FEATURES
APPLICATIONS
High Temperature
–
Very Low ESR – High Ripple Current –
Stable with Temperature – High Frequency
DC-DC Converters
–
Voltage Regulators
–
Decoupling
-55°C to +105°C
+20% at 120 Hz, 20°C
10
16
20
Operating Temperature Range
Capacitance Tolerance
WVDC
Surge Voltage
SVDC
Dissipation Factor
120 Hz, 20°C
Leakage Current
Low Temperature Stability
Impedance Ratio
(100 kHz)
2.5
4
6.3
25
1.15 x rated WVDC
15% MAX
2 Minutes
0.2CV or 280uA, whichever is greater
<1.25
<1.25
2000 hours at 105°C with rated WVDC applied
Capacitance Change
<20% of initial measured value
Dissipation Factor
<150% of maximum specified value
ESR
<150% of maximum specified value
Leakage Current
<100% of maximum specified value
1000 hours at 60°C with rated voltage applied at 90-95% R.H.
Capacitance Change
<20% of initial measured value
Dissipation Factor
<150% of maximum specified value
ESR
<150% of maximum specified value
Leakage Current
<100% of maximum specified value
Capacitors placed on a 230°C hot plate for 75 seconds with their electrode terminations facing
downward will fulfill the following conditions after being cooled to room temperature
Capacitance Change
<20% of initial measured value
Dissipation Factor
<150% of maximum specified value
ESR
<150% of maximum specified value
Leakage Current
<100% of maximum specified value
-55°C/ +20°C
+105°C/ +20°C
Load Life
Damp Heat test
Resistance to Soldering Heat
Ripple Current Multipliers
120Hz<f<1kHz
0.05
Frequency (Hz)
1kHz<f<10kHz 10kHz<f<100kHz
0.3
0.7
100kHz<f<500kHz
1.0
D+0.5
6.3
8
W+0.2
6.6
8.3
H+0.2
6.6
8.3
LL+0.2
2.1
2.8
R+0..15
.65
.95
S+0.2
1.9
3.2
Feb-17
