VTG4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> MKE04Z8VTG4

MKE04Z8VTG4: DescriptionARM Microcontrollers - MCU M0 + 8K FLASH 48MHZ; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，33 Pages; ManufacturerNXP; Websitehttps://www.nxp.com; Environmental Compliance

Download Datasheet Parametric Compare View All

MKE04Z8VTG4 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MKE04Z8VTG4	-	-	View	Buy Now

MKE04Z8VTG4 Overview

ARM Microcontrollers - MCU M0 + 8K FLASH 48MHZ

MKE04Z8VTG4 Parametric

Parameter Name	Attribute value
Brand Name	Freescale
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	TSSOP-16
Reach Compliance Code	compliant
ECCN code	3A991.A.2
Has ADC	YES
Address bus width
maximum clock frequency	24 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PDSO-G16
JESD-609 code	e3
Humidity sensitivity level	3
Number of I/O lines	14
Number of terminals	16
On-chip program ROM width	8
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
RAM (bytes)	1024
rom(word)	8192
ROM programmability	FLASH
speed	48 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	2.7 V
Nominal supply voltage	3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	40
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC
Base Number Matches	1

Preview

Download Datasheet

View All

Freescale Semiconductor

Data Sheet: Technical Data

Document Number MKE04P24M48SF0

Rev 3, 3/2014

KE04 Sub-Family Data Sheet

MKE04P24M48SF0

Supports the following:

MKE04Z8VTG4(R), MKE04Z8VWJ4(R),

and MKE04Z8VFK4(R)

Key features

• Operating characteristics

– Voltage range: 2.7 to 5.5 V

– Flash write voltage range: 2.7 to 5.5 V

– Temperature range (ambient): -40 to 105°C

• Performance

– Up to 48 MHz ARM® Cortex-M0+ core

– Single cycle 32-bit x 32-bit multiplier

– Single cycle I/O access port

• Memories and memory interfaces

– Up to 8 KB flash

– Up to 1 KB RAM

• Clocks

– Oscillator (OSC) - supports 32.768 kHz crystal

or 4 MHz to 24 MHz crystal or ceramic

resonator; choice of low power or high gain

oscillators

– Internal clock source (ICS) - internal FLL with

internal or external reference, 37.5 kHz pre-

trimmed internal reference for 48 MHz system

clock

– Internal 1 kHz low-power oscillator (LPO)

• System peripherals

– Power management module (PMC) with three

power modes: Run, Wait, Stop

– Low-voltage detection (LVD) with reset or

interrupt, selectable trip points

– Watchdog with independent clock source

(WDOG)

– Programmable cyclic redundancy check module

(CRC)

– Serial wire debug interface (SWD)

– Aliased SRAM bitband region (BIT-BAND)

– Bit manipulation engine (BME)

• Security and integrity modules

– 80-bit unique identification (ID) number per chip

• Human-machine interface

– Up to 22 general-purpose input/output (GPIO)

– Two 8-bit keyboard interrupt modules (KBI)

– External interrupt (IRQ)

• Analog modules

– One 12-channel 12-bit SAR ADC, operation in

Stop mode, optional hardware trigger (ADC)

– Two analog comparators containing a 6-bit

DAC and programmable reference input

(ACMP)

• Timers

– One 6-channel FlexTimer/PWM (FTM)

– One 2-channel FlexTimer/PWM (FTM)

– One 2-channel periodic interrupt timer (PIT)

– One pulse width timer (PWT)

– One real-time clock (RTC)

• Communication interfaces

– One SPI module (SPI)

– One UART module (UART)

– One I2C module (I2C)

• Package options

– 24-pin QFN

– 20-pin SOIC

– 16-pin TSSOP

Freescale reserves the right to change the detail specifications as may be

required to permit improvements in the design of its products.

