VS-6TQ035SPbF, VS-6TQ040SPbF, VS-6TQ045SPbF
www.vishay.com
Vishay Semiconductors
High Performance Schottky Rectifier, 6 A
TO-263AB
(D
2
PAK)
Base
cathode
2
FEATURES
• 175 °C T
J
operation
• High frequency operation
• Low forward voltage drop
• High purity, high temperature epoxy
encapsulation for enhanced mechanical
strength and moisture resistance
• Guard ring for enhanced ruggedness and long
term reliability
• Meets MSL level 1, per J-STD-020, LF maximum peak
of 260 °C
1
N/C
3
Anode
PRODUCT SUMMARY
Package
I
F(AV)
V
R
V
F
at I
F
I
RM
T
J
max.
Diode variation
E
AS
TO-263AB (D
2
PAK)
6A
35 V, 40 V, 45 V
0.53 V
7 mA at 125 °C
175 °C
Single die
8 mJ
• AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DESCRIPTION
The VS-6TQ... Schottky rectifier series has been optimized
for low reverse leakage at high temperature. The proprietary
barrier technology allows for reliable operation up to 175 °C
junction temperature. Typical applications are in switching
power supplies, converters, freewheeling diodes, and
reverse battery protection.
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
I
F(AV)
V
RRM
I
FSM
V
F
T
J
CHARACTERISTICS
Rectangular waveform
Range
t
p
= 5 μs sine
6 A
pk
, T
J
= 125 °C
Range
VALUES
6
35 to 45
690
0.53
-55 to +175
UNITS
A
V
A
V
°C
VOLTAGE RATINGS
PARAMETER
Maximum DC reverse voltage
Maximum working peak reverse voltage
SYMBOL
V
R
V
RWM
VS-6TQ035SPbF
35
VS-6TQ040SPbF
40
VS-6TQ045SPbF
45
UNITS
V
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Maximum average forward current
See fig. 5
Maximum peak one cycle
non-repetitive surge current
See fig. 7
SYMBOL
I
F(AV)
TEST CONDITIONS
50 % duty cycle at T
C
= 164 °C, rectangular waveform
5 μs sine or 3 μs rect. pulse
I
FSM
10 ms sine or 6 ms rect. pulse
E
AS
I
AR
Following any rated load
condition and with rated
V
RRM
applied
VALUES
6
690
140
8
1.20
mJ
A
A
UNITS
Non-repetitive avalanche energy
Repetitive avalanche current
T
J
= 25 °C, I
AS
= 1.20 A, L = 11.10 mH
Current decaying linearly to zero in 1 μs
Frequency limited by T
J
maximum V
A
= 1.5 x V
R
typical
Revision: 08-Dec-14
Document Number: 94253
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VS-6TQ035SPbF, VS-6TQ040SPbF, VS-6TQ045SPbF
www.vishay.com
Vishay Semiconductors
ELECTRICAL SPECIFICATIONS
PARAMETER
SYMBOL
6A
Maximum forward voltage drop
See fig. 1
V
FM (1)
12 A
6A
12 A
Maximum reverse leakage current
See fig. 2
Threshold voltage
Forward slope resistance
Maximum junction capacitance
Typical series inductance
Maximum voltage rate of change
Note
(1)
Pulse width < 300 μs, duty cycle < 2 %
I
RM (1)
V
F(TO)
r
t
C
T
L
S
dV/dt
T
J
= 25 °C
T
J
= 125 °C
T
J
= T
J
maximum
V
R
= 5 V
DC
(test signal range 100 kHz to 1 MHz), 25 °C
Measured lead to lead 5 mm from package body
Rated V
R
TEST CONDITIONS
T
J
= 25 °C
T
J
= 125 °C
V
R
= Rated V
R
VALUES
0.60
0.73
0.53
0.64
0.8
7
0.35
18.23
400
8.0
10 000
mA
V
m
pF
nH
V/μs
V
UNITS
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER
Maximum junction and storage
temperature range
Maximum thermal resistance,
junction to case
Typical thermal resistance,
case to heatsink
Approximate weight
minimum
maximum
SYMBOL
T
J
, T
Stg
R
thJC
R
thCS
DC operation
See fig. 4
Mounting surface, smooth and greased
TEST CONDITIONS
VALUES
-55 to +175
2.2
°C/W
0.50
2
0.07
6 (5)
12 (10)
g
oz.
