MAX5956AEEE+T Overview

Hot Swap Voltage Controllers Dual Hot-Swap Controller

MAX5956AEEE+T Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	SSOP
package instruction	SSOP, SSOP16,.25
Contacts	16
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	7 weeks
Adjustable threshold	YES
Analog Integrated Circuits - Other Types	POWER SUPPLY SUPPORT CIRCUIT
JESD-30 code	R-PDSO-G16
JESD-609 code	e3
length	4.89 mm
Humidity sensitivity level	1
Number of channels	2
Number of functions	1
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Encapsulate equivalent code	SSOP16,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
power supply	1/13.2 V
Certification status	Not Qualified
Maximum seat height	1.73 mm
Maximum supply current (Isup)	2.3 mA
Maximum supply voltage (Vsup)	13.2 V
Minimum supply voltage (Vsup)	1 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	BICMOS
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	0.635 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3.9 mm
Base Number Matches	1

Preview

Download Datasheet

View All

19-3813; Rev 0; 9/05

KIT

ATION

EVALU

BLE

AVAILA

Low-Voltage, Dual Hot-Swap

Controllers with Independent On/Off Control

General Description

Features

Safe Hot Swap for +1V to +13.2V Power Supplies

with V

IN1

or V

IN2

≥ 2.7V

Independent On/Off Control for Each Channel

Internal Charge Pumps Generate n-Channel

MOSFET Gate Drives

Inrush Current Regulated at Startup

Circuit-Breaker Function

Adjustable Circuit Breaker/Current-Limit

Threshold from 25mV to 100mV

VariableSpeed/BiLevel Circuit Breaker Response

Autoretry or Latched Fault Management

Status Outputs Indicate Fault/Safe Condition

Output Undervoltage and Overvoltage Monitoring

or Protection

MAX5955/MAX5956

The MAX5955 and MAX5956 are +1V to +13.2V dual

hot-swap controllers with independent on/off control for

complete protection of dual-supply systems. They allow

the safe insertion and removal of circuit cards into live

backplanes. The MAX5955 and MAX5956 operate

down to 1V provided one of the inputs is above 2.7V.

The discharged filter capacitors of the circuit card pro-

vide low impedance to the live backplane. High inrush

currents from the backplane to the circuit card can burn

up connectors and components, or momentarily collapse

the backplane power supply leading to a system reset.

The MAX5955 and MAX5956 hot-swap controllers pre-

vent such problems by gradually ramping up the output

voltage and regulating the current to a preset limit when

the board is plugged in, allowing the system to stabilize

safely. After the startup cycle is completed, two on-chip

comparators provide VariableSpeed/BiLevel™ protection

against short-circuit and overcurrent faults, as well as

immunity against system noise and load transients. In the

event of a fault condition, the load is disconnected. The

MAX5955B and MAX5956B must be unlatched after a

fault, and the MAX5955A and MAX5956A automatically

restart after a fault.

The MAX5955 and MAX5956 integrate an on-board

charge pump to drive the gates of low-cost, external n-

channel MOSFETs. The devices offer integrated fea-

tures like startup current regulation and current glitch

protection to eliminate external timing resistors and

capacitors. These devices provide open-drain status

outputs, an adjustable startup timer, and adjustable

current limits. The MAX5955 provides output undervolt-

age/overvoltage protection for each channel, while the

MAX5956 provides undervoltage/overvoltage monitor-

ing for each channel.

The MAX5955 and MAX5956 are available in a space-

saving 16-pin QSOP package.

Ordering Information

PART

MAX5955AEEE

MAX5955AEEE+

MAX5955AUEE

MAX5955AUEE+

MAX5955BEEE

MAX5955BEEE+

MAX5955BUEE

MAX5955BUEE+

TEMP RANGE

-40°C to +85°C

0°C to +85°C

-40°C to +85°C

0°C to +85°C

PIN-PACKAGE

16 QSOP

+Denotes

lead-free package.

Ordering Information continued at end of data sheet.

Selector Guide and Typical Operating Circuit appear at end

of data sheet.

Pin Configuration

TOP VIEW

PGOOD1 1

TIM 2

IN1 3

SENSE1 4

GATE1 5

GND 6

LIM1 7

MON1 8

16 PGOOD2

15 ON2

14 IN2

Applications

Base Station Line Cards

Network Switches,

Routers, Hubs

Solid-State Circuit

Breakers

RAID

Power-Supply Sequencing

Hot Plug-In Daughter

Cards

Portable Computer Device

Bays (Docking Stations)

MAX5955

MAX5956

13 SENSE2

12 GATE2

11 ON1

10 LIM2

MON2

Variable Speed/BiLevel is a trademark of Maxim Integrated

Products, Inc.

QSOP

________________________________________________________________

Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at

1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
