• Case sizes through 0.709" x 1.417" [18.0 mm x 36.0 mm]
• Optional third lead on diameters
0.492" [12.5 mm]
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
QUICK REFERENCE DATA
DESCRIPTION
Nominal case size
Ø D x L in mm
Operating temperature
Rated capacitance range, C
R
Tolerance on C
R
Rated voltage range, U
R
Termination
VALUE
0.236" x 0.433" [6.0 x 11.0]
to 0.709" x 1.417" [18.0 x 36.0]
-40 °C to +125 °C
1.0 μF to 6800 μF
± 20 %
6.3 WV
DC
to 63 WV
DC
2 and 3 radial leads
2000 h:
CAP
15 %
(6.3 WV
DC
to 10 WV
DC
),
10 % (16 WV
DC
to 63 WV
DC
)
from initial measurement.
DF
1.25 x initial specified limit.
DCL
initial specified limit.
500 h:
CAP
12 % from
initial measurement.
DF
1.25 x initial specified limit.
DCL
2.0 x initial specified limit.
I = 0.01 CV
I in μA, C in μF, V in Volts
RIPPLE CURRENT MULTIPLIERS
TEMPERATURE
AMBIENT TEMPERATURE
MULTIPLIERS
+125 °C
0.4
+105 °C
1.0
+85 °C
1.41
+75 °C
1.58
+65 °C
,1.73
FREQUENCY (Hz)
FREQUENCY (Hz) 50 TO 60 100 TO 120 300 TO 400 1K AND UP
0.85
1.00
1.05
1.10
MULTIPLIERS
0.80
1.00
1.30
1.40
LOW TEMPERATURE PERFORMANCE
CAPACITANCE RATIO C
-55 °C
/ C
+25 °C
MINIMUM AT 120 Hz
RATED VOLTAGE (WV
DC
)
CAPACITANCE REMAINING
6.3 to 10
75 %
16 to 25
80 %
36 to 63
85 %
-55 °C
/ ESR
+25 °C
MAXIMUM AT 120 Hz
ESR RATIO ESR
MULTIPLIER
RATED VOLTAGE (WV
DC
)
6.3 to 10
35
16 to 25
30
36 to 63
25
Life validation test at 125 °C
Shelf life at 105 °C
DC leakage current
(after 2 min charge)
DIMENSIONS
in inches [millimeters]
CASE
CODE
BB
BD
CC
CG
DG
DK
EN
ER
FR
NOMINAL
D
0.315 [8.0]
0.315 [8.0]
0.394 [10.0]
0.394 [10.0]
0.492 [12.5]
0.492 [12.5]
0.630 [16.0]
0.630 [16.0]
0.709 [18.0]
L
0.472 [12.0]
0.630 [16.0]
0.512 [13.0]
0.787 [20.0]
0.787 [20.0]
0.984 [25.0]
1.260 [32.0]
1.417 [36.0]
1.417 [36.0]
STYLES 2 AND 4
D (max.)
0.335 [8.5]
0.335 [8.5]
0.413 [10.5]
0.413 [10.5]
0.512 [13.0]
0.512 [13.0]
0.650 [16.5]
0.650 [16.5]
0.728 [18.5]
L (max.)
0.512 [13.0]
0.669 [17.0]
0.563 [14.3]
0.846 [21.5]
0.846 [21.5]
1.043 [26.5]
1.319 [33.5]
1.476 [37.5]
1.476 [37.5]
STYLES 3 AND 5
D (max.)
0.335 [8.5]
0.335 [8.5]
0.413 [10.5]
0.413 [10.5]
0.512 [13.0]
0.512 [13.0]
0.650 [16.5]
0.650 [16.5]
0.728 [18.5]
L (max.)
