BR1005 thru BR104
Silicon Bridge
Rectifier
Features
• Types up to 1000 V V
RRM
• Low forward voltage drop
• Low leakage current
BR-10 Package
V
RRM
= 50 V - 1000 V
I
F
=10 A
Mechanical Data
Case: Molded plastic body
Polarity: Marked on body
Mounting position: Any
Mounting: Hole for number 6 screw
Maximum ratings, at T
j
= 25 °C, unless otherwise specified
Parameter
p
peak reverse voltage
g
Repetitive p
RMS reverse voltage
DC blocking voltage
Continuous forward current
Surge non-repetitive forward
current, Half Sine Wave
Operating temperature
Storage temperature
Symbol
V
RRM
V
RMS
V
DC
I
F
I
F,SM
T
j
T
stg
T
C
≤
50 °C
T
C
= 25 °C, t
p
= 8.3 ms
Conditions
BR1005
50
35
50
10
150
-65 to 150
-65 to 150
BR101
100
70
100
10
150
-65 to 150
-65 to 150
BR102
200
140
200
10
150
-65 to 150
-65 to 150
BR104
400
280
400
10
150
-65 to 150
-65 to 150
Unit
V
V
V
A
A
°C
°C
Electrical characteristics, at Tj = 25 °C, unless otherwise specified
Parameter
Diode forward voltage
Reverse current
Symbol
V
F
I
R
Conditions
I
F
= 5 A, T
j
= 25 °C
V
R
= 50 V, T
j
= 25 °C
V
R
= 50 V, T
j
= 100 °C
BR1005
1.1
10
1000
9.40
BR101
1.1
10
1000
9.40
BR102
1.1
10
1000
9.40
BR104
1.1
10
1000
9.40
Unit
V
μA
Thermal characteristics
Thermal resistance, junction -
case
R
thJC
°C/W
www.genesicsemi.com
1