Table of Contents

1 Ordering parts...........................................................................3

1.1 Determining valid orderable parts......................................3

2 Part identification......................................................................3

2.1 Description.........................................................................3

2.2 Format...............................................................................3

2.3 Fields.................................................................................3

2.4 Example............................................................................4

3 Parameter classification............................................................4

4 Ratings......................................................................................4

4.1 Thermal handling ratings...................................................4

4.2 Moisture handling ratings..................................................5

4.3 ESD handling ratings.........................................................5

4.4 Voltage and current operating ratings...............................5

5 General.....................................................................................6

5.1 Nonswitching electrical specifications...............................6

5.1.1

5.1.2

5.1.3

DC characteristics.................................................6

Supply current characteristics...............................13

EMC performance.................................................14

5.2.2

FTM module timing...............................................16

5.3 Thermal specifications.......................................................17

5.3.1

Thermal characteristics.........................................17

6 Peripheral operating requirements and behaviors....................19

6.1 Core modules....................................................................19

6.1.1

SWD electricals ....................................................19

6.2 External oscillator (OSC) and ICS characteristics.............20

6.3 NVM specifications............................................................22

6.4 Analog...............................................................................23

6.4.1

6.4.2

ADC characteristics...............................................23

Analog comparator (ACMP) electricals.................25

6.5 Communication interfaces.................................................26

6.5.1

SPI switching specifications..................................26

7 Dimensions...............................................................................29

7.1 Obtaining package dimensions.........................................29

8 Pinout........................................................................................29

8.1 Signal Multiplexing and Pin Assignments..........................29

8.2 Device pin assignment......................................................31

9 Revision history.........................................................................32

5.2 Switching specifications.....................................................15

5.2.1

Control timing........................................................15

KE04 Sub-Family Data Sheet, Rev3, 3/2014.

Freescale Semiconductor, Inc.

MKE04Z8VTG4 Related Products

	MKE04Z8VTG4	MKE04Z8VWJ4R	MKE04Z8VFK4R	MKE04Z8VTG4R
Description	ARM Microcontrollers - MCU M0 + 8K FLASH 48MHZ	ARM Microcontrollers - MCU Kinetis KE04: 48MHz Cortex-M0+ 5V/Robust MCU, 8KB Flash, 1KB SRAM, 20-SOIC WB	ARM Microcontrollers - MCU MKE04Z8VFK4/HVQFN24///REEL 13 Q2/T3 *STANDARD MAR	ARM Microcontrollers - MCU MKE04Z8VTG4/TSSOP16///REEL13 Q1/T1*STANDARD MARK S
Product Attribute	-	Attribute Value	Attribute Value	Attribute Value
Manufacturer	-	NXP	NXP	NXP
Product Category	-	ARM Microcontrollers - MCU	ARM Microcontrollers - MCU	ARM Microcontrollers - MCU
Mounting Style	-	SMD/SMT	SMD/SMT	SMD/SMT
Core	-	ARM Cortex M0+	ARM Cortex M0+	ARM Cortex M0+
Data Bus Width	-	32 bit	32 bit	32 bit
Maximum Clock Frequency	-	48 MHz	48 MHz	48 MHz
Program Memory Size	-	8 kB	8 kB	8 kB
Data RAM Size	-	1 kB	1 kB	1 kB
ADC Resolution	-	12 bit	12 bit	12 bit
Number of I/Os	-	18 I/O	22 I/O	14 I/O
Operating Supply Voltage	-	2.7 V to 5.5 V	2.7 V to 5.5 V	2.7 V to 5.5 V
Minimum Operating Temperature	-	- 40 C	- 40 C	- 40 C
Maximum Operating Temperature	-	+ 105 C	+ 105 C	+ 105 C
Interface Type	-	I2C, SPI, UART	I2C, SPI, UART	I2C, SPI, UART
Product	-	MCU+DSP	MCU+DSP	MCU+DSP
Program Memory Type	-	Flash	Flash	Flash
Data RAM Type	-	SRAM	SRAM	SRAM
Analog Supply Voltage	-	2.7 V to 5.5 V	2.7 V to 5.5 V	2.7 V to 5.5 V
DAC Resolution	-	6 bit	6 bit	6 bit
Number of ADC Channels	-	10 Channel	12 Channel	6 Channel
Number of Timers/Counters	-	2 x 16 bit, 1 x 32 bit	2 x 16 bit, 1 x 32 bit	2 x 16 bit, 1 x 32 bit
Processor Series	-	KE04	KE04	KE04
Factory Pack Quantity	-	1000	5000	5000
Supply Voltage - Max	-	5.5 V	5.5 V	5.5 V
Supply Voltage - Min	-	2.7 V	2.7 V	2.7 V
Watchdog Timers	-	Watchdog Timer	Watchdog Timer	Watchdog Timer
Unit Weight	-	0.018325 oz	0.000586 oz	0.002194 oz