0.551 [14.0]
0.709 [18.0]
0.630 [16.0]
0.906 [23.0]
0.906 [23.0]
1.142 [29.0]
1.417 [36.0]
1.575 [40.0]
1.575 [40.0]
LEAD SPACING
S ± 0.024
[0.60]
0.138 [3.5]
0.138 [3.5]
0.197 [5.0]
0.197 [5.0]
0.197 [5.0]
0.197 [5.0]
0.295 [7.5]
0.295 [7.5]
0.295 [7.5]
T ± 0.020
[0.50]
n/a
n/a
n/a
n/a
0.098 [2.5]
0.098 [2.5]
0.150 [3.8]
0.150 [3.8]
0.150 [3.8]
LEAD DIAMETER
NOMINAL
0.025 [0.63]
0.025 [0.63]
0.025 [0.63]
0.025 [0.63]
0.028 [0.71]
0.032 [0.81]
0.032 [0.81]
0.032 [0.81]
0.032 [0.81]
AWG
NO.
22
22
22
22
20
20
20
20
20
Revision: 18-Jul-16
Document Number: 42050
1
For technical questions, contact:
aluminumcaps4@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
510DX
www.vishay.com
DIMENSIONS
in inches [millimeters]
AND AVAILABLE FORMS
Formed Leads
P
Vishay Sprague
K
H
F
H
0
W
0
W
L
1
P
0
d
D
0
DIMENSIONS
in inches [millimeters]
AND PACKAGING QUANTITIES
CASE SIZE
0.236 x 0.433 [6.0 x 11.0]
0.315 x 0.472 [8.0 x 12.0]
F LEAD SPACING
0.197 [5.0]
0.197 [5.0]
STD. QTY/REEL
800
700
Unformed (Straight) Leads
P
H
F
W
0
W
L
1
P
0
d
D
0
f
DIMENSIONS
in inches [millimeters]
AND PACKAGING QUANTITIES
CASE SIZE
0.236 x 0.433 [6.0 x 11.0]
0.315 x 0.472 [8.0 x 12.0]
0.394 x 0.512 [10.0 x 13.0]
0.394 x 0.630 [10.0 x 16.0]
0.394 x 0.787 [10.0 x 20.0]
Note
(1)
Available as special order.
F LEAD SPACING
0.098 [2.5]
(1)
0.140 [3.5]
(1)
STD. QTY/REEL
800
700
500
500
500
0.197 [5.0]
0.197 [5.0]
0.197 [5.0]
Revision: 18-Jul-16
Document Number: 42050
2
For technical questions, contact:
aluminumcaps4@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
510DX
www.vishay.com
Vishay Sprague
CASE SIZE (Diameter x Length)
0.315 x 0.472
0.394 x 0.512
0.394 x 0.630
[8.0 x 12.0]
[10.0 x 13.0]
[10.0 x 16.0]
0.025 [0.63]
0.025 [0.63]
0.025 [0.63]
0.500 [12.7]
0.500 [12.7]
0.500 [12.7]
0.500 [12.7]
0.500 [12.7]
0.500 [12.7]
0.197 [5.0]
0.197 [5.0]
0.197 [5.0]
0.157 [4.0]
n/a
n/a
0.787 [20.0]
0.906 [23.0]
0.906 [23.0]
0.630 [16.0]
n/a
n/a
0.709 [18.0]
0.709 [18.0]
0.709 [18.0]
0.591 [15.0]
0.591 [15.0]
0.591 [15.0]
0.157 [4.0]
0.157 [4.0]
0.157 [4.0]
0.028 [0.7]
0.028 [0.7]
0.028 [0.7]
0.118 [3.0]
0.118 [3.0]
0.118 [3.0]
DIMENSIONS
in inches [millimeters]
ITEM
d - Lead-wire diameter
P - Pitch of component
P
0
- Feed hole pitch
F - Lead-to-lead distance
K - Clinch height
H - Height of component from tape center
H
0
- Lead-wire clinch height
W - Tape width
W
0
- Hold down tape width
D
0
- Feed hole diameter
t - Total tape thickness
L
1
- Maximum lead protrusion
0.236 x 0.433
[6.0 x 11.0]
0.025 [0.63]
0.500 [12.7]
0.500 [12.7]
0.197 [5.0]
0.098 [2.5]
0.728 [18.5]
0.630 [16.0]
0.709 [18.0]
0.591 [15.0]
0.157 [4.0]
0.028 [0.7]
0.118 [3.0]
0.394 x 0.787
[10.0 x 20.0]
0.025 [0.63]
0.500 [12.7]
0.500 [12.7]
0.197 [5.0]
n/a
0.906 [23.0]
n/a
0.709 [18.0]
0.591 [15.0]
0.157 [4.0]
0.028 [0.7]
0.118 [3.0]
Note
• Positive leader is standard. Negative leader is available by special order.
