product family. Using the ultra-high density propri-
etary TrenchDMOS technology, this product
demonstrates high power handling and small size.
AAT7126
Features
•
•
•
V
DS(MAX)
= 30V
I
D(MAX)
1
= 6.8A @ 25°C
Low R
DS(ON)
:
• 26 mΩ @V
GS
= 10V
• 41 mΩ @ V
GS
= 4.5V
Applications
•
•
•
•
Battery-powered portable equipment
Laptop computers
Desktop computers
DC/DC converters
Dual SOP-8 Package
Preliminary Information
Top View
D1
8
D1
7
D2
6
D2
5
1
S1
2
G1
3
S2
4
G2
Absolute Maximum Ratings
Symbol
V
DS
V
GS
I
D
I
DM
I
S
P
D
T
J
, T
STG
(T
A
=25°C unless otherwise noted)
Value
30
±20
±6.8
±5.4
±24
1.7
2.0
1.25
-55 to 150
Description
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current @ T
J
=150°C
1
Units
V
T
A
= 25°C
T
A
= 70°C
Pulsed Drain Current
Continuous Source Current (Source-Drain Diode)
1
T
A
= 25°C
Maximum Power Dissipation
1
T
A
= 70°C
Operating Junction and Storage Temperature Range
A
W
°C
Thermal Characteristics
Symbol
R
θJA
R
θJA2
R
ΘJC
Description
Typical Junction-to-Ambient steady state, one FET on
Industry Standard Junction-to-Ambient Figure, t < 10 sec.
Typical Junction-to-Case, one FET on
Value
100
62.5
35
Units
°C/W
°C/W
°C/W
7126.2002.10.0.9
1
30V N-Channel Power MOSFET
Electrical Characteristics
Symbol
Description
(T
J
=25°C unless otherwise noted)
Conditions
V
GS
=0V, I
D
=250µA
V
GS
=10V, I
D
=6.8A
V
GS
=4.5V, I
D
=5.4A
V
GS
=10V ,V
DS
=5V (Pulsed)
V
GS
=V
DS
, I
D
=250µA
V
GS
=±20V, V
DS
=0V
V
GS
=0V,V
DS
=30V
V
GS
=0V,V
DS
=30V, T
J
=70°C
V
DS
=5V, I
D
=6.8A
V
DS
=15V, I
D
=6.8A, V
GS
=5V
V
DS
=15V, I
D
=6.8A, V
GS
=10V
V
DS
=15V, I
D
=6.8A, V
GS
=10V
V
DS
=15V, I
D
=6.8A, V
GS
=10V
V
DD
=15V, V
GS
=10V, R
D
=3Ω, R
G
=6Ω
V
DD
=15V, V
GS
=10V, R
D
=3Ω, R
G
=6Ω
V
DD
=15V, V
GS
=10V, R
D
=3Ω, R
G
=6Ω
V
DD
=15V, V
GS
=10V, R
D
=3Ω, R
G
=6Ω
2
AAT7126
Min
30
Typ
Max
Units
V
DC Characteristics
BV
DSS
Drain-Source Breakdown Voltage
R
DS(ON)
I
D(ON)
V
GS(th)
I
GSS
I
DSS
Drain-Source ON-Resistance
On-State Drain Current
2
Gate Threshold Voltage
Gate-Body Leakage Current
Drain Source Leakage Current
2
19.5
32
24
1.0
26
41
mΩ
A
V
nA
µA
S
±100
1
5
14
8.6
16
2.5
2.8
3
3
12
6
13
24
g
fs
Forward Transconductance
2
Dynamic Characteristics
3
Q
G
Total Gate Charge
Q
GT
Total Gate Charge
Q
GS
Gate-Source Charge
Q
GD
Gate-Drain Charge
t
D(ON)
Turn-ON Delay
t
R
Turn-ON Rise Time
t
D(OFF)
Turn-OFF Delay
t
F
Turn-OFF Fall Time
Source-Drain Diode Characteristics
V
SD
Source-Drain Forward Voltage
I
S
Continuous Diode Current
Note 2: Pulse test: pulse width = 300µs
nC
nC
nC
nC
ns
ns
ns
ns
V
A
V
GS
=0, I
S
=1.7A
1.2
1.7
Note 1: Mounted on 1” x 1” FR4 Copper Board, 10 sec pulse width.
Note 3: Guaranteed by design. Not subjected to production testing.
2
7126.2002.10.0.9
30V N-Channel Power MOSFET
Typical Characteristics
(T
J
= 25ºC unless otherwise noted)
Forward Characteristics
R
DS(ON)
/ R
DS(ON)
at gate = 10 V
25
20
15
10
5
0
0
1
2
3
4
5
AAT7126
Normalized R
DS(ON)
3
10V
6V
5V
4.5V
4V
3.5V
3V
2V
3.5V
4V
4.5V
2
I
D
(A)
1
5V
0
0
5
10
15
6V
10V
20
25
V
D
(V)
I
D
(A)
R
DS(ON)
vs. V
G
100
25
Transfer
5A
80
20
R
DS(ON)
(mΩ)
10A
15A
I
D
(A)
6
8
10
60
40
20
0
0
2
4
15
10
5
0
0
1
2
3
4
5
V
G
(V)
V
G
(V)
Source to Drain Voltage
100
10
8
10
Gate Charge Characteristics
Gate Voltage (V)
0.6
0.8
1
1.2
I
SD
(A)
6
4
2
0
0
4
8
12
16
20
1
0.1
0.4
V
SD
(V)
Gate Charge (nC)
7126.2002.10.0.9
3
30V N-Channel Power MOSFET
Ordering Information
Package
SOP-8
Marking
7126
Part Number (Tape and Reel)
AAT7126IAS-T1
AAT7126
Note: Sample stock is generally held on all part numbers listed in
BOLD.
Package Information
SOP-8
3.90
±
0.10
4.90
±
0.10
6.00
±
0.20
0.375
±
0.125
1.55
±
0.20
45°
0.175
±
0.075
4°
±
4°
0.235
±
0.045
0.825
±
0.445
0.42
±
0.09
×
8
1.27 BSC
All dimensions in millimeters.
