This document was generated on 06/10/2011
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0760480002
Active
sfp_stacked_multiport_connectors
Small Form-factor Pluggable Plus (SFP+) Stacked 2-by-6 Multi-Port Connector with 2
Inner Lightpipe Ports, EMI Metal Gasket, 240 Circuits, Tin (Sn)/Lead(Pb) Tails
Documents:
3D Model
Drawing (PDF)
Product Specification PS-75310-001 (PDF)
Application Specification AS-75310-001 (PDF)
Packaging Specification PK-75451-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
EU RoHS
RoHS Compliant by
Exemption
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Low-Halogen
China RoHS
Agency Certification
CSA
UL
LR19980
E29179
General
Product Family
Series
Application
Component Type
Overview
Product Name
Type
I/O Connectors
76048
Module-to-Board
Receptacle
sfp_stacked_multiport_connectors
SFP Plus
N/A
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Boot Color
Circuits (Loaded)
Circuits (maximum)
Circuits Detail
Color - Resin
Durability (mating cycles max)
Flammability
Gender
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Ports
Surface Mount Compatible (SMC)
Temperature Range - Operating
N/A
240
240
240
Black, Clear (Blue Tint)
100
94V-0
Female
None
Yes
High Performance Alloy (HPA)
Gold
Tin-Lead
High Temperature Thermoplastic, Polycarbonate
2
Right Angle
2.07mm (.081")
Yes
Yes
1.57mm (.062")
Tray
No
0.80mm (.031")
0.80mm (.031")
0.762µm (30µ")
0.762µm (30µ")
Yes
Yes
12
No
-40°C to +85°C
Search Parts in this Series
76048Series
Use With
0759510999 SFP Dust Plug,
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
2-by-6 SFP Stacked 0622030155
Multi-Port Insertion
Tool
SFP Stacked Multi- 0622029950
Port Extraction Tool,
2 by 6
Termination Interface: Style
Waterproof / Dustproof
Through Hole - Compliant Pin
No
Electrical
Current - Maximum per Contact
Grounding to Panel
Shield Type
Shielded
Voltage - Maximum
0.5A
None
EMI Gasket
Yes
120V AC (RMS)/DC
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
AS-75310-001
PK-75451-001
PS-75310-001
SD-76048-001
This document was generated on 06/10/2011
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