ORDERING EXAMPLE
Electrolytic capacitor 510DX series: 510DX 227 M 050 DG 2 D
DESCRIPTION
CODE
510DX
227
M
050
DG
2
D
EXPLANATION
Product type
Capacitance value (220 μF)
Tolerance (M = ± 20 %)
Voltage rating at 105 °C (050 = 50 V)
Can size (see “Dimensions” table)
Sleeve and sealing (2 = polyester sleeve)
Packaging (D = bulk; straight leads)
Note
• For lead (Pb)-free / RoHS compliant products add suffix “E3” to part number.
Example: 510DX227M050DG2DE3
ELECTRICAL DATA AND ORDERING INFORMATION
CAPACITANCE
(μF)
PART NUMBER
(1)
NOMINAL CASE SIZE
DxL
IN INCHES (mm)
MAX. ESR
AT +25 °C (m)
MAX. RIPPLE
AT +105 °C (A)
MAX. Z
AT +25 °C
(m)
100 Hz
457.0
181.0
121.0
36.0
854.0
475.0
124.0
33.0
494.0
194.0
39.0
120 Hz 20 kHz TO 40 kHz 120 Hz 20 kHz TO 40 kHz
0.294
0.697
0.931
2.193
0.182
0.247
0.911
2.582
0.255
0.654
2.060
0.454
0.984
1.313
3.193
0.278
0.417
1.287
3.576
0.409
0.946
3.078
330.0
1000.0
1500.0
4700.0
150.0
220.0
1200.0
4700.0
150.0
470.0
2200.0
510DX337M6R3CC2D
510DX108M6R3DG2D
510DX158M6R3DK2D
510DX478M6R3ER2D
510DX157M010BB2D
510DX227M010BD2D
510DX128M010DK2D
510DX478M010FR2D
510DX157M016BD2D
510DX477M016DG2D
510DX228M016ER2D
6.3 WV
DC
AT 125 °C, SURGE = 8 V
0.394 x 0.512 [10.0 x 13.0] 1206.0
507.0
0.492 x 0.787 [12.5 x 20.0] 398.0
201.0
0.492 x 0.984 [12.5 x 25.0] 265.0
133.0
0.630 x 1.417 [16.0 x 36.0]
85.0
40.0
10 WV
DC
AT 125 °C, SURGE = 13 V
0.315 x 0.472 [8.0 x 12.0] 2210.0
948.0
0.315 x 0.630 [8.0 x 16.0] 1507.0
528.0
0.492 x 0.984 [12.5 x 25.0] 276.0
138.0
0.709 x 1.417[18.0 x 36.0]
71.0
37.0
16 WV
DC
AT 125 °C, SURGE = 20 V
0.315 x 0.630 [8.0 x 16.0] 1415.0
549.0
0.492 x 0.787 [12.5 x 20.0] 451.0
216.0
0.630 x 1.417 [16.0 x 36.0]
96.0
43.0
Revision: 18-Jul-16
Document Number: 42050
3
For technical questions, contact:
aluminumcaps4@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
510DX
www.vishay.com
Vishay Sprague
MAX. ESR
AT +25 °C (m)
MAX. RIPPLE
AT +105 °C (A)
MAX. Z
AT +25 °C
(m)
100 Hz
ELECTRICAL DATA AND ORDERING INFORMATION
CAPACITANCE
(μF)
PART NUMBER
(1)
NOMINAL CASE SIZE
DxL
IN INCHES (mm)
120 Hz 20 kHz TO 40 kHz 120 Hz 20 kHz TO 40 kHz
25 WV
DC
AT 125 °C, SURGE = 32 V
100.0
100.0
330.0
470.0
1500.0
510DX107M025BD2D
510DX107M025CC2D
510DX337M025DG2D
510DX477M025DK2D
510DX158M025ER2D
0.315 x 0.630 [8.0 x 16.0]
0.394 x 0.512 [10.0 x 13.0]
0.492 x 0.787 [12.5 x 20.0]
0.492 x 0.984 [12.5 x 25.0]
0.630 x 1.417 [16.0 x 36.0]
1459.0
1459.0
442.0
310.0
97.0
571.0
571.0
224.0
150.0
45.0
0.251
0.268
0.661
0.859
2.049
0.401
0.428
0.927
1.238
3.009
514.0
514.0
202.0
135.0
40.0
35 WV
DC
AT 125 °C, SURGE = 44 V
47.0
100.0
220.0
470.0
1200.0
1500.0
510DX476M035BB2D
510DX107M035CC2D
510DX227M035CG2D
510DX477M035DK2D
510DX128M035EN2D
510DX158M035ER2D
0.315 x 0.472 [8.0 x 12.0]
0.394 x 0.512 [10.0 x 13.0]
0.394 x 0.787 [10.0 x 20.0]
0.492 x 0.984 [12.5 x 25.0]
0.630 x 1.260 [16.0 x 32.0]
0.630 x 1.417 [16.0 x 36.0]
2822.0
1326.0
603.0
282.0
111.0
88.0
1067.0
593.0
248.0
156.0
58.0
47.0
0.161
0.281
0.496
0.901