kgf · cm
(lbf · in)
UNITS
°C
Mounting torque
6TQ035S
Marking device
Case style D
2
PAK
6TQ040S
6TQ045S
Revision: 08-Dec-14
Document Number: 94253
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VS-6TQ035SPbF, VS-6TQ040SPbF, VS-6TQ045SPbF
www.vishay.com
Vishay Semiconductors
100
T
J
= 175 °C
I
F
- Instantaneous Forward Current (A)
100
I
R
- Reverse Current (mA)
10
1.0
0.1
0.01
0.001
0.0001
T
J
= 150 °C
T
J
= 125 °C
T
J
= 100 °C
T
J
= 75 °C
T
J
= 50 °C
T
J
= 25 °C
0
5
10
15
20
25
30
35
40
45
10
T
J
= 175 °C
T
J
= 125 °C
T
J
= 25 °C
1
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
V
FM
- Forward Voltage Drop (V)
Fig. 1 - Maximum Forward Voltage Drop Characteristics
V
R
- Reverse Voltage (V)
Fig. 2 - Typical Values of Reverse Current vs. Reverse Voltage
1000
C
T
- Junction Capacitance (pF)
T
J
= 25 °C
100
0
10
20
30
40
50
V
R
- Reverse Voltage (V)
Fig. 3 - Typical Junction Capacitance vs. Reverse Voltage
Z
thJC
- Thermal Impedance (°C/W)
10
1.0
P
DM
0.1
D = 0.75
D = 0.50
D = 0.33
D = 0.25
D = 0.20
Single pulse
(thermal resistance)
t
1
t
2
0.01
Notes:
1. Duty factor D = t
1
/t
2
2. Peak T
J
= P
DM
x Z
thJC
+ T
C
0.0001
0.00001
0.0001
0.001
0.01
0.1
1.0
10
100
t
1
- Rectangular Pulse Duration (s)
Fig. 4 - Maximum Thermal Impedance Z
thJC
Characteristics
Revision: 08-Dec-14
Document Number: 94253
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VS-6TQ035SPbF, VS-6TQ040SPbF, VS-6TQ045SPbF
www.vishay.com
Vishay Semiconductors
5
D = 0.20
D = 0.25
D = 0.33
D = 0.50
D = 0.75
RMS limit
Allowable Case Temperature (°C)
180
Average Power Loss (W)
175
170
165
160
155
4
DC
3
Square wave (D = 0.50)
80 % rated V
R
applied
2
DC
1
See note (1)
150
0
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
I
F(AV)
- Average Forward Current (A)
Fig. 5 - Maximum Allowable Case Temperature vs.
Average Forward Current
I
F(AV)
- Average Forward Current (A)
Fig. 6 - Forward Power Loss Characteristics
I
FSM
- Non-Repetitive Surge Current (A)
1000
At any rated load condition
and with rated V
RRM
applied
following surge
100
10
100
1000
10 000
t
p
- Square Wave Pulse Duration (µs)
Fig. 7 - Maximum Non-Repetitive Surge Current
L
High-speed
switch
Freewheel
diode
40HFL40S02
+ V
d
= 25 V
D.U.T.
IRFP460
R
g
= 25
Ω
Current
monitor
Fig. 8 - Unclamped Inductive Test Circuit
Note
(1)
Formula used: T = T - (Pd + Pd
C
J
REV
) x R
thJC
;
Pd = Forward power loss = I
F(AV)
x V
FM
at (I
F(AV)
/D) (see fig. 6);
Pd
REV
= Inverse power loss = V
R1
x I
R
(1 - D); I
R
at V
R1
= 80 % rated V
R
Revision: 08-Dec-14
Document Number: 94253
4
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VS-6TQ035SPbF, VS-6TQ040SPbF, VS-6TQ045SPbF
www.vishay.com
ORDERING INFORMATION TABLE
Vishay Semiconductors
Device code
VS-
1
1
2
3
4
5
6
7
-
-
-
-
-
-
-
6
2
T
3
Q
4
045
5
S
6
TRL PbF
7
8
Vishay Semiconductors product
Current rating (6 A)
Package: T = TO-220
Schottky “Q” series
Voltage ratings
S = D
2
PAK
None = tube (50 pieces)
TRL = tape and reel (left oriented)
TRR = tape and reel (right oriented)
035 = 35 V
040 = 40 V
045 = 45 V
8
-
PbF = lead (Pb)-free
ORDERING INFORMATION
(Example)
PREFERRED P/N
VS-6TQ035SPBF
VS-6TQ035STRRPBF
VS-6TQ035STRLPBF
VS-6TQ040SPBF
VS-6TQ040STRRPBF
VS-6TQ040STRLPBF
VS-6TQ045SPBF
VS-6TQ045STRRPBF
VS-6TQ045STRLPBF
QUANTITY PER REEL
50
800
800
50
800
800
50
800
800
MINIMUM ORDER QUANTITY
1000
800
800
1000
800
800
1000
800
800
PACKAGING DESCRIPTION
Antistatic plastic tubes
13" diameter plastic tape and reel
13" diameter plastic tape and reel
Antistatic plastic tubes
13" diameter plastic tape and reel
13" diameter plastic tape and reel
Antistatic plastic tubes
13" diameter plastic tape and reel
13" diameter plastic tape and reel
LINKS TO RELATED DOCUMENTS
Dimensions
Part marking information
Packaging information
www.vishay.com/doc?95046
www.vishay.com/doc?95054
www.vishay.com/doc?95032
Revision: 08-Dec-14
Document Number: 94253
5
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
