LV8860V-TLM-H datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Other integrated circuit (IC)> The signal circuit> LV8860V-TLM-H

LV8860V-TLM-H: DescriptionMotor / Motion / Ignition Controllers & Drivers BRUSHLESS MOTOR Drvr; CategoryOther integrated circuit (IC) The signal circuit; File Size152KB，1 Pages; ManufacturerON Semiconductor; Websitehttp://www.onsemi.cn

Download Datasheet Parametric View All

LV8860V-TLM-H Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	LV8860V-TLM-H	-	-	View	Buy Now

LV8860V-TLM-H Overview

Motor / Motion / Ignition Controllers & Drivers BRUSHLESS MOTOR Drvr

LV8860V-TLM-H Parametric

Parameter Name	Attribute value
Brand Name	ON Semiconductor
Is it lead-free?	Lead free
package instruction	LSSOP, SSOP16,.25
Contacts	16
Manufacturer packaging code	565AM
Reach Compliance Code	compliant
Factory Lead Time	16 weeks
Other features	ALSO OPERATES IN 6 TO 34V SUPPLY
Analog Integrated Circuits - Other Types	BRUSH DC MOTOR CONTROLLER
JESD-30 code	R-PDSO-G16
JESD-609 code	e6
length	5.2 mm
Humidity sensitivity level	3
Number of functions	1
Number of terminals	16
Maximum operating temperature	95 °C
Minimum operating temperature	-40 °C
Maximum output current	0.7 A
Package body material	PLASTIC/EPOXY
encapsulated code	LSSOP
Encapsulate equivalent code	SSOP16,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	24 V
Certification status	Not Qualified
Maximum seat height	1.5 mm
Maximum supply current (Isup)	3.5 mA
Maximum supply voltage (Vsup)	34 V
Minimum supply voltage (Vsup)	7 V
Nominal supply voltage (Vsup)	24 V
surface mount	YES
technology	BICMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Bismuth (Sn/Bi)
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	4.4 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Product Overview

LV8860V: Motor Driver, Single-Phase, PWM, Full-Wave, Brushless

For complete documentation, see the data sheet.

LV8860V is a driver IC used for single-phase fan motor. High-efficiency and low-noise are realized by reducing reactive power using

Silent PWM. The operating range of LV8860V is wide. LV8860V also corresponds to 24V. Therefore, it is optimal for office

automation equipment and factory automation equipment.

Features

•

Speed is controllable by PWM input.

Hall bias output pin.

Integrated Quick Start Circuit.

FG (rotation detection) / RD (lock detection) output pin (open

drain output)

Integrated current limiter circuit (limit at IO=450mA with

Rf=0.5 connection, limit value is determined based on Rf.)

Integrated lock protector circuit and automatic recovery

circuit.

Integrated thermal shut-down (TSD) circuit.

Single-phase full wave operation by Silent PWM drive.

Benefits

•

High-efficiency and low-noise, Easy speed control

Hall bias

Quick Start

Easy speed control

• Current limit protection

• Lock protection

• Thermal protection

Applications

• Industrial

• Computing & Peripherals

End Products

•

Printers

Vending Machine

Desktop Computor

Cooling FAN for OA equipment

FA equipment

Part Electrical Specifications

Product

LV8860V-TLM-H

Compliance

Pb-free

Halide free

Status

Active

Phase

Min (V) V

Max

(V)

Min

(V)

Max

(V)

Max (A)

Peak

Max (A)

0.7

Control

Type

PWM

Package

Type

SSOP-16

For more information please contact your local sales support at www.onsemi.com.

Created on: 10/22/2018