1.826
2.151
0.262
0.421
0.774
1.214
2.527
2.944
960.0
534.0
223.0
140.0
52.0
42.0
50 WV
DC
AT 125 °C, SURGE = 63 V
220.0
330.0
1000.0
510DX227M050DG2D
510DX337M050DK2D
510DX108M050ER2D
0.492 x 0.787 [12.5 x 20.0]
0.492 x 0.984 [12.5 x 25.0]
0.630 x 1.417 [16.0 x 36.0]
543.0
362.0
119.0
243.0
162.0
49.0
0.597
0.796
1.847
0.892
1.191
2.883
218.0
146.0
44.0
63 WV
DC
AT 125 °C, SURGE = 79 V
47.0
47.0
220.0
1000.0
Statements about product lifetime are based on calculations and internal testing. They should only be interpreted as estimations. Also due to external factors, the
lifetime in the field application may deviate from the calculated lifetime. In general, nothing stated herein shall be construed as a guarantee of durability.
510DX476M063BD2D
510DX476M063CC2D
510DX227M063DK2D
510DX108M063FR2D
0.315 x 0.630 [8.0 x 16.0]
0.394 x 0.512 [10.0 x 13.0]
0.492 x 0.984 [12.5 x 25.0]
0.709 x 1.417 [18.0 x 36.0]
1975.0
1975.0
422.0
93.0
642.0
642.0
168.0
45.0
0.215
0.231
0.737
2.256
0.378
0.404
1.167
3.243
578.0
578.0
151.0
41.0
Revision: 18-Jul-16
Document Number: 42050
4
For technical questions, contact:
aluminumcaps4@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Legal Disclaimer Notice
www.vishay.com
Vishay
Disclaimer
ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively,
“Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other
disclosure relating to any product.
Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or
the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all
liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special,
consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular
purpose, non-infringement and merchantability.
Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of
typical requirements that are often placed on Vishay products in generic applications. Such statements are not binding
statements about the suitability of products for a particular application. It is the customer’s responsibility to validate that a
particular product with the properties described in the product specification is suitable for use in a particular application.
Parameters provided in datasheets and / or specifications may vary in different applications and performance may vary over
time. All operating parameters, including typical parameters, must be validated for each customer application by the customer’s
technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase,
including but not limited to the warranty expressed therein.
Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining
applications or for any other application in which the failure of the Vishay product could result in personal injury or death.
Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk.
Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for
such applications.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document
or by any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners.
京公网安备 11010802033920号
EEWORLD
