IHLD-4032KB-5A
www.vishay.com
Vishay Dale
Low Profile, High Current Dual Inductors
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
Two inductors in one package
High temperature, up to 155 °C
Shielded construction
Optimal design realizes high quality sound and
low distortion
Low coupling for minimal cross-talk between
inductors
Frequency range up to 1 MHz
Lowest DCR/μH, in this package size
Handles high transient current spikes without saturation
Ultra-low buzz noise, due to composite construction
AEC-Q200 qualified
IHLP design. PATENT(S):
www.vishay.com/patents
Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DESIGN SUPPORT TOOLS
click logo to get started
Design Tools
Available
STANDARD ELECTRICAL SPECIFICATIONS
L
0
INDUCTANCE
± 20 % AT
100 kHz,
0.25 V, 0 A
(μH)
10
15
22
33
DCR
TYP.
25 °C
(m)
30.5
43.5
67.8
100
DCR
MAX.
25 °C
(m)
32.6
45.5
72.5
107.0
HEAT
RATING SATURATION
CURRENT CURRENT
SRF
DC TYP.
DC TYP.
TYP.
(A)
(1)
(A)
(2)
(MHz)
5.6
4.6
4.1
3.8
7.4
5.5
4.1
3.7
10.2
9.5
7
6
APPLICATIONS
• Class D audio amplifiers
DIMENSIONS
in inches [millimeters]
0.440 ± 0.005
(11.2 ± 0.127)
0.379 ± 0.010
(9.624 ± 0.254)
0.342 ± 0.010
(8.69 ± 0.254)
0.111 ± 0.005
(2.808 ± 0.127)
0.080 ± 0.005
(2.042 ± 0.127)
RECOMMENDED PAD LAYOUT
0.118 (3.00)
0.130 (3.30)
0.060 (1.52)
0.468 ± 0.010
(11.896 ± 0.254)
Notes
• All test data is referenced to 25 °C ambient
• Operating temperature range -55 °C to +155 °C
• The part temperature (ambient + temp. rise) should not exceed
155 °C under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow
and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application
• Rated operating voltage (across inductor) = 50 V
(1)
DC current (A) that will cause an approximate
T
of 40 °C
(2)
DC current (A) that will cause L to drop approximately 20 %
0
0.131 (3.33)
0.380 (9.65)
DESCRIPTION
IHLD-4032KB-5A
MODEL
22 μH
INDUCTANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
JEDEC
®
e3
LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
H
L
D
4
0
3
SIZE
2
K
B
E
R
2
2
INDUCTANCE
VALUE
0
M
TOL.
5
A
PRODUCT FAMILY
PACKAGE
CODE
SERIES
PATENT(S):
www.vishay.com/patents
This Vishay product is protected by one or more United States and international patents.
Revision: 20-Oct-17
Document Number: 34381
