BAT81S, BAT82S, BAT83S
www.vishay.com
Vishay Semiconductors
Small Signal Schottky Diode
FEATURES
• Integrated protection ring against static
discharge
• Low capacitance
• Low leakage current
• Low forward voltage drop
• Very low switching time
• AEC-Q101 qualified
• Material categorization: for definitions of
compliance please see
www.vishay.com/doc?99912
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
APPLICATIONS
•
•
•
•
•
•
•
General purpose and switching Schottky barrier diode
HF-detector
Protection circuit
Diode for low currents with a low supply voltage
Small battery charger
Power supplies
DC/DC converter for notebooks
MECHANICAL DATA
Case:
DO-35 (DO-204AH)
Weight:
approx. 125 mg
Cathode band color:
black
Packaging codes/options:
TR/10K per 13" reel (52 mm tape), 50K/box
TAP/10K per ammopack (52 mm tape), 50K/box
PARTS TABLE
PART
BAT81S
BAT82S
BAT83S
TYPE
DIFFERENTIATION
V
R
= 40 V
V
R
= 50 V
V
R
= 60 V
ORDERING CODE
BAT81S-TR or BAT81S-TAP
BAT82S-TR or BAT82S-TAP
BAT83S-TR or BAT83S-TAP
CIRCUIT
CONFIGURATION
Single
Single
Single
TYPE MARKING
BAT81S
BAT82S
BAT83S
REMARKS
Tape and reel/ammopack
Tape and reel/ammopack
Tape and reel/ammopack
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Reverse voltage
Forward continuous current
Peak forward surge current
Repetitive peak forward current
TEST CONDITION
PART
BAT81S
BAT82S
BAT83S
SYMBOL
V
R
V
R
V
R
I
F
I
FSM
I
FRM
VALUE
40
50
60
30
500
150
UNIT
V
V
V
mA
mA
mA
t
p
≤
10 ms
t
p
≤
1 s
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Thermal resistance junction to ambient air
Junction temperature
Storage temperature range
TEST CONDITION
I = 4 mm, T
L
= constant
SYMBOL
R
thJA
T
j
T
stg
VALUE
320
125
-65 to +150
UNIT
K/W
°C
°C
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Forward voltage
Reverse current
Diode capacitance
TEST CONDITION
I
F
= 0.1 mA
I
F
= 1 mA
I
F
= 15 mA
V
R
= V
Rmax.
V
R
= 1 V, f = 1 MHz
SYMBOL
V
F
V
F
V
F
I
R
C
D
MIN.
TYP.
MAX.
330
410
1000
200
1.6
UNIT
mV
mV
mV
nA
pF
Rev. 2.0, 04-Apr-17
Document Number: 85512
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAT81S, BAT82S, BAT83S
www.vishay.com
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
P
R
- Reverse Power Dissipation (mW)
14
V
R
= 60
V
1000
Vishay Semiconductors
I
F
- Forward Current (mA)
12
R
thJA
= 540 K/W
10
8
6
P
R
Limit
at 100
V
V
P
R
- Limit
at 100 %
%
R
R
4
P
R
- Limit at 80 %
V
R
2
0
25
50
75
100
125
150
100
T
j
= 125 °C
10
T
j
= 25 °C
1
0.1
0.01
0
15796
0.5
1
1.5
2.0
15794
T
j
- Junction Temperature (°C)
V
F
- Forward
Voltage
(V)
Fig. 1 -
Max. Reverse Power Dissipation vs.
Junction Temperature
1000
Fig. 3 -
Forward Current vs. Forward Voltage
2.0
C
D
- Diode Capacitance (pF)
V
R
=
V
RRM
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
f = 1 MHz
I
R
- Reverse Current (µA)
100
10
1
0.1
25
15795
0
50
75
100
125
150
15797
0.1
1
10
100
T
j
- Junction Temperature (°C)
V
R
- Reverse
Voltage
(V)
Fig. 2 -
Reverse Current vs. Junction Temperature
Fig. 4 -
Diode Capacitance vs. Reverse Voltage
PACKAGE DIMENSIONS
in millimeters (inches):
DO-35 (DO-204AH)
Cathode Identification
Ø 0.6 max. [0.024]
Ø 0.4 min. [0.015]
1.7 [0.067]
26 min. [1.024]
3.9 max. [0.154]
3.1 min. [0.120]
26 min. [1.024]
Rev. 6 - Date: 19. December 2011
Document no.: SB-V-3906.04-031(4)
94 9366
Rev. 2.0, 04-Apr-17
Document Number: 85512
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
1.3 [0.050]
