Part Number:
Status:
Overview:
Description:
0460123241
Active
Mini-Fit Plus Connector System
Mini-Fit Plus Crimp Terminal, 16 AWG, Reel, Selective Gold (Au) Plating 0.76µm
Documents:
Drawing (PDF)
Product Specification PS-45750-001-001 (PDF)
General
Product Family
Series
Application
Comments
Packaging Specification PK-46012-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Crimp Quality Equipment
Current Released Drawing
Current Released Revision
Data Load Status
Made From
Overview
Packaging Alternative
Product Name
UPC
Physical
Durability (mating cycles max)
Gender
Material - Metal
Material - Plating Mating
Material - Plating Termination
Net Weight
Packaging Type
Plating min - Mating
Plating min - Termination
Termination Interface: Style
Wire Insulation Diameter
Wire Size AWG
Wire Size mm²
Electrical
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Lead-freeProcess Capability
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
Crimp Terminals
46012
Power
Current = 13A max. per circuit when header is mated
to a receptacle loaded with 45750 series terminals
crimped to 16 AWG wire. . See Molex product
specification PS-45750-001 for additional current de-
rating information.
Yes
E-46012-001
E
Data Bulk Loaded from Saqqara
0460123999
Mini-Fit Plus Connector System
46012-3242 (Loose)
Mini-Fit Plus
822350570497
250
Male
Copper
Gold
Tin
0.144/g
Reel
0.762µm
2.540µm
Crimp or Compression
2.20-3.15mm
16
N/A
13.0A
600V
N/A
Search Parts in this Series
46012 Series
Mates With
45750 Mini-Fit Plus Crimp Terminal
Use With
5559 Mini-Fit Jr. Plugs, 42475 Mini-Fit MBI
Panel Mount Plugs, 30068 Mini-Fit TPA
Plugs
PK-46012-001
PS-45750-001-001
SD-46012-001-001
